80.10.02 CONTROLS - HEATER - UP TO 04MY

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 1

Scheme 2

Scheme 3

Scheme 4

1. Remove front console. See «76.25.01 CONSOLE - FRONT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__762501-console-front-up) .
2. Release air blend control cable from control knob and abutment.
3. Release air distribution control cable from control knob and abutment.
4. Disconnect multiplugs from all switches.
5. Disconnect illumination multiplug.
6. Remove heater controls.
7. Remove fan speed switch drive shaft.
8. Remove 2 screws securing fan speed switch and remove switch.
9. Remove 5 switches from heater controls.

REFIT

1. Fit switches to heater control housing.
2. Fit fan speed switch and secure with screws.
3. Fit drive shaft to fan speed switch.
4. Fit heater control assembly to vehicle.
5. Connect switch and illumination multiplugs.
6. Connect air blend control cable to control knob and abutment.
7. Connect air distribution control cable to control knob and abutment.
8. Fit front console. See «76.25.01 CONSOLE - FRONT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__762501-console-front-up) .

80.10.02 CONTROLS - HEATER - FROM 04MY

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 5

Scheme 6

1. Remove the Radio/CD module. See «86.50.03 RADIO CD - FROM 04MY»(/land-rover/freelander/l314-2003-2006/remont/entertainment-systems/#in-car-entertainment) .
2. Remove 4 screws securing heater controls to fascia.
3. Move heater control assembly to access cables.
4. Release air distribution cables from control knobs and abutments.
5. Disconnect 3 multiplugs from heater control assembly.
6. Remove heater controls.

1. Fit heater control assembly to vehicle.
2. Connect multiplugs.
3. Connect heater control cables and secure to abutment with clips.
4. Position heater control panel, fit and tighten screws.
5. Fit Radio/CD module. See «86.50.03 RADIO CD - FROM 04MY»(/land-rover/freelander/l314-2003-2006/remont/entertainment-systems/#in-car-entertainment) .

80.10.18 SERVO-AIR RECIRCULATION

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 7

1. Remove glove box. See «76.52.03 GLOVE BOX»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__765203-glove-box) .
2. Disconnect multiplug from servo.
3. Remove screw securing servo to evaporator and remove servo.

1. Fit servo to evaporator and secure with screw.
2. Connect multiplug to servo.
3. Fit glove box. See «76.52.03 GLOVE BOX»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__765203-glove-box) .

80.10.21 SWITCH - RECIRCULATION CONTROL

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 8

Scheme 9

1. Remove 3 heater control knobs.
2. Remove 2 screws securing heater control finisher to heater controls and remove finisher.
3. Release switch and disconnect multiplug.
4. Remove switch.

1. Fit recirculation switch to heater control panel and connect multiplug.
2. Fit heater control finisher to heater controls and secure with screws.
3. Fit heater control knobs.

80.10.22 SWITCH - FAN - FRONT HEATER

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 10

Scheme 11

Scheme 12

1. Remove front console. See «76.25.01 CONSOLE - FRONT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__762501-console-front-up) .
2. Disconnect multiplug from switch.
3. Remove drive shaft from switch.
4. Remove 2 screws securing switch to heater controls.
5. Remove switch.

1. Fit switch to heater controls and secure with screws.
2. Fit drive shaft to switch.
3. Connect multiplug to switch.
4. Fit front console. See «76.25.01 CONSOLE - FRONT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__762501-console-front-up) .

80.15.05 VENTILATOR - FACE LEVEL LH

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 13

1. Protect fascia and carefully lever vent from fascia.
2. Remove and discard seal.

1. Fit new seal to vent.
2. Fit vent to fascia.

80.15.62 PLENUM - AIR INTAKE

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 14

Scheme 15

1. Remove both wiper arms. See «84.35.01 ARM - WIPER»(/land-rover/freelander/l314-2003-2006/remont/wiperwasher-systems/#wipers-and-washers__843501-arm-wiper) .
2. Remove 6 studs securing rear edge of air intake moulding.
3. Remove air intake moulding and bonnet sealing rubber. NOTE: Do not carry out further dismantling if component is removed for access only.
4. Remove bonnet sealing rubber from air intake moulding.
5. Remove 4 clips securing air intake filter retainers. Remove retainers and filters.

1. Fit filters and retainers to air intake moulding and secure with clips.
2. Fit bonnet sealing rubber to air intake moulding.
3. Fit air intake moulding and secure with studs.
4. Fit wiper arms. See «84.35.01 ARM - WIPER»(/land-rover/freelander/l314-2003-2006/remont/wiperwasher-systems/#wipers-and-washers__843501-arm-wiper) .

80.20.01 HEATER UNIT

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

1. Drain cooling system. See «ENGINE COOLING»(/land-rover/freelander/l314-2003-2006/remont/cooling-fan/#engine-cooling) .
2. Release 2 clips securing heater hoses to heater and disconnect hoses.
3. Remove fascia. See «76.46.23 FASCIA - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__764623-fascia-up-to-04my) or «76.46.23 FASCIA - FROM 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__764623-fascia-from-04my) .
4. Remove 2 bolts from console support bracket, release 2 relays and remove bracket. Up to 03MY illustrated.
5. Disconnect 4 multiplugs from heater controls. Up to 04MY illustrated.
6. Disconnect multiplug from heater and release diagnostic socket.
7. Models with A/C: Disconnect multiplug from evaporator.
8. Remove bolt from duct of LH outer face level vent and release duct from heater.
9. Remove bolt from duct of RH outer face level vent and release duct from heater.
10. Release duct of RH demister vent.
11. Release duct of LH demister vent.
12. Release air inlet connector hose.
13. Release harness from 2 clips on heater.
14. Remove 2 nuts and 1 bolt securing heater to body and remove heater. NOTE: Do not carry out further dismantling if component is removed for access only.
15. Disconnect 2 multiplugs from heater controls.
16. Release air blend control cable from lever and abutment.
17. Release air distribution cable from lever and abutment.
18. Remove heater controls.

1. Position heater controls to replacement heater.
2. Connect air distribution cable to lever and abutment.
3. Connect air blend cable to lever and abutment.
4. Connect multiplugs to heater controls.
5. Fit heater and secure with nuts and bolt.
6. Position harness and connect to clips on heater.
7. Fit air inlet connector hose.
8. Fit RH demister vent duct to heater.
9. Models with passenger airbag, fit carrier. Fit RH outer face level vent duct to heater and secure to body with bolt.
10. Fit LH demister vent duct to heater.
11. Fit LH outer face level vent duct to heater and secure to body with bolt.
12. Models with A/C: Connect multiplug to evaporator.
13. Connect multiplug to heater and secure diagnostic socket.
14. Connect multiplugs to heater controls.
15. Fit console support bracket and secure with bolts.
16. Fit relays to console support bracket.
17. Fit fascia. See «76.46.23 FASCIA - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__764623-fascia-up-to-04my) or «76.46.23 FASCIA - FROM 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__764623-fascia-from-04my) .
18. Connect heater hoses and secure with clips.
19. Refill cooling system. See «ENGINE COOLING»(/land-rover/freelander/l314-2003-2006/remont/cooling-fan/#engine-cooling) .

80.20.05 ELEMENT - POSITIVE TEMPERATURE CO-EFFICIENT (PTC) HEATER - TD4 MODELS

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 23

Scheme 24

1. Remove heater matrix. See «80.20.29 MATRIX - HEATER»(/land-rover/freelander/l314-2003-2006/remont/heater/#heating-and-ventilation__802029-matrix-heater) .
2. Release PTC top and bottom retaining stud bosses from locating holes.
3. Release PTC element harness grommet from passenger side of heater unit.
4. Carefully remove element also guiding harness through assembly

1. Carefully fit PTC element into heater assembly, also guide harness through opposite side.
2. Fit harness grommet.
3. Locate bottom stud bosses into locating holes, then locate top bosses.
4. Fit heater matrix. See «80.20.29 MATRIX - HEATER»(/land-rover/freelander/l314-2003-2006/remont/heater/#heating-and-ventilation__802029-matrix-heater) .

80.20.06 HARNESS - POSITIVE TEMPERATURE CO-EFFICIENT (PTC) HEATER - TD4 MODELS

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

1. Disconnect battery earth lead.
2. Remove bolt securing PTC cable from positive side of battery.
3. Remove ECM from 'E' box. See 18.30.03 ENGINE CONTROL MODULE (ECM) .
4. Disconnect multiplugs from gearbox ECU and cooling fan sensor
5. Release harness from cable ties and release relays from inner casing.
6. Release and disconnect cooling fan and joint harness multiplugs.
7. Release 3 harnesses and air duct rubber sleeve's from housing.
8. Release clips and remove fuse box cover.
9. Remove nut securing ECM housing.
10. Release housing from retaining brackets and remove.
11. Remove 3 nuts securing fuse box, place fuse box aside.
12. Release PTC harness from ECM housing bracket.
13. Remove cover from PTC positive lead fuse holder.
14. Release multiplug and disconnect PTC harness from engine harness.
15. Remove 2 nuts securing both leads from (80 amp) fuse holder, remove leads.
16. Release clip securing PTC harness to ECM housing bracket.
17. Release PTC harness relay from bulkhead retaining bracket.
18. Remove fascia. See «76.46.23 FASCIA - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__764623-fascia-up-to-04my) or «76.46.23 FASCIA - FROM 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__764623-fascia-from-04my) .
19. Release and remove RH demister vent duct
20. Release and remove air duct.
21. Disconnect 3 Lucar connections from PTC element.
22. Release cable ties securing PTC harness to main harness.
23. Remove air intake plenum. See «80.15.62 PLENUM - AIR INTAKE»(/land-rover/freelander/l314-2003-2006/remont/heater/#heating-and-ventilation__801562-plenum-air-intake) .
24. Release 2 clips securing PTC harness from plenum box section.
25. With assistance release 2 grommets from bulkhead and remove PTC harness from vehicle.

1. With assistance route PTC harness through bulkhead and fit grommets.
2. Fit clips securing PTC harness to plenum box
3. Fit air intake plenum. See «80.15.62 PLENUM - AIR INTAKE»(/land-rover/freelander/l314-2003-2006/remont/heater/#heating-and-ventilation__801562-plenum-air-intake) .
4. Fit cable ties securing PTC harness to main bulkhead harness.
5. Connect Lucar connections to PTC element.
6. Fit air duct.
7. Fit RH demister vent duct.
8. Fit fascia. See «76.46.23 FASCIA - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__764623-fascia-up-to-04my) or «76.46.23 FASCIA - FROM 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__764623-fascia-from-04my) .
9. Connect and secure PTC harness multiplug to engine harness.
10. Secure PTC harness/relay to bulkhead bracket
11. Fit clip to secure PTC harness to ECM housing bracket.
12. Fit PTC positive leads to (80 amp) fuse holder, fit and tighten nuts to 7 Nm (5.2 lbf.ft).
13. Fit (80 amp) fuse cover.
14. Secure PTC harness/relays to ECM housing bracket.
15. Fit fuse box, ensure harness routing is clear suspension turret. Tighten nuts to 10 Nm (7 lbf.ft).
16. Fit fuse box cover.
17. Fit 'E' box housing into securing brackets.
18. Fit and tighten nut securing housing.
19. Fit harness and air duct rubber sleeve's to housing.
20. Fit harness cable tie and secure relay in housing.
21. Connect and secure joint harness and cooling fan multiplugs.
22. Connect cooling fan sensor and gearbox ECU multiplugs.
23. Fit ECM into 'E' box. See 18.30.03 ENGINE CONTROL MODULE (ECM) .
24. Position PTC positive cable to battery and secure with bolt, tighten to 25 Nm (18 lbf.ft).
25. Connect battery earth lead.

80.20.08 MICROSWITCH - POSITIVE TEMPERATURE CO-EFFICIENT (PTC) HEATER - TD4 MODELS

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 35

1. Remove front console. See «76.25.01 CONSOLE - FRONT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__762501-console-front-up) .
2. Disconnect multiplug and release microswitch from heater control pack.

1. Fit microswitch to heater control pack and connect multiplug.
2. Fit front console. See «76.25.01 CONSOLE - FRONT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__762501-console-front-up) .

80.20.12 BLOWER ASSEMBLY

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 36

1. Remove 3 screws securing fan motor assembly to heater casing.
2. Release fan assembly from heater and disconnect multiplug.
3. Remove fan assembly.

1. Position fan assembly to heater and connect multiplug.
2. Fit fan assembly to heater casing and secure with screws.

80.20.17 RESISTOR UNIT - FAN MOTOR

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 37

1. LHD models only: Disconnect air inlet connector hose from heater and evaporator.
2. Disconnect multiplug from resistor.
3. Release clip and remove resistor from heater.

1. Fit resistor to heater.
2. Connect multiplug to resistor.
3. LHD models only: Connect air inlet connector hose.

80.20.29 MATRIX - HEATER

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 38

1. Remove heater assembly. See «80.20.01 HEATER UNIT»(/land-rover/freelander/l314-2003-2006/remont/heater/#heating-and-ventilation__802001-heater-unit) .
2. Remove screw securing pipe clamp to heater casing and remove clamp.
3. Remove 2 screws from matrix cover and remove cover.
4. Remove heater matrix.

1. Fit heater matrix to heater assembly.
2. Fit matrix cover and secure with screws.
3. Fit pipe clamp and secure with screw.
4. Fit heater assembly. See «80.20.01 HEATER UNIT»(/land-rover/freelander/l314-2003-2006/remont/heater/#heating-and-ventilation__802001-heater-unit) .

80.20.34 RELAY - POWER - POSITIVE TEMPERATURE COEFFICIENT (PTC) - TD4 MODELS

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 39

Scheme 40

Scheme 41

1. Disconnect battery earth lead.
2. Release and open under bonnet fuse box lid.
3. Remove 3 nuts securing fuse box and release fuse box from studs.
4. Remove fixing and release PTC power relay bracket from studs.
5. Remove cover from PTC power relay.
6. Remove cable ties securing PTC power relay.
7. Remove PTC power relay.

1. Fit PTC power relay.
2. Fit cable ties to secure PTC power relay.
3. Fit cover over PTC power relay.
4. Fit PTC power relay bracket to studs and secure with fixing.
5. Fit fuse box to studs, fit nuts and tighten to 8 Nm (6 lbf.ft).
6. Close fuse box lid.

80.20.35 RELAY - CONTROL - POSITIVE TEMPERATURE CO- (PTC) - TD4 MODELS

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 42

Scheme 43

Scheme 44

1. Release PTC heater fuse holder from PTC heater control relay.
2. Release PTC heater control relay holder from 'E' box bracket.
3. Remove cover from PTC heater control relay.
4. Remove PTC heater control relay.

1. Fit PTC heater control relay.
2. Ensure cover seal is fitted correctly and fit PTC heater control relay cover.
3. Fit PTC heater control relay holder to 'E' box bracket.
4. Fit PTC heater fuse holder to PTC heater control relay holder.

80.40.01 FUEL BURNING HEATER (FBH)

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

1. Disconnect battery earth lead.
2. Remove front bumper. See «76.22.72 BUMPER - ASSEMBLY FRONT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762272-bumper-assembly-front) or «76.22.72 BUMPER - ASSEMBLY - FRONT - FROM 04M»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762272-bumper-assembly-front) .
3. Drain coolant. See «ENGINE COOLING»(/land-rover/freelander/l314-2003-2006/remont/cooling-fan/#engine-cooling) .
4. Position container to collect coolant spillage.
5. Release clips, disconnect coolant feed and return hoses from FBH. CAUTION: Before disconnecting or removing components, ensure the immediate area around joint faces and connections are clean. Plug open connections to prevent contamination.
6. Position an absorbent cloth, release clip and remove fuel feed hose from FBH. Plug connections and move aside.
7. Loosen 1 bolt and remove other bolt securing FBH mounting bracket to body.
8. Release FBH from mounting, disconnect multiplugs and move assembly aside. NOTE: Do not carry out further dismantling if component is removed for access only.
9. Remove 3 bolts securing FBH to mounting bracket.
10. Remove bracket.
11. Release clip securing air intake hose to FBH, release clamp from exhaust manifold.
12. Remove 2 bolts securing air intake and exhaust assembly to FBH and move aside.

1. Fit exhaust pipe, air intake hose and bracket assembly to FBH.
2. Fit and tighten bolts to 10 Nm (7.5 lbf.ft).
3. Tighten exhaust pipe clamp to 5 Nm (3.5 lbf.ft).
4. Align air intake hose with mark on casing and secure with clip.
5. Fit mounting bracket to FBH and tighten bolts to 10 Nm (7.5 lbf.ft).
6. Connect multiplugs to FBH.
7. Fit FBH to body, tighten bolts to 10 Nm (7.5 lbf.ft).
8. Fit coolant hoses to FBH and secure with clips.
9. Fit fuel feed hose to FBH and secure with clip.
10. Refill cooling system. See «ENGINE COOLING»(/land-rover/freelander/l314-2003-2006/remont/cooling-fan/#engine-cooling) .
11. Fit front bumper. See «76.22.72 BUMPER - ASSEMBLY FRONT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762272-bumper-assembly-front) or «76.22.72 BUMPER - ASSEMBLY - FRONT - FROM 04M»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762272-bumper-assembly-front) .
12. Connect battery earth lead.

80.40.31 SENSOR - OUTSIDE TEMPERATURE (OT)

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 50

1. Remove front bumper. See «76.22.72 BUMPER - ASSEMBLY FRONT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762272-bumper-assembly-front) or «76.22.72 BUMPER - ASSEMBLY - FRONT - FROM 04M»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762272-bumper-assembly-front) .
2. Disconnect multiplug from OT sensor.
3. Remove OT sensor from mounting bracket, collect rubber washer and spacer.

1. Clean OT mounting bracket and sensor.
2. Fit OT sensor to mounting bracket, fit rubber washer and spacer, connect multiplug.
3. Fit front bumper. See «76.22.72 BUMPER - ASSEMBLY FRONT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762272-bumper-assembly-front) or «76.22.72 BUMPER - ASSEMBLY - FRONT - FROM 04M»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762272-bumper-assembly-front) .

80.40.40 FUEL PUMP - FUEL BURNING HEATER - UP TO 03MY

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 51

1. . Disconnect battery earth lead.
2. Remove RH rear wheel arch liner. See «76.10.49 LINER - REAR WHEEL ARCH»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__761049-liner-rear-wheel-arch) .
3. Disconnect multiplug from fuel pump.
4. Release clips and remove fuel pipes from fuel pump. CAUTION: Before disconnecting or removing components, ensure the immediate area around joint faces and connections are clean. Plug open connections to prevent contamination.
5. Release fuel pump from rubber mountings and remove pump.

1. Clean fuel hose connections.
2. Position fuel pump and secure in rubber mountings.
3. Position fuel pipes to pump and secure with clips.
4. Connect multiplug to fuel pump.
5. Fit rear wheel arch liner. See «76.10.49 LINER - REAR WHEEL ARCH»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__761049-liner-rear-wheel-arch) .
6. Connect battery earth lead.

80.40.40 FUEL PUMP - FUEL BURNING HEATER - FROM 03MY

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 52

Scheme 53

1. Disconnect battery earth lead. WARNING: Fuel vapour is highly flammable and in confined spaces is also explosive and toxic. Always have a fire extinguisher containing foam, CO2, gas or powder close at hand when handling or draining fuel.
2. Raise vehicle on lift.
3. Remove 2 bolts securing fuel pump and filter assembly to body.
4. Lower fuel pump and filter assembly.
5. Disconnect multiplug from fuel burning heater pump.
6. Position container below fuel pipes to collect fuel spillage.
7. Disconnect fuel pipes from fuel burning heater pump. CAUTION: Before disconnecting or removing components, ensure the immediate area around joint faces and connections are clean. Plug open connections to prevent contamination.
8. Release and remove fuel burning heater pump from fuel pump and filter assembly.

1. Clean fuel pipe connections.
2. Fit and secure fuel burning heater pump to fuel pump and filter assembly.
3. Connect fuel pipes to fuel burning heater pump.
4. Remove container from below fuel pipes.
5. Connect multiplug to fuel burning heater pump.
6. Position fuel pump and filter assembly to body, fit bolts and tighten to 10 Nm (7 lbf.ft).
7. Lower vehicle on lift.
8. Connect battery earth lead.

See also:
• 76.25.01 CONSOLE - FRONT - UP TO 04MY
• 86.50.03 RADIO CD - FROM 04MY
• 76.52.03 GLOVE BOX
• 84.35.01 ARM - WIPER
• ENGINE COOLING
• 76.46.23 FASCIA - UP TO 04MY
• 76.46.23 FASCIA - FROM 04MY
• 76.22.72 BUMPER - ASSEMBLY FRONT - UP TO 04MY
• 76.10.49 LINER - REAR WHEEL ARCH
• 80.20.29 MATRIX - HEATER
• 80.15.62 PLENUM - AIR INTAKE
• 80.20.01 HEATER UNIT
