Starters: Removal & Installation Land Rover Freelander I рестайлинг

Starter 5 illustrations ~301 words

Removal & Installation

  1. Disconnect battery terminals. See «BATTERY DISCONNECT/CONNECT»(ref-167774-S03339926462004102700000) under SERVICE PRECAUTIONS.
  2. Remove bolt and battery clamp. (Scheme 1)
  3. Remove battery.
  4. Clean battery tray.
  5. Fit battery and clamp, tighten bolt to specifications. See «TORQUE SPECIFICATIONS»(ref-167774-S14638213692004102100000).
  6. Apply petroleum jelly to both terminals, fit and tighten terminal bolts negative lead last.

Scheme 1

Scheme 1
Scheme 1

Removal

  1. Remove battery. See «BATTERY»(ref-167774-S15072526212004102700000).
  2. If equipped with cruise control, disconnect multiplug and hose from cruise control vacuum pump. (Scheme 2)
  3. Release harness clips from battery carrier.
  4. Remove 4 bolts and remove battery carrier. (Scheme 3)
  5. If equipped with cruise control, remove cruise control vacuum pump and mountings from battery carrier. (Scheme 4)

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Installation

  1. If equipped with cruise control, fit mountings and cruise control vacuum pump to battery carrier.
  2. Fit battery carrier. Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(ref-167774-S14638213692004102100000) .
  3. Secure harness clips to battery carrier.
  4. If equipped with cruise control, connect multiplug and hose to cruise control vacuum pump.
  5. Fit battery. See «BATTERY DISCONNECT/CONNECT»(ref-167774-S03339926462004102700000) under SERVICE PRECAUTIONS.
  1. Remove battery. See «BATTERY»(ref-167774-S15072526212004102700000) .
  2. Remove battery carrier. See «BATTERY CARRIER»(ref-167774-S13753679322004102700000) .
  3. Release starter motor solenoid terminal cover. Remove nut securing battery lead to solenoid and disconnect battery lead.
  4. Disconnect Lucar connector from starter solenoid.
  5. Remove 3 bolts securing starter motor to gearbox noting that the left hand bolt also secures the mounting bracket for the Crankshaft Position (CKP) sensor multiplug.
  6. Maneuver and remove starter motor.

Scheme 5

Scheme 5
Scheme 5
  1. Clean starter motor and mating face on gearbox.
  2. Position starter motor to gearbox, align Crankshaft Position (CKP) sensor multiplug bracket. Fit and tighten bolts to specifications. See «TORQUE SPECIFICATIONS»(ref-167774-S14638213692004102100000) .
  3. Connect battery lead to solenoid terminal. Tighten nut to specification. See «TORQUE SPECIFICATIONS»(ref-167774-S14638213692004102100000) . Secure terminal cover.
  4. Connect Lucar connector to starter solenoid.
  5. Fit battery carrier.
  6. Fit battery. See «BATTERY DISCONNECT/CONNECT»(ref-167774-S03339926462004102700000) under SERVICE PRECAUTIONS.
