76.10.47 SUN VISOR

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 73

Scheme 73: REMOVE
Scheme 73: REMOVE
  1. Release sun visor from retaining clip.
  2. Remove 2 screws securing sun visor to roof.
  3. Disconnect multiplug from sun visor.
  4. Remove sun visor.
  5. Remove screw securing sun visor clip to roof and remove clip.

REFIT

  1. Fit sun visor clip to roof and secure with screw.
  2. Fit sun visor to roof and secure with screws.
  3. Fit sun visor to clip.
  4. Position sun visor and connect multiplug.

76.13.12 TRIM CASING - REAR QUARTER - LOWER - 3 DOOR

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 74

Scheme 74: REMOVE
Scheme 74: REMOVE
  1. 03MY: Remove body side rear trim casing. See «76.13.57 TRIM CASING - BODY SIDE - REAR - 3 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761357-trim-casing-body-side) .
  2. Release rear seat squab and fold seat forward.
  3. Release load space lamp from trim casing.
  4. Disconnect 2 Lucars and remove load space lamp.
  5. Remove 6 Torx screws securing luggage compartment carpet retainer.
  6. Remove carpet retainer.
  7. Release 4 turn buckles securing trim casing.
  8. Release and remove trim casing from luggage compartment.
  1. Fit trim casing to luggage compartment and secure with turn buckles.
  2. Fit luggage compartment carpet retainer and secure with Torx screws.
  3. Position load space lamp to casing, connect Lucars and secure lamp to casing.
  4. Reposition rear seat.

76.13.12 TRIM CASING - REAR QUARTER - LOWER - 5 DOOR

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 75

Scheme 75: REMOVE
Scheme 75: REMOVE
  1. Release rear seat squab and fold seat forward.
  2. Remove Torx bolt securing rear seat belt lower fixing to body and position seat belt aside.
  3. Release load space lamp from trim casing.
  4. Disconnect 2 Lucars and remove load space lamp.
  5. Remove 2 screws securing casing to load space carpet retainer.
  6. Release 4 turn buckles securing trim casing.
  7. Release trim casing from 5 retaining clips.
  8. Remove loadspace side trim casing.
  9. Remove 5 retaining clips from trim casing.
  1. Fit retaining clips to casing.
  2. Position casing in loadspace, locate and secure retaining clips.
  3. Fit turn buckles.
  4. Fit screws securing casing to carpet retainer.
  5. Position load space lamp to casing, connect Lucars and secure lamp to casing.
  6. Position loadspace cover retainer and secure with screw.
  7. Fit loadspace cover and secure in retainers.
  8. Position rear seat belt and tighten bolt to 40 Nm (29 lbf.ft).
  9. Reposition rear seats.

76.13.13 TRIM CASING - REAR QUARTER - UPPER - 3 DOOR

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 76

Scheme 76: REMOVE
Scheme 76: REMOVE

Scheme 77

Scheme 77
Scheme 77
  1. Remove rear quarter lower casing. See «76.13.12 TRIM CASING - REAR QUARTER - LOWER - 3 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761312-trim-casing-rear-quarter) .
  2. Remove body rear side casing. See «76.13.57 TRIM CASING - BODY SIDE - REAR - 3 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761357-trim-casing-body-side) .
  3. Remove screw and release rear vent catch.
  4. Remove seat belt access cover from upper casing.
  5. Release 4 clips securing upper casing to body and remove casing.
  6. Remove 4 retaining clips from trim casing.
  1. Fit retaining clips to casing.
  2. Position trim casing, align seat belt and secure casing retaining clips.
  3. Fit seat belt access cover.
  4. Position rear vent sealing rubber to trim casing.
  5. Position rear vent catch and tighten screw.
  6. Fit body rear side trim casing. See «76.13.57 TRIM CASING - BODY SIDE - REAR - 3 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761357-trim-casing-body-side) .
  7. Fit rear quarter lowercasing. See «76.13.12 TRIM CASING - REAR QUARTER - LOWER - 3 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761312-trim-casing-rear-quarter) .

76.13.13 TRIM CASING - REAR QUARTER - UPPER - 5 DOOR

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 78

Scheme 78: REMOVE
Scheme 78: REMOVE

Scheme 79

Scheme 79
Scheme 79
  1. Remove rear quarter lower casing. See «76.13.12 TRIM CASING - REAR QUARTER - LOWER - 5 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761312-trim-casing-rear-quarter) .
  2. Remove 3 screws securing upper casing to body.
  3. Remove retainer from tail door seal.
  4. Release trim casing from 8 retaining clips.
  5. Remove upper casing from loadspace.
  6. Remove 8 retaining clips from casing.
  1. Fit retaining clips to casing.
  2. Position casing in loadspace, locate and secure retaining clips.
  3. Fit retainer to tail door seal.
  4. Fit screws securing bottom of casing.
  5. Fit rear quarter lowercasing. See «76.13.12 TRIM CASING - REAR QUARTER - LOWER - 5 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761312-trim-casing-rear-quarter) .

76.13.26 TRIM FINISHER - "A" POST - UPPER - RENEW

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 80

Scheme 80: REMOVE
Scheme 80: REMOVE
  1. Release seal from door aperture.
  2. Release 4 clips and remove "A" post finisher.
  3. Remove clips from finisher.
  1. Fit clips to "A" post finisher.
  2. Fit finisher to "A" post and secure with clips.
  3. Fit seal to door aperture.

76.13.28 TRIM FINISHER - "B/C" POST - UPPER - RENEW

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 81

Scheme 81: Remove
Scheme 81: Remove

Scheme 82

Scheme 82
Scheme 82
  1. Remove seat base finisher. See «78.55.01 FINISHER - SEAT BASE FRONT - EACH»(/land-rover/freelander/l314-2003-2006/remont/seats/#seats__785501-finisher-seat-base-front) .
  2. Remove Torx bolt securing rear seat belt lower fixing to body and position seat belt aside.
  3. Release finisher from 6 retaining clips and remove finisher. NOTE: Do not carry out further dismantling if component is removed for access only.
  4. Remove 6 retaining clips from finisher.
  5. Remove seat belt slide.
  1. Fit seat belt slide to finisher.
  2. Fit retaining clips to finisher.
  3. Position finisher and engage retaining clips.
  4. Position seat belt lower mounting, fit Torx bolt and tighten to 40 Nm (29 lbf.ft).
  5. Fit seat base finisher. See «78.55.01 FINISHER - SEAT BASE FRONT - EACH»(/land-rover/freelander/l314-2003-2006/remont/seats/#seats__785501-finisher-seat-base-front) .

76.13.29 TRIM FINISHER - "B" POST - LOWER - 5 DOOR

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 83

Scheme 83: REMOVE
Scheme 83: REMOVE

Scheme 84

Scheme 84
Scheme 84

Scheme 85

Scheme 85
Scheme 85

Scheme 86

Scheme 86
Scheme 86
  1. Remove front seat cushion side finisher. See «78.55.06 FINISHER - CUSHION SIDE - FRONT SEAT»(/land-rover/freelander/l314-2003-2006/remont/seats/#seats__785506-finisher-cushion-side) .
  2. Remove scrivet and 5 Torx screws securing front carpet retainer and remove carpet retainer.
  3. Release "B/C" post upper finisher.
  4. Remove 3 Torx screws from top of seat base finisher.
  5. Remove scrivet and Torx screw from "B/C" post lower finisher.
  6. Release and remove "B/C" post lower finisher from seat base finisher.
  1. Locate "B/C" post lower finisher under seat base finisher and rear carpet retainer.
  2. Fit scrivet and Torx screw to "B/C" post lower finisher.
  3. Fit Torx screws to seat base finisher.
  4. Align and secure "B/C" post upper finisher.
  5. Fit front seat cushion side finisher. See «78.55.06 FINISHER - CUSHION SIDE - FRONT SEAT»(/land-rover/freelander/l314-2003-2006/remont/seats/#seats__785506-finisher-cushion-side) .
  6. Fit carpet retainer and secure with Torx screws and scrivet.

76.13.57 TRIM CASING - BODY SIDE - REAR - 3 DOOR

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 87

Scheme 87: REMOVE
Scheme 87: REMOVE

Scheme 88

Scheme 88
Scheme 88
  1. Remove rear seat. See «78.10.48.99 REAR SEAT - LH»(/land-rover/freelander/l314-2003-2006/remont/seats/#seats__78104899-rear-seat-lh) and «78.10.49.99 REAR SEAT - RH»(/land-rover/freelander/l314-2003-2006/remont/seats/#seats__78104999-rear-seat-rh) .
  2. Remove Torx bolt securing rear seat belt lower fixing to body and position seat belt aside.
  3. Remove 4 Torx bolts securing trim casing to body.
  4. Release 2 trim clips and trim casing.
  5. Disconnect multiplug from tweeter if fitted.
  6. Remove trim casing. Do not carry out further dismantling if component is removed for access only
  7. Noting the position of the 3 long screws, remove 10 Torx screws and remove pocket from trim casing.
  8. Remove 3 screws securing pocket finisher to trim casing and remove finisher.
  9. Release 6 tags and remove speaker grille.
  1. Position speaker grille on replacement casing and secure tags.
  2. Fit pocket finisher and secure with screws.
  3. Fit pocket and secure with Torx screws.
  4. Fit trim clips to trim casing.
  5. Position trim casing and if fitted connect tweeter multiplug.
  6. Fit trim casing to body and secure with clips and Torx screws.
  7. Fit seat belt lower fixing and tighten Torx bolt to 50 Nm (37 lbf.ft).
  8. Fit rear seat. See «78.10.48.99 REAR SEAT - LH»(/land-rover/freelander/l314-2003-2006/remont/seats/#seats__78104899-rear-seat-lh) and «78.10.49.99 REAR SEAT - RH»(/land-rover/freelander/l314-2003-2006/remont/seats/#seats__78104999-rear-seat-rh) .

76.25.01 CONSOLE - FRONT - UP TO 04MY

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 89

Scheme 89: REMOVE
Scheme 89: REMOVE

Scheme 90

Scheme 90
Scheme 90

Scheme 91

Scheme 91
Scheme 91

Scheme 92

Scheme 92
Scheme 92
  1. Remove rear console. See «76.25.04 CONSOLE - REAR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__762504-console-rear) .
  2. Remove radio. See «86.50.03 RADIO - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/entertainment-systems/#in-car-entertainment__865003-radio-up-to-04my) .
  3. Remove gear lever knob.
  4. Manual gearbox only: Remove descent selector.
  5. Remove 3 heater control knobs.
  6. Remove 2 screws from heater control panel.
  7. Remove heater control panel.
  8. Release tags and remove radio cage.
  9. Remove 2 screws from top of console.
  10. Remove 4 screws securing heater controls to centre console.
  11. Remove 3 screws from centre and sides of console.
  12. Disconnect multiplugs and bulb holder from switch pack.
  13. Automatic gearbox only: Disconnect multiplugs from gear selector.
  14. Remove centre console.
  15. Remove 4 screws from switch pack assembly and remove assembly.
  1. Position switch pack assembly, fit and tighten screws.
  2. Position console to fascia.
  3. Connect multiplugs and bulb holder to switch pack.
  4. Automatic gearbox only: Connect multiplugs to gear selector.
  5. Fit centre console.
  6. Fit and tighten screws securing centre and sides to console.
  7. Fit and tighten screws securing switch pack to console.
  8. Fit and tighten screws to top of console.
  9. Position radio cage to console and secure with retaining tags.
  10. Position heater control panel, fit and tighten screws.
  11. Fit heater control knobs.
  12. Manual gearbox only: Fit descent selector.
  13. Fit gear lever knob.
  14. Fit radio. See «86.50.03 RADIO - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/entertainment-systems/#in-car-entertainment__865003-radio-up-to-04my) .
  15. Fit rear console. See «76.25.04 CONSOLE - REAR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__762504-console-rear) .

76.25.01 CONSOLE ASSEMBLY FRONT - FROM 04MY

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 93

Scheme 93: REMOVE
Scheme 93: REMOVE

Scheme 94

Scheme 94
Scheme 94

Scheme 95

Scheme 95
Scheme 95
  1. Remove rear console. See «76.25.04 CONSOLE - REAR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__762504-console-rear)
  2. Remove gear selector indicator assembly. See «SELECTOR INDICATOR (FROM MODEL YEAR 2004)»(/land-rover/freelander/l314-2003-2006/remont/automatic-trans/#removal-installation-automatic-transaxle) .
  3. Carefully lever upper console finisher rearward, to release clips on forward edge of finisher.
  4. Remove 4 screws securing centre console.
  5. Disconnect 6 multiplugs and remove console. NOTE: Do not carry out further dismantling if component is removed for access only.
  6. Remove switches from console, noting fitted position.
  7. Remove 4 screws securing ash tray to centre console finisher and remove ash tray.
  1. Fit switches to console.
  2. Fit and secure ash tray to centre console finisher.
  3. Position console assembly and connect multiplugs.
  4. Fit console and secure with screws.
  5. Align upper console finisher and secure with clips.
  6. Refit gearshift selector assembly. See «SELECTOR INDICATOR (FROM MODEL YEAR 2004)»(/land-rover/freelander/l314-2003-2006/remont/automatic-trans/#removal-installation-automatic-transaxle) .
  7. Fit rear console. See «76.25.04 CONSOLE - REAR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__762504-console-rear) .

76.25.04 CONSOLE - REAR

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 96

Scheme 96: REMOVE
Scheme 96: REMOVE

Scheme 97

Scheme 97
Scheme 97

Scheme 98

Scheme 98
Scheme 98

Scheme 99

Scheme 99
Scheme 99

Scheme 100

Scheme 100
Scheme 100

Scheme 101

Scheme 101
Scheme 101
  1. Release rear ash tray panel from rear console, disconnect multiplug from power socket and remove panel.
  2. Remove oddments tray liner, raise cubby box lid and remove cubby box.
  3. Remove 2 screws securing rear of console.
  4. Remove screw cover and remove 2 screws securing front of console.
  5. Disconnect multiplugs from window lift switches and if fitted, rear window isolator switch.
  6. Release clip securing harness to centre console.
  7. Remove rear console.
  8. Remove switches from rear console.
  1. Fit switches to console.
  2. Position rear console and connect multiplugs.
  3. Fit harness clip to centre console.
  4. Align console, fit screws and screw cover.
  5. Fit cubby box and oddments tray mat.
  6. Position rear ash tray panel, connect multiplug and secure ash tray panel to console.

76.46.09 CUP HOLDER - FASCIA FROM 04MY

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 102

Scheme 102: REMOVE
Scheme 102: REMOVE
  1. Remove screw securing fascia cup holder, release 5 clips and remove cup holder.
  1. Fit cup holder to fascia and secure with screw.

76.46.23 FASCIA - UP TO 04MY

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 103

Scheme 103: REMOVE
Scheme 103: REMOVE

Scheme 104

Scheme 104
Scheme 104

Scheme 105

Scheme 105
Scheme 105

Scheme 106

Scheme 106
Scheme 106

Scheme 107

Scheme 107
Scheme 107

Scheme 108

Scheme 108
Scheme 108

Scheme 109

Scheme 109
Scheme 109

Scheme 110

Scheme 110
Scheme 110

Scheme 111

Scheme 111
Scheme 111

Scheme 112

Scheme 112
Scheme 112

Scheme 113

Scheme 113
Scheme 113

Scheme 114

Scheme 114
Scheme 114

Scheme 115

Scheme 115
Scheme 115

Scheme 116

Scheme 116
Scheme 116

Scheme 117

Scheme 117
Scheme 117

Scheme 118

Scheme 118
Scheme 118

Scheme 119

Scheme 119
Scheme 119

Scheme 120

Scheme 120
Scheme 120
  1. Remove front console. See «76.25.01 CONSOLE - FRONT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__762501-console-front-up) .
  2. Remove rotary coupler. For 2002 models, see «ROTARY COUPLER (CLOCKSPRING)»(ref-150749-S37201093772002112100000) . For 2003 models, see «ROTARY COUPLER (CLOCKSPRING)»(ref-160441-S06918976152004021000000) . For 2004 models, see «ROTARY COUPLER (CLOCKSPRING)»(/land-rover/freelander/l314-2003-2006/remont/airbag/#air-bag-restraint-systems) .
  3. Disconnect 4 multiplugs from wiper/indicator switch.
  4. Loosen clamping screw and remove wiper/indicator switch.
  5. Remove 2 screws from steering column lower finisher and remove finisher.
  6. Open drivers glove box lid and remove fuse box cover.
  7. Disconnect 2 multiplugs from fusebox.
  8. Close glove box.
  9. Remove clock. See «88.15.07 CLOCK»(/land-rover/freelander/l314-2003-2006/remont/gauges-instrument-panels/#instruments__881507-clock) .
  10. Remove both "A" post upper trim finishers. See «76.13.26 TRIM FINISHER - "A" POST - UPPER - RENEW»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761326-trim-finisher-a-post) .
  11. Models without passenger airbag: Remove fascia stowage box. See «76.46.45 STOWAGE BOX - FASCIA»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__764645-stowage-box-fascia) .
  12. Models with passenger airbag: Remove passenger airbag. For 2002 models, see «PASSENGER-SIDE AIR BAG MODULE»(ref-150749-S42673312262002112100000) . For 2003 models, see «PASSENGER-SIDE AIR BAG MODULE»(ref-160441-S16641790772004021000000) . For 2004 models, see «PASSENGER-SIDE AIR BAG MODULE»(/land-rover/freelander/l314-2003-2006/remont/airbag/#air-bag-restraint-systems) .
  13. Disconnect 2 main harness to fascia harness multiplugs.
  14. Remove 12 bolts securing fascia.
  15. With assistance remove fascia.
  16. Remove 4 screws, disconnect 3 multiplugs from switches, and remove instrument bezel finisher.
  17. Remove 2 screws from instrument upper cover and remove cover.
  18. Disconnect 3 multiplugs from instrument pack.
  19. Release mirror and headlamp levelling switches.
  20. Disconnect multiplugs from mirror switch and headlamp levelling switch.
  21. Disconnect 4 Lucars from glove box lamp and switch.
  22. Release 9 harness clips.
  23. Feed harness through fascia and remove harness.
  24. Remove 4 screws from instrument pack and remove instrument pack.
  25. Remove 6 screws from instrument pack lower cover and remove cover.
  26. Models without passenger airbag: Remove 4 nuts from grab handle and remove handle.
  27. Remove 4 screws from centre bracket and remove bracket.
  28. Remove 4 face level vents and collect seals.
  29. Remove glove box hinge pins and remove glove box lids.
  30. Remove glove box lamp and mat.
  31. Remove 4 screws from glove box and remove glove box.
  32. Remove 2 screws from each glove box lock and remove locks.
  33. Remove switch blank.
  34. Disconnect multiplug from immobilisation ECU.
  35. Remove 2 nuts securing immobilisation ECU to fascia and remove ECU.
  36. Remove fascia and coin tray mats.
  1. Fit fascia and coin tray mats.
  2. Fit immobilisation ECU to fascia and secure with nuts.
  3. Connect multiplug to immobilisation ECU.
  4. Fit switch blank.
  5. Fit glove box locks to fascia and secure with screws.
  6. Fit glove box and secure with screws.
  7. Fit glove box lamp and mat.
  8. Fit glove box lids and secure hinge pins.
  9. Fit face level vents and seals to fascia.
  10. Fit centre bracket and secure with screws.
  11. Models without passenger airbag: Fit grab handle and secure with nuts.
  12. Fit instrument pack lower cover and secure with screws.
  13. Fit instrument pack to fascia and secure with screws.
  14. Fit fascia harness to fascia and secure with clips.
  15. Connect Lucars to glove box lamp and switch.
  16. Connect multiplugs to mirror switch and headlamp levelling switch.
  17. Fit mirror switch and headlamp levelling switch.
  18. Connect multiplugs to instrument pack.
  19. Fit instrument pack upper cover and secure with screws.
  20. Connect multiplugs to switches on instrument bezel finisher, fit bezel and secure with screws.
  21. With assistance fit fascia to vehicle and secure with bolts.
  22. Connect fascia harness multiplugs to main harness.
  23. Models with passenger airbag: Fit passenger airbag. For 2002 models, see «PASSENGER-SIDE AIR BAG MODULE»(ref-150749-S42673312262002112100000) . For 2003 models, see «PASSENGER-SIDE AIR BAG MODULE»(ref-160441-S16641790772004021000000) . For 2004 models, see «PASSENGER-SIDE AIR BAG MODULE»(/land-rover/freelander/l314-2003-2006/remont/airbag/#air-bag-restraint-systems) .
  24. Models without passenger airbag: Fit fascia stowage box. See «76.46.45 STOWAGE BOX - FASCIA»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__764645-stowage-box-fascia) .
  25. Fit "A" post upper trim finishers. See «76.13.26 TRIM FINISHER - "A" POST - UPPER - RENEW»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761326-trim-finisher-a-post) .
  26. Fit clock. See «88.15.07 CLOCK»(/land-rover/freelander/l314-2003-2006/remont/gauges-instrument-panels/#instruments__881507-clock) .
  27. Open drivers glove box lid and remove fuse box cover.
  28. Connect multiplugs to fusebox.
  29. Fit fusebox cover and close glove box lid.
  30. Fit steering column lower cover and secure with screws.
  31. Fit wiper/indicator switch and tighten clamping screw.
  32. Connect multiplugs to wiper/indicator switch.
  33. Fit rotary coupler. For 2002 models, see «ROTARY COUPLER (CLOCKSPRING)»(ref-150749-S37201093772002112100000) . For 2003 models, see «ROTARY COUPLER (CLOCKSPRING)»(ref-160441-S06918976152004021000000) . For 2004 models, see «ROTARY COUPLER (CLOCKSPRING)»(/land-rover/freelander/l314-2003-2006/remont/airbag/#air-bag-restraint-systems) .
  34. Fit front console. See «76.25.01 CONSOLE - FRONT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__762501-console-front-up) .

76.46.23 FASCIA - FROM 04MY

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 121

Scheme 121: REMOVE
Scheme 121: REMOVE

Scheme 122

Scheme 122
Scheme 122

Scheme 123

Scheme 123
Scheme 123

Scheme 124

Scheme 124
Scheme 124

Scheme 125

Scheme 125
Scheme 125

Scheme 126

Scheme 126
Scheme 126

Scheme 127

Scheme 127
Scheme 127

Scheme 128

Scheme 128
Scheme 128

Scheme 129

Scheme 129
Scheme 129

Scheme 130

Scheme 130
Scheme 130

Scheme 131

Scheme 131
Scheme 131

Scheme 132

Scheme 132
Scheme 132

Scheme 133

Scheme 133
Scheme 133
  1. Remove the Radio/CD module. See «86.50.03 RADIO CD - FROM 04MY»(/land-rover/freelander/l314-2003-2006/remont/entertainment-systems/#in-car-entertainment) .
  2. Remove 4 screws securing heater controls to centre console.
  3. Remove rotary coupler. For 2002 models, see «ROTARY COUPLER (CLOCKSPRING)»(ref-150749-S37201093772002112100000) . For 2003 models, see «ROTARY COUPLER (CLOCKSPRING)»(ref-160441-S06918976152004021000000) . For 2004 models, see «ROTARY COUPLER (CLOCKSPRING)»(/land-rover/freelander/l314-2003-2006/remont/airbag/#air-bag-restraint-systems) .
  4. Disconnect 4 multiplugs from wiper/indicator switch.
  5. Loosen clamping screw and remove wiper/indicator switch.
  6. Remove 2 screws from steering column lower finisher and remove finisher.
  7. Open drivers glove box lid and remove fuse box cover.
  8. Disconnect 2 multiplugs from fuse box.
  9. Close glove box.
  10. Remove clock. See «88.15.07 CLOCK»(/land-rover/freelander/l314-2003-2006/remont/gauges-instrument-panels/#instruments__881507-clock) .
  11. Remove hazard warning switch. See «86.65.50 SWITCH - HAZARD WARNING»(/land-rover/freelander/l314-2003-2006/remont/exterior-lights/#lighting__866550-switch-hazard-warning) .
  12. Remove both "A" post upper trim finishers. See «76.13.26 TRIM FINISHER - "A" POST - UPPER - RENEW»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761326-trim-finisher-a-post) .
  13. Remove passenger airbag. For 2002 models, see «PASSENGER-SIDE AIR BAG MODULE»(ref-150749-S42673312262002112100000) . For 2003 models, see «PASSENGER-SIDE AIR BAG MODULE»(ref-160441-S16641790772004021000000) . For 2004 models, see «PASSENGER-SIDE AIR BAG MODULE»(/land-rover/freelander/l314-2003-2006/remont/airbag/#air-bag-restraint-systems) .
  14. Disconnect 2 multiplugs from fascia harness.
  15. Remove 14 bolts securing fascia.
  16. With assistance remove fascia. NOTE: Do not carry out further dismantling if component is removed for access only.
  17. Disconnect 4 multiplugs from fascia switch assembly.
  18. Remove 4 switches from fascia switch carrier.
  19. Release mirror switch from fascia and disconnect multiplug, remove switch assembly.
  20. Remove passenger glove box internal finisher and remove 4 screws securing liner.
  21. Release glove box liner and release lamp assembly.
  22. Remove passenger side glove box liner assembly.
  23. Remove glove box hinge pins and remove glove box lids.
  24. Remove cruise control switch carrier assembly from fascia. See 19.75.30 SWITCH - ENGAGEMENT (ON OFF) - FROM 04MY .
  25. Carefully release and remove 4 face level fascia air vents.
  26. Remove 2 screws securing drivers side glove box striker plate assembly and collect striker.
  27. Noting fitted position remove fascia harness assembly.
  1. Fit and secure fascia harness.
  2. Fit striker plate, secure with screws and adjust if necessary.
  3. Fit passenger side glove box assembly.
  4. Fit face level air vents.
  5. Fit and secure cruise switch carrier assembly to fascia. See 19.75.30 SWITCH - ENGAGEMENT (ON OFF) - FROM 04MY .
  6. Fit glove box lids and secure hinge pins.
  7. Connect mirror switch multiplug and fit switch assembly to fascia.
  8. Fit switches to fascia carrier and connect multiplugs.
  9. With assistance fit fascia to vehicle and secure bolts to 10 Nm (7 lbf.ft).
  10. Connect fascia harness multiplugs to main harness.
  11. Fit passenger airbag. For 2002 models, see «PASSENGER-SIDE AIR BAG MODULE»(ref-150749-S42673312262002112100000) . For 2003 models, see «PASSENGER-SIDE AIR BAG MODULE»(ref-160441-S16641790772004021000000) . For 2004 models, see «PASSENGER-SIDE AIR BAG MODULE»(/land-rover/freelander/l314-2003-2006/remont/airbag/#air-bag-restraint-systems) .
  12. Fit "A" post upper trim finishers. See «76.13.26 TRIM FINISHER - "A" POST - UPPER - RENEW»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761326-trim-finisher-a-post) .
  13. Fit hazard warning switch. See «86.65.50 SWITCH - HAZARD WARNING»(/land-rover/freelander/l314-2003-2006/remont/exterior-lights/#lighting__866550-switch-hazard-warning) .
  14. Fit clock. See «88.15.07 CLOCK»(/land-rover/freelander/l314-2003-2006/remont/gauges-instrument-panels/#instruments__881507-clock) .
  15. Open drivers side glove box.
  16. Fit Radio/CD module. See «86.50.03 RADIO CD - FROM 04MY»(/land-rover/freelander/l314-2003-2006/remont/entertainment-systems/#in-car-entertainment) .
  17. Fit fuse box cover and close glove box lid.
  18. Fit steering column lower cover and secure with screws.
  19. Fit wiper/indicator switch and tighten clamping screw.
  20. Connect multiplugs to wiper/indicator switch.
  21. Fit rotary coupler. For 2002 models, see «ROTARY COUPLER (CLOCKSPRING)»(ref-150749-S37201093772002112100000) . For 2003 models, see «ROTARY COUPLER (CLOCKSPRING)»(ref-160441-S06918976152004021000000) . For 2004 models, see «ROTARY COUPLER (CLOCKSPRING)»(/land-rover/freelander/l314-2003-2006/remont/airbag/#air-bag-restraint-systems) .
  22. Fit heater control to fascia and secure with screws.

76.46.41 DRINK TRAY ASSEMBLY FASCIA - UP TO 04MY

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 134

Scheme 134: REMOVE
Scheme 134: REMOVE
  1. Open cup holder and remove both rubber mats.
  2. Remove 2 screws securing cup holder assembly and remove assembly.
  1. Position cup holder assembly and secure with screws.
  2. Fit rubber mates and close cup holder.

76.46.45 STOWAGE BOX - FASCIA

Note. Numbers in figures correspond to step numbers in procedures.

REMOVE

  1. Remove mat from stowage box to access screws.
  2. Remove 2 screws.
  3. Remove stowage box from fascia.
  1. Position stowage box and secure with screws.
  2. Fit mat to stowage box.

76.49.04 CARPET - LUGGAGE COMPARTMENT

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 135

Scheme 135: REMOVE
Scheme 135: REMOVE

Scheme 136

Scheme 136
Scheme 136
  1. Remove both rear quarter lower trim casings. See «76.13.12 TRIM CASING - REAR QUARTER - LOWER - 3 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761312-trim-casing-rear-quarter) . See «76.13.12 TRIM CASING - REAR QUARTER - LOWER - 5 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761312-trim-casing-rear-quarter) .
  2. Open lid on security box.
  3. Disconnect multiplug from sub-woofer if fitted.
  4. Remove 6 screws securing lid to body and remove lid.
  5. Remove 4 screws securing lid latch strikers to body and remove strikers.
  6. Remove 4 buckles from rear carpet.
  7. Release carpet from rear seat strikers and lashing eyes and remove carpet.
  1. Fit rear carpet in loadspace and secure with buckles.
  2. Fit lid latch strikers and secure with screws.
  3. Fit security box lid and secure with screws.
  4. Connect multiplug to sub-woofer if fitted.
  5. Close security box lid.
  6. Fit rear quarter lower trim casings. See «76.13.12 TRIM CASING - REAR QUARTER - LOWER - 5 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761312-trim-casing-rear-quarter) . See «76.13.12 TRIM CASING - REAR QUARTER - LOWER - 5 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761312-trim-casing-rear-quarter) .

76.52.03 GLOVE BOX

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 137

Scheme 137: REMOVE
Scheme 137: REMOVE
  1. Open glove box and remove glove box mat.
  2. Release illumination lamp from glove box.
  3. Remove 4 screws from glove box and remove glove box.
  1. Fit glove box and secure with screws.
  2. Fit illumination lamp.
  3. Fit glove box mat.
  4. Close glove box.

76.64.15 HEADLINING - 3 DOOR

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 138

Scheme 138: REMOVE
Scheme 138: REMOVE

Scheme 139

Scheme 139
Scheme 139

Scheme 140

Scheme 140
Scheme 140

Scheme 141

Scheme 141
Scheme 141
  1. Fold front seat squabs forward.
  2. Remove both sun visors. See «76.10.47 SUN VISOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761047-sun-visor) .
  3. Remove both "A" post upper trim finishers. See «76.13.26 TRIM FINISHER - "A" POST - UPPER - RENEW»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761326-trim-finisher-a-post) .
  4. Remove 2 screws securing headlining to front end of roof panel.
  5. Remove roof lamp lens.
  6. Remove 2 screws securing roof lamp to body.
  7. Disconnect multiplug from roof lamp and remove lamp.
  8. Release clips securing headlining rear finisher to body and remove finisher.
  9. Release 3 studs securing rear edge of headlining to roof panel.
  10. Remove 4 screws securing headlining to "B" posts.
  11. Release 2 studs securing sides of headlining to body.
  12. Lower front edge of headlining.
  13. Release headlining from sun roof seal and remove headlining.
  14. Remove studs from headlining.
  15. Remove 3 screws and remove pocket from headlining.
  1. Fit pocket to headlining and secure with screws.
  2. Fit studs to headlining.
  3. Position headlining and secure studs to roof panel.
  4. Position headlining to "B" posts and secure with screws.
  5. Secure headlining behind rear vent rubbers.
  6. Fit headlining rear finisher and secure clips.
  7. Fit headlining to sun roof seal.
  8. Position roof lamp and connect multiplug.
  9. Fit roof lamp and secure with screws.
  10. Fit lens to roof lamp.
  11. Fit both sun visors. See «76.10.47 SUN VISOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761047-sun-visor) .
  12. Fit "A" post upper finishers. See «76.13.26 TRIM FINISHER - "A" POST - UPPER - RENEW»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761326-trim-finisher-a-post) .
  13. Reposition front seat squabs.

76.64.15 HEADLINING - 5 DOOR

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 142

Scheme 142: REMOVE
Scheme 142: REMOVE

Scheme 143

Scheme 143
Scheme 143

Scheme 144

Scheme 144
Scheme 144

Scheme 145

Scheme 145
Scheme 145

Scheme 146

Scheme 146
Scheme 146

Scheme 147

Scheme 147
Scheme 147
  1. Remove both "A" post upper trim finishers. See «76.13.26 TRIM FINISHER - "A" POST - UPPER - RENEW»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761326-trim-finisher-a-post) .
  2. Remove both rear quarter upper trim casings. See «76.13.13 TRIM CASING - REAR QUARTER - UPPER - 5 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761313-trim-casing-rear-quarter) .
  3. Remove both sun visors. See «76.10.47 SUN VISOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761047-sun-visor) .
  4. Remove screw covers and screws from grab handles and remove handles.
  5. Remove grab handle blanking plugs.
  6. Remove lens from front interior lamp.
  7. Remove 2 bolts securing front interior lamp to body.
  8. Release interior lamp from headlining, disconnect multiplug and remove lamp.
  9. Release rear interior lamp from headlining, disconnect multiplug and remove lamp.
  10. Release both "B/C" post upper finishers and position aside.
  11. Release headlining from front and rear door aperture seals.
  12. Models with sun roof: Release and remove sun roof surround finisher from sun roof aperture.
  13. Remove 5 retaining studs from headlining.
  14. With assistance remove headlining through tail door. NOTE: Do not carry out further dismantling if component is removed for access only.
  15. Release 8 tags securing front roof lamp support and remove support.
  16. Remove 14 nuts from stowage pockets, collect backing plates and remove stowage pockets.
  1. Position stowage pockets, and backing plates to headlining and secure with nuts.
  2. Position roof lamp support and secure retaining tags.
  3. With assistance position headlining and secure with retaining studs.
  4. Models with sun roof: Position sun roof surround finisher and secure in position.
  5. Locate headlining to front and rear door aperture seals.
  6. Fit and secure "B/C" post upper finishers.
  7. Position rear interior lamp and connect multiplug.
  8. Fit rear interior lamp to headlining.
  9. Position front interior lamp and connect multiplug.
  10. Fit front interior lamp to headlining and secure with bolts.
  11. Fit grab handle blanking plugs.
  12. Fit grab handles, tighten screws and fit screw covers.
  13. Fit both sun visors. See «76.10.47 SUN VISOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761047-sun-visor) .
  14. Fit "A" post upper trim finishers. See «76.13.26 TRIM FINISHER - "A" POST - UPPER - RENEW»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761326-trim-finisher-a-post) .
  15. Fit rear quarter upper trim casings. See «76.13.13 TRIM CASING - REAR QUARTER - UPPER - 5 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761313-trim-casing-rear-quarter) .

More articles — Body & Frame
