Disc & Drum Land Rover Freelander L314

INTRODUCTION

This vehicle is equipped with Anti-Lock Brake System (ABS) as standard equipment. ABS features 4-wheel electronic traction control and hill descent functions as well as anti-lock braking and electronic brake distribution. This article contains information on repair and service of non-ABS portion of the brake system. For servicing and diagnosing ABS portion of braking system, see appropriate ANTI-LOCK article.

BRAKE SYSTEM

Vehicle braking is provided by disc brakes on the front wheels and drum brakes on the rear wheels. The foot brakes are operated by a TEVES Mk25, 4 channel system controlling diagonally split, dual circuit hydraulic system with a vacuum enhanced brake vacuum booster power assistance. (Scheme 1) A cable operated parking brake operates rear brakes. (Scheme 2)

Scheme 1

Scheme 2

FRONT BRAKES

The front brakes each comprise a hub mounted, single piston caliper assembly and a vented disc. The inboard side of the disc is protected by a mudshield. When hydraulic pressure is supplied to the caliper, the piston extends and forces the inner pad against the disc. The caliper body reacts and slides on the guide pins to bring the outer pad into contact with the disc. (Scheme 3)

Scheme 3

REAR BRAKES

The rear brakes each comprise a hub mounted backplate and drum containing leading and trailing brake shoes when operated by the foot brake. An adjuster rod is incorporated to automatically adjust the brake shoes to compensate for wear of the brake linings. Adjustment occurs during operation of the foot brake. When hydraulic pressure is supplied to the wheel cylinder, the cylinder extends and forces the brake shoes against the drum. When a force is supplied to the shoes via the hand brake lever and cables, both brake shoes become leading. (Scheme 4)

Scheme 4

HYDRAULIC SYSTEM

The hydraulic unit of the modulator consists of a pump, 12 solenoid operated valves, and an accumulator and damper chambers. Each brake unit has its own inlet and outlet valves. The hydraulic system operates the brakes in response to brake pedal movement. For normal brake operation, brake pedal movement is assisted by the brake vacuum booster assembly and transmitted to the master cylinder assembly. The master cylinder assembly converts brake pedal movement to hydraulic pressure. Primary and secondary brake pipe circuits supply the hydraulic pressure to the brakes

1. Primary circuit supplies left front and right rear brakes.
2. Secondary circuit supplies right front and left rear brakes.

See

(Scheme 5)

. A Red, brake warning lamp in the instrument pack illuminates if the fluid level in the hydraulic system falls to an unsafe level. The brake fluid level is checked via a brake fluid level switch in the brake fluid reservoir. On right hand drive vehicles the brake fluid reservoir is remotely located on a bracket on the bulkhead. Left hand drive vehicles have the brake fluid reservoir in the usual position on top of the master cylinder. Vacuum for the brake vacuum booster assembly is obtained from the engine intake manifold. To reduce operating noise, sleeving is installed on some of the brake pipes in the engine compartment and the pipes are located in sprung pipe clips.

Scheme 5

MASTER CYLINDER

The master cylinder assembly produces hydraulic pressure to operate the brakes when the brake pedal is depressed. The assembly is attached to the front of the brake vacuum booster assembly, and comprises a cylinder containing 2 pistons in tandem. The rear piston produces pressure for the primary circuit and the front piston produces pressure for the secondary circuit. The brake fluid reservoir is located either on top of the master cylinder assembly (left hand drive vehicles) or above the master cylinder on a bracket on the bulkhead (right hand drive vehicles). The reservoir is internally divided to provide an independent supply of fluid to each brake circuit, and so prevent a single fluid leak from disabling both primary and secondary brake circuits. Should a failure occur in one circuit, the remaining circuit will still operate effectively, although brake pedal travel and vehicle braking distances will increase. If the fluid level in the reservoir is too low, the brake fluid level switch in the reservoir filler cap breaks a contact to the ABS ECU, which sends a CAN message to illuminate the brake warning lamp in the instrument pack.

When the brake pedal is pressed, the front push rod in the brake vacuum booster assembly pushes the primary piston along the cylinder bore. This produces pressure in the primary pressure chamber which, in conjunction with the primary spring, overcomes the secondary spring and simultaneously moves the secondary piston along the cylinder bore. The initial movement of the pistons, away from the piston stops, closes the primary and secondary center valves. Further movement of the pistons then pressurizes the fluid in the primary and secondary pressure chambers, and thus the brake circuits. The fluid in the chambers, behind the pistons, is unaffected by movement of the pistons and can flow unrestricted through the feed holes between the chambers and the reservoir. When the brake pedal is released, the primary and secondary springs push the pistons back down the bore of the cylinder. As the pistons contact the piston stops, the primary and secondary center valves open, which allows fluid to circulate unrestricted between the 2 hydraulic circuits and the reservoir, through the center valves, the chambers behind the pistons and the feed holes.

BRAKE FLUID LEVEL SWITCH

The Brake Fluid Level Switch (BFLS) is a Reed switch located in the brake fluid reservoir. The BFLS is connected to the ABS ECU and to ground. The BFLS is closed when the brake fluid level is above the minimum limit. If the brake fluid level decreases below the minimum limit, the BFLS opens and the ABS ECU sends a CAN message to the instrument pack to activate the brake warning lamp.

MECHANICAL BRAKE SWITCH

A mechanical brake pedal switch is used to illuminate the stop/brake lamps on the vehicle because of its high current carrying/switching capabilities. It is also used to input the status of the brake pedal to the ABS ECU. This switch is a double contact switch where the Brake Lamp Switch (BLS) contacts are open and the Brake Test Switch (BTS) contacts are closed when the brake pedal is at rest. When the pedal is depressed, the BLS contacts close and BTS contacts open, supplying 12 volts to the brake/stop lamps and indicating to the ABS ECU that the pedal has been operated. When the pedal is depressed there is a time when both the BLS and the BTS contacts are closed, which allows the ABS ECU to perform a plausibility check on the switch. A Hall effect brake pedal position sensor is installed adjacent to the mechanical brake switch. This is not used by the brake system but by other system ECU's which are not compatible with the outputs from a mechanical switch.

BRAKE VACUUM BOOSTER

The brake vacuum booster assembly provides power assistance to reduce the pedal load when braking. The assembly is attached to the front of the pedal box and comprises a circular housing containing a diaphragm, push rods, valve and filter. A push rod at the rear of the housing is connected to the brake pedal. The vacuum line is connected to a port in the front face of the housing. With the brake pedal released and the engine running, vacuum pressure is present on both sides of the diaphragm. When the brake pedal is pressed, the rear push rod moves forward and opens the valve to allow atmospheric pressure through the filter into the pedal side of the diaphragm. The pressure differential acting on the diaphragm increases the pressure being applied by the brake pedal, which is transmitted to the master cylinder via the forward push rod. If the vacuum booster fails, the hydraulic system will still function but will require greater pedal effort due to the lack of vacuum assistance.

VACUUM ENHANCER SYSTEM

Note. The vacuum enhancer solenoid valve is no longer installed on vehicles from 2003 model year onwards. On these vehicles the solenoid valve is removed, but the venturi valve and associated piping is retained. On this system the vacuum enhancement is still required, but due to the deletion of the air assist injectors, the vacuum enhancement can be permanently operated.

The vacuum enhancer system increases the relatively low vacuum available from the intake manifold to increase braking assistance. The system consists of a venturi valve, a solenoid valve and associated pipes. (Scheme 1)

The venturi valve is installed in the vacuum pipe between the brake vacuum booster and the intake manifold. An air feed pipe, from the intake duct upstream of the throttle body via the solenoid valve, is also connected to the venturi valve. Internal ducts in the venturi valve connect the brake vacuum booster and air feed ports to the intake manifold port. The duct connecting the air feed port to the intake manifold port incorporates the venturi. A check valve, integrated into the brake vacuum booster port, prevents the reverse flow of air and fuel vapor to the brake vacuum booster. The solenoid valve controls the air feed to the venturi valve. Operation of the solenoid valve is controlled by the ECM.

To improve engine idle speed refinement, when the gearbox lever is in Park or Neutral, the solenoid valve is closed and the brake vacuum booster senses the vacuum in the intake manifold via the venturi valve. When the gearbox lever is selected to positions other than Park or Neutral, the ECM energizes the solenoid valve and air from the upstream side of the throttle body is fed to the venturi valve. The air flows through the venturi valve into the intake manifold. As the air flows through the venturi in the venturi valve, it increases in velocity and decreases in pressure, resulting in an increase in the vacuum sensed by the brake vacuum booster. Depending on ambient conditions and engine speed, the vacuum enhancer system increases intake manifold vacuum by a maximum of approximately 40 percent.

PARKING BRAKE

The parking brake operates on both rear brakes via 2 parking brake cables, a cable equalizer and an intermediate rod on the parking brake lever. (Scheme 2) As the parking brake lever is applied, movement is transmitted by the intermediate rod and the cable equalizer to the two parking brake cables. Each parking brake cable pulls on a lever on the trailing brake shoe. The lever pivots against the brake adjuster rod, which forces the brake shoes apart and brings the brake linings into contact with the drum. The cables are adjusted by the parking brake adjust nut that locates the cable equalizer on the intermediate rod. A warning switch, on the base of the parking brake lever, operates the brake warning lamp in the instrument pack. When the parking brake is applied and the ignition is on, the warning switch connects a ground to the instrument pack and illuminates the brake warning lamp. In some markets, the central control unit performs a bulb check of the brake warning lamp each time the ignition is switched on.

BLEEDING BRAKE SYSTEM

Note. Following procedure covers partial bleeding of the system. Bleeding could be performed where only the primary or secondary circuit have been disturbed in isolation. It should only be necessary to bleed the disturbed system. This partial bleeding of the hydraulic system is only permissible if a brake pipe or hose has been disconnected with only minor loss of fluid.

Note. If any components upstream of brake modulator, including modulator itself are replaced. Brake system must be bled using procedure on TestBook/T4 scan tool, to ensure that all air is expelled from the new components.

BLEEDING SEQUENCE

Bleeding sequence starts from left front to right front to left rear to right rear.

BLEEDING PROCEDURE

1. Raise and support vehicle. Ensure that all lines and connections are tight and no leaks are present. Fill brake fluid reservoir to MAX level with NEW DOT 4 brake fluid.
2. Attach bleed hose to the first brake caliper bleed screw in sequence. Obtain a clean transparent bottle containing a small amount of clean brake fluid and a bleed hose. (Scheme 6) Ensure free end of hose is submerged in the clean brake fluid. Apply pressure to brake pedal several times, then apply steady pressure. Loosen bleed screw to release brake fluid and air. Allow pedal to return unassisted.
3. Depress brake pedal steadily through its full stroke and allow to return unassisted. Repeat procedure unit a flow of clean, air-free fluid is purged into container. Then while holding pedal at end of its downward stroke, tighten bleed screw to specification. See «TORQUE SPECIFICATIONS»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__torque-specifications).
4. Fill brake fluid reservoir to MAX level with NEW DOT 4 brake fluid. Repeat procedure for the other 3 brake calipers in sequence. See «BLEEDING SEQUENCE»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__bleeding-sequence).
5. Remove tube from bleed screw and install bleed screw dust cap. Apply brakes and check for leakage. Road test vehicle. Check brake pedal for short firm travel when brakes are applied.

Scheme 6

ADJUSTMENTS

BRAKELIGHT SWITCH

Brakelight switch is automatically set during installation. If the setting is disturbed, brakelight switch may be readjusted by depressing brake pedal, pulling plunger out of brakelight switch body until it contacts pedal, and releasing brake pedal.

MASTER CYLINDER PUSH ROD

Note. Master cylinder push rod is not adjustable.

Checking Parking Brake

1. Release ash tray panel from rear console, disconnect connector from power socket and remove ash tray panel. Fully release parking brake lever. Start engine and allow to idle. With engine running, apply foot brake a minimum of 30 times, to ensure full adjustment of rear brake shoes. Turn off engine.
2. Apply parking brake lever one notch at a time and count the number of notches required to apply the brakes firmly. Should be equivalent to a pull of about 44 lbs (20 kg) applied at mid point of parking brake lever grip. Parking brake lever travel should be 4-7 notches. Adjust parking brake cable tension if travel is outside limits.

Adjusting Parking Brake

Note. Ensure parking brake shoes are properly adjusted before adjusting parking brake cable.

Note. If carrying out parking brake adjustment after brake drum installation, apply brake pedal a minimum of 30 times, to ensure full adjustment of rear brake shoes.

1. Raise rear of vehicle. Check parking brake cable connections for free movement in parking brake equalizer. Apply parking brake lever one notch.
2. Tighten equalizer adjusting nut until rear wheels drag slightly when turned. (Scheme 7) Release parking brake lever and check that rear wheels do not drag when turned. Adjust rear brakes if necessary.
3. Apply parking brake one notch at a time and count the number of notches until both rear wheels lock. This should be a minimum of 4 and a maximum of 7 clicks. Adjust equalizer nut if necessary.
4. Release parking brake. Install ash tray panel and cigar lighter to rear console. Remove stands and lower vehicle.

Scheme 7

SERVICING

Manufacturer specifies replacing brake fluid every 36 months or 36,000 miles, whichever is sooner using DOT 4 brake fluid. DO NOT use brake fluid of a different specification. After replacing brake fluid, bleed brake system. See BLEEDING BRAKE SYSTEM .

REMOVAL & INSTALLATION

1. Disconnect brake light switch connector. Release bayonet fitting on brake light switch and remove switch. (Scheme 8)
2. Position brake light switch and secure bayonet fitting. Connect brake light switch connector. Depress and hold brake pedal. Reset switch by pulling plunger fully out. Release brake pedal slowly to set switch adjustment.

1. Release bayonet fitting on brake light switch and remove switch. Release sensor from mounting bracket. (Scheme 8) Disconnect sensor connector and remove sensor. Remove sensor mounting from bracket.
2. To install, position sensor to mounting bracket and connect connector. Position switch and secure bayonet fitting. Hold brake pedal depressed and push sensor fully into bracket, release pedal slowly to set sensor position.

Scheme 8

1. Remove brake master cylinder. See «MASTER CYLINDER»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum). Release and disconnect vacuum hose from vacuum booster. Remove and discard vacuum hose seal. Release brake pipes from clips on bulkhead. (Scheme 9)
2. Remove clip and clevis pin securing brake vacuum booster push rod to brake pedal. (Scheme 10) Remove 4 nuts securing vacuum booster to body and remove vacuum booster. Remove and discard gasket.
3. To install, clean vacuum booster and mating faces. Install NEW gasket to vacuum booster. Position vacuum booster to body, install nuts and tighten in a diagonal sequence to specification. See «TORQUE SPECIFICATIONS»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__torque-specifications). Align push rod to brake pedal, install clevis pin and secure with NEW spring clip.
4. Install NEW vacuum hose seal. Connect vacuum hose to vacuum booster. Install brake master cylinder. See «MASTER CYLINDER»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum). Secure brake pipes in retaining clips.

Scheme 9

Scheme 10

1. Release rear ash tray panel from rear console, disconnect connector from cigar lighter and remove ash tray panel. Remove oddments tray liner, raise cubby box lid and remove cubby box. (Scheme 11)
2. Remove 2 rear screws securing rear of console. Remove screw cover and remove 2 front screws securing front of console. Disconnect connectors from window lift switches and if equipped, rear window isolator switch. Release clip securing harness to center console. Remove rear console. Remove switches from rear console.
3. Install switches to console. Position rear console and connect connectors. Install harness clip to center console. Align console, install screws and screw cover. Install cubby box and oddments tray mat. Position rear ash tray panel, connect connector and secure ash tray panel to console.

Scheme 11

1. Raise and support vehicle. Remove front road wheels. Remove lower guide pin bolt from caliper and pivot caliper housing upwards. Remove brake pads and retainers from caliper brackets. (Scheme 3)
2. To install, rotate disc by hand and scrape all scale and rust from around edge of disc. Scrape rust from pad locating surfaces on caliper. Clean dust from calipers using brake cleaning fluid.
3. Position bleed bottle, connect bleed hose to bleed screw and loosen screw. Press piston back into housing and tighten bleed screw to specification. See «TORQUE SPECIFICATIONS»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__torque-specifications). Disconnect bleed hose and remove bottle. Fit pad retainers to caliper bracket.
4. Install pads to caliper bracket. The leading edge of the pads have chamfers on them, the chamfers are asymmetric. It is imperative that the pads are correctly fitted. Pad "A" in illustration must be fitted to the inboard side of the caliper. Pad "B" must be fitted to the outboard side of the caliper. (Scheme 12)
5. Lower caliper housing over pads. Ensure flats on guide pins locate with lugs on caliper housing. Install guide pin bolts and tighten to specification. See «TORQUE SPECIFICATIONS»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__torque-specifications). Repeat procedure for other side.
6. Install road wheels and tighten nuts to specification. See «TORQUE SPECIFICATIONS»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__torque-specifications). Remove safety stands and lower vehicle. Depress brake pedal several times to set pad to disc clearance. Check reservoir and top-up brake fluid.

Scheme 12

Removal

1. Raise and support vehicle. Remove front wheels. If replacing brake hose, loosen brake pipe union to hose and release union. Install plugs to open connections to prevent contamination. Remove 2 clips securing hose to valance and damper bracket. Release clips securing ABS sensor lead to brake hose.
2. Remove banjo bolt securing brake hose to caliper and collect sealing washers. Remove brake hose and plug brake caliper opening. Remove 2 guide pins from caliper housing. Release caliper housing from caliper carrier.
3. Remove 2 brake pads and retainers from caliper carrier. Remove 2 bolts securing caliper carrier and remove carrier. Remove guide pins and seals from carrier. Remove 2 screws securing brake disc to drive flange and remove disc from drive flange.

Installation

1. Clean brake disc and drive flange mating faces. Install disc to drive flange, install screws and tighten to specification. See «TORQUE SPECIFICATIONS»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__torque-specifications) . Clean guide pins and carrier mating faces. Install guide pins and seals to carrier. Install carrier bolts and tighten to specification.
2. Rotate disc by hand and scrape all scale and rust from around edge of disc. Clean location surfaces on caliper bracket. Clean dust from brake parts using brake cleaning fluid. Clean mating faces of caliper and hub.
3. Clean mating faces of caliper and hub. Install pad retainers to caliper bracket. Install brake pads to caliper carrier. See «FRONT DISC BRAKE PADS»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum) .
4. Position caliper housing to carrier, align flats on guide pins with caliper housing. Ensure flats on guide pins locate with lugs on caliper housing. Install guide pin bolts and tighten to specification. See «TORQUE SPECIFICATIONS»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__torque-specifications) .
5. Remove plugs and clean brake pipe male end. Align hose to brake pipe and tighten union to specification. See «TORQUE SPECIFICATIONS»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__torque-specifications) . Secure ABS sensor lead to brake hose. Position hose to support brackets and secure with clips.
6. Clean banjo bolt, hose and caliper mating faces. Using NEW sealing washers, align hose to caliper, install banjo bolt and tighten to specification. See «TORQUE SPECIFICATIONS»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__torque-specifications) .
7. Install road wheels and tighten nuts to specification. See «TORQUE SPECIFICATIONS»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__torque-specifications) . Lower vehicle. Check brake fluid level in reservoir. Bleed air from system. See «BLEEDING BRAKE SYSTEM»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__bleeding-brake-system) . Depress brake pedal several times to locate pads.

1. Disconnect brake fluid level switch connector. Release retaining pin and remove fluid level switch. (Scheme 13)
2. To install, clean brake fluid level switch. Install brake fluid level switch. Connect brake fluid level switch connector.

Scheme 13

1. Disconnect brake fluid level connector. (Scheme 14) Position cloth under master cylinder to absorb spilled fluid. Disconnect secondary system pipe union from master cylinder. Disconnect primary system pipe union from master cylinder. Install plugs to open connections to prevent contamination.
2. Remove Torx bolt securing master cylinder reservoir to access master cylinder retaining nut. (Scheme 14) Remove and discard 2 nuts securing master cylinder to booster, remove master cylinder. Reinstall Torx bolt to reservoir. Remove and discard sealing ring.
3. To install, clean master cylinder and booster mating surfaces. Remove Torx bolt securing brake fluid reservoir to master cylinder. Install NEW sealing ring to master cylinder. Align push rod and position master cylinder to vacuum booster.
4. Install NEW nuts and tighten to specification. See «TORQUE SPECIFICATIONS»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__torque-specifications). Install Torx bolt securing reservoir to master cylinder and tighten to specification.
5. Clean brake pipe unions. Connect primary and secondary brake pipes and tighten unions to specification. See «TORQUE SPECIFICATIONS»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__torque-specifications). Connect fluid level switch connector. Bleed brakes. See «BLEEDING BRAKE SYSTEM»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__bleeding-brake-system).

Scheme 14

1. Release ash tray panel from rear console, disconnect cigar lighter connector and remove ash tray panel. Remove cable adjusting nut. (Scheme 7) Remove 2 bolts securing parking brake cable retaining plate to body and subframe. Remove plate.
2. Release adjusting rod from equalizer and remove parking brake lever assembly. Remove spring from adjusting rod. Raise and support vehicle. Remove road wheels.
3. Remove 2 bolts securing cable retainers to underbody. Release cable from chassis clip. Release cable grommet from floor and pull cable from interior. (Scheme 15) Remove rear brake shoes. See «REAR BRAKE SHOES»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum).
4. Using tool LRT-70-007 release cable retainer from backplate and remove cable from vehicle. (Scheme 16)

Scheme 15

Scheme 16

1. Maneuver cable into position and secure floor grommet. Install and secure parking brake cable to backplate. Install brake shoes. See «REAR BRAKE SHOES»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum) .
2. Align cable retainers, install bolts and tighten to specification. See «TORQUE SPECIFICATIONS»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__torque-specifications) . Secure cable in chassis clip. Connect parking brake cable to equalizer. Ensure spring is in place and install equalizer to adjusting rod.
3. Install cable adjusting nut. Install cable retaining plate bolts and tighten to specification. See «TORQUE SPECIFICATIONS»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__torque-specifications) .
4. Adjust parking brake cable. See «PARKING BRAKE»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum) under ADJUSTMENTS. Install ash tray and cigar lighter to rear console. Install road wheels. Lower vehicle.

PARKING BRAKE LEVER ASSEMBLY

1. Remove center console. See «CENTER CONSOLE»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum). Disconnect Lucar from parking brake warning switch. (Scheme 17) Remove cable adjusting nut.
2. Remove 2 bolts securing parking brake lever assembly. Release adjusting rod from equalizer and remove parking brake lever assembly. Remove spring from adjusting rod.
3. Install spring to adjusting rod. Install parking brake lever assembly, install bolts and tighten to specification. See «TORQUE SPECIFICATIONS»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__torque-specifications). Install cable adjusting nut.
4. Connect Lucar to parking brake switch. Adjust parking brake. See «PARKING BRAKE»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum) under ADJUSTMENTS. Install center console.

Scheme 17

1. Remove center console. See «CENTER CONSOLE»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum) . Disconnect Lucar from parking brake warning switch. Remove clip and clevis pin securing cable to parking brake lever. Remove 2 bolts and remove parking brake lever. Remove 2 screws securing switch to parking brake lever and remove switch.
2. To install, reveres removal procedure. Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__torque-specifications) .

1. Raise and support vehicle. Remove rear road wheels. Remove rear brake drums. See «REAR BRAKE DRUM»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__rear-brake-drum). Depress brake shoe clips and turn to release. Remove both clips and retaining pins. Release parking brake cable from brake shoe lever. (Scheme 4)and (Scheme 18).
2. Ease one brake shoe out of retaining groove in abutment followed by the other shoe. (Scheme 19) Maneuver brake shoe assembly around wheel cylinder and rear hub and remove brake shoe assembly. (Scheme 20)
3. Install an elastic band around wheel cylinder to retain pistons. Noting their installed position, release and remove return springs. Collect adjuster and expander. (Scheme 4)and (Scheme 21).
4. Clean backplate and drum with brake cleaning fluid. Use a wire brush to remove any corrosion, take care not to damage wheel cylinder covers.
5. Inspect all parts for wear or damage. Examine wheel cylinder dust seals for signs of brake fluid leakage, a certain amount of dampness is usual. However, if excessive fluid is apparent, lift dust seals and check for leakage. Renew wheel cylinders and brake shoes if linings are contaminated.
6. Check wheel cylinder pistons for freedom of movement. Check brake adjuster rod threads, nut and parking brake linkage for wear. (Scheme 4) Replace if necessary. Check condition of return springs and replace if necessary. Ensure brake adjuster is fully off.

Scheme 18

Scheme 19

Scheme 20

Scheme 21

1. Position adjuster and expander to brake shoes and install return springs. (Scheme 21) Smear brake shoe contact points with Molykote 111 grease. Remove elastic band from wheel cylinder.
2. Maneuver brake shoes around rear hub and locate to abutment and wheel cylinder. Install brake shoe retaining pins and secure with clips. Connect hand brake cable to brake shoe lever.
3. Install brake drum. See «REAR BRAKE DRUM»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__rear-brake-drum). Apply brake pedal a minimum of 30 times to ensure full adjustment of rear brake shoes after refitting. Install road wheels and tighten nuts to specification. See «TORQUE SPECIFICATIONS»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__torque-specifications). Lower vehicle.

REAR BRAKE DRUM

1. Raise and support vehicle. Remove road wheel. Release parking brake. Remove 2 screws securing brake drum and remove brake drum. If brake drum cannot be removed, go to next step.
2. Remove rubber grommet from rear of backplate. Using 2 flat bladed screwdrivers, release ratchet and turn the adjuster to increase shoe-to-drum clearance. Remove brake drum.

1. Replace brake drum if scored, grooved or cracked. Check wheel cylinder pistons for freedom of movement. Clean backplate and brake drum with brake cleaning fluid.
2. Measure inside diameter of drum at 2 points, 90 degrees apart. Replace drum if outside limits. See «DISC/DRUM BRAKE SPECIFICATIONS»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__discdrum-brake-specifications) .
3. Examine wheel cylinder dust seals for signs of brake fluid leakage, a certain amount of dampness is usual. However, if excessive fluid is apparent, lift dust seals and check for leakage. Replace wheel cylinders and brake shoes if linings are contaminated.
4. Apply molykote 111 grease to brake shoe and spring contact points. Check adjuster ratchet and if necessary set to minimum adjustment position as follows: Lever leading shoe away from wheel cylinder. Move adjuster ratchet back fully. Ease shoe back into position.
5. Install brake drum and tighten screws. If necessary, install backplate grommet. Apply brake pedal a minimum of 30 times to ensure full adjustment of rear brake shoes after reinstalling. Check parking brake operation, adjust if necessary. Install road wheels and tighten nuts to specification. See «TORQUE SPECIFICATIONS»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__torque-specifications) . Lower vehicle.

1. Raise and support vehicle. Remove rear brake shoes. See «REAR BRAKE SHOES»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum). Disconnect pipe union from wheel cylinder. Install plugs to open connections to prevent contamination.
2. Remove 2 bolts securing wheel cylinder and remove wheel cylinder. (Scheme 22) Use a wire brush to remove any corrosion. Clean backplate and drum with brake cleaning fluid.
3. Install wheel cylinder to backplate, install bolts and tighten to specification. See «TORQUE SPECIFICATIONS»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__torque-specifications). Connect brake pipe union to wheel cylinder and tighten union to specification.
4. Install brake shoes. See «REAR BRAKE SHOES»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum). Bleed brakes. See «BLEEDING BRAKE SYSTEM»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__bleeding-brake-system). Install road wheels and tighten nuts to specification. See «TORQUE SPECIFICATIONS»(/land-rover/freelander/l314-2003-2006/remont/mechanical-hydraulic/#disc-drum__torque-specifications). Lower vehicle.

Scheme 22

1. Disconnect battery earth ground. Loosen clip and disconnect fresh air intake hose from acoustic cover. Loosen clip and disconnect air intake hose from Mass Air Flow (MAF) sensor. Release 2 turnbuckles securing acoustic cover to left camshaft cover. Release retaining strap and remove engine acoustic cover.
2. Release enhancer from support clips. (Scheme 1)and (Scheme 23). Disconnect solenoid valve connector, if equipped. Release and disconnect vacuum booster pipe. Release clip and disconnect from intake hose. Release and remove enhancer assembly from intake manifold.
3. Install enhancer to intake manifold. Connect to intake hose and secure with clip. Connect vacuum booster hose. Connect solenoid valve connector, if equipped. Install enhancer into clips. Install engine acoustic cover.
4. Connect battery earth ground. Install and secure engine acoustic cover. Connect air intake and air bypass hoses, secure clip. Connect fresh air intake hose to acoustic cover and tighten clip screw.

Scheme 23

OVERHAUL

Note. For exploded view of front brakes (Scheme 1) For exploded view of rear brakes (Scheme 3)

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

DISC/DRUM BRAKE SPECIFICATIONS

1. For disc brake specifications on 2002 vehicles, see «DISC BRAKE»(ref-140590-S09196866952004080600000) in SPECIFICATIONS article.
2. For disc brake specifications on 2003, see «DISC BRAKE»(ref-160732-S22160145542004022600000) in SPECIFICATIONS article.
3. For disc brake specifications on 2004 vehicles, see «DISC BRAKE»(ref-162013-S19967200462004051200000) in SPECIFICATIONS article.
4. For drum brake specifications on 2002 vehicles, see «DRUM BRAKE»(ref-140590-S33530941862004080600000) in SPECIFICATIONS article.
5. For drum brake specifications on 2003 vehicles, see «DRUM BRAKE»(ref-160732-S03840078002004030200000) in SPECIFICATIONS article.
6. For drum brake specifications on 2004 vehicles, see «DRUM BRAKE»(ref-162013-S19150124442004051200000) in SPECIFICATIONS article.
