Land Rover Freelander
Wiring diagram

Wiring diagram: Shift interlock — Shift interlock circuit

Land Rover Freelander II facelift · 2010-2012

Repair manual
All systems

Shift interlock circuit Land Rover Freelander II facelift

Components on the diagram

    Components on these wiring diagrams

    Click a component to highlight it on every diagram it appears on.
