Driver Controls Land Rover Freelander L314

Collision/avoidance 9 illustrations ~764 words

Scheme 1

Scheme 1: REMOVE
Scheme 1: REMOVE
  1. Remove drivers airbag. For 2002 models, see «DRIVER-SIDE AIR BAG MODULE»(ref-150749-S23140253802002112100000) . For 2003 models, see «DRIVER-SIDE AIR BAG MODULE»(ref-160441-S29025151922004021000000) . For 2004 models, see «DRIVER-SIDE AIR BAG MODULE»(/land-rover/freelander/l314-2003-2006/remont/airbag/#air-bag-restraint-systems) .
  2. Release remote control switch leads and disconnect multiplug.
  3. Remove 2 screws securing remote control switch and remove switch.

REFIT

  1. Fit remote control switch and secure with screws.
  2. Connect switch multiplug and fit leads in clip.
  3. Fit drivers airbag. For 2002 models, see «DRIVER-SIDE AIR BAG MODULE»(ref-150749-S23140253802002112100000) . For 2003 models, see «DRIVER-SIDE AIR BAG MODULE»(ref-160441-S29025151922004021000000) . For 2004 models, see «DRIVER-SIDE AIR BAG MODULE»(/land-rover/freelander/l314-2003-2006/remont/airbag/#air-bag-restraint-systems) .

Scheme 2

Scheme 2: REMOVE
Scheme 2: REMOVE

Scheme 3

Scheme 3
Scheme 3
  1. Release 2 clips and remove fascia mounted switch cover.
  2. Remove 2 screws securing switch carrier to fascia.
  3. Release switch carrier from fascia and disconnect PDC multiplug.
  4. Remove switch assembly from carrier.
  1. Fit PDC switch to carrier.
  2. Connect multiplug to PDC switch.
  3. Secure switch carrier to fascia with screws.
  4. Fit and secure switch cover.

Scheme 4

Scheme 4: REMOVE
Scheme 4: REMOVE
  1. 3 door models: Remove RH rear lower quarter trim casing. See «76.13.12 TRIM CASING - REAR QUARTER - LOWER - 3 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761312-trim-casing-rear-quarter) .
  2. 5 door models: Remove RH rear lower quarter trim casing. See «76.13.12 TRIM CASING - REAR QUARTER - LOWER - 5 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761312-trim-casing-rear-quarter) .
  3. Disconnect 2 multiplugs from parking aid ECU.
  4. Remove 2 nuts securing parking aid ECU to mounting bracket and remove ECU.
  1. Position parking aid ECU to mounting bracket, fit nuts and tighten to 4 Nm (3 lbf.ft).
  2. Connect multiplugs to parking aid ECU.
  3. 3 door models: Fit RH rear lower quarter trim casing. See «76.13.12 TRIM CASING - REAR QUARTER - LOWER - 3 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761312-trim-casing-rear-quarter) .
  4. 5 door models: Fit RH rear lower quarter trim casing. See «76.13.12 TRIM CASING - REAR QUARTER - LOWER - 5 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761312-trim-casing-rear-quarter) .

Scheme 5

Scheme 5: REMOVE
Scheme 5: REMOVE
  1. Remove rear bumper assembly. See «76.22.74 BUMPER VALANCE - REAR UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762274-bumper-valance-rear-up) or «76.22.74 BUMPER VALANCE - REAR FROM 04MY»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762274-bumper-valance-rear-from) .
  2. Disconnect multiplug from parking aid sensor.
  3. Release 2 retaining clips and remove parking aid sensor from finisher.
  4. Remove parking aid sensor finisher from bumper valance.
  1. Fit parking aid sensor finisher to bumper valance.
  2. Fit parking aid sensor to finisher and connect multiplug.
  3. Fit rear bumper assembly. See «76.22.74 BUMPER VALANCE - REAR UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762274-bumper-valance-rear-up) or «76.22.74 BUMPER VALANCE - REAR FROM 04MY»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762274-bumper-valance-rear-from) .

Scheme 6

Scheme 6: REMOVE
Scheme 6: REMOVE
  1. 3 door models: Remove RH rear lower quarter trim casing. See «76.13.12 TRIM CASING - REAR QUARTER - LOWER - 3 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761312-trim-casing-rear-quarter) .
  2. 5 door models: Remove RH rear lower quarter trim casing. See «76.13.12 TRIM CASING - REAR QUARTER - LOWER - 5 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761312-trim-casing-rear-quarter) .
  3. Disconnect multiplug from parking aid sounder.
  4. Remove 2 nuts securing parking aid sounder to mounting bracket and remove sounder.
  1. Position parking aid sounder to mounting bracket and secure with nuts.
  2. Connect multiplug to parking aid sounder.
  3. 5 door models: Fit RH rear lower quarter trim casing. See «76.13.12 TRIM CASING - REAR QUARTER - LOWER - 5 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761312-trim-casing-rear-quarter) .
  4. 3 door models: Fit RH rear lower quarter trim casing. See «76.13.12 TRIM CASING - REAR QUARTER - LOWER - 3 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761312-trim-casing-rear-quarter) .

Scheme 7

Scheme 7: REMOVE
Scheme 7: REMOVE
  1. Remove rear console. See «76.25.04 CONSOLE - REAR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__762504-console-rear) .
  2. Disconnect Lucar from handbrake warning switch.
  3. Release switch from handbrake.
  1. Fit switch to handbrake and connect Lucar.
  2. Fit rear console. See «76.25.04 CONSOLE - REAR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__762504-console-rear) .

REMOVE

  1. Remove fascia cup holder. See «76.46.09 CUP HOLDER - FASCIA - FROM 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__764609-cup-holder-fascia-from) .
  2. Release hazard switch from fascia carrier.
  3. Disconnect multiplug and remove hazard warning switch.
  1. Position hazard warning switch and connect multiplug.
  2. Fit switch to fascia carrier.
  3. Fit fascia cup holder. See «76.46.09 CUP HOLDER - FASCIA - FROM 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__764609-cup-holder-fascia-from) .

Scheme 8

Scheme 8: REMOVE
Scheme 8: REMOVE
  1. Remove front console. See «76.25.01 CONSOLE - FRONT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__762501-console-front-up) or «76.25.01 CONSOLE ASSEMBLY FRONT - FROM 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__762501-console-assembly-front-from) .
  2. Remove cigar lighter element.
  3. Remove bulb holder from lighter.
  4. Release cigar lighter body from console and remove.
  1. Fit and secure cigar lighter body to console.
  2. Fit bulb holder to lighter.
  3. Fit lighter element.
  4. Fit front console. See «76.25.01 CONSOLE - FRONT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__762501-console-front-up) or «76.25.01 CONSOLE ASSEMBLY FRONT - FROM 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__762501-console-assembly-front-from) .

Scheme 9

Scheme 9: REMOVE
Scheme 9: REMOVE
  1. Release mirror switch from fascia and disconnect multiplug.
  1. Position switch, connect multiplug and secure switch to fascia.
