Reassembly: Overview Land Rover Freelander I рестайлинг

1. Fit selected big-end bearing shells to connecting rods and caps.
2. Lubricate crankshaft journals with clean engine oil. Hold crankshaft with big end journals horizontal, lower crankshaft into main bearings.
3. Carefully pull connecting rods into place, fit connecting rod caps noting that featherways are on opposite sides; fit and lightly tighten dowel bolts.
4. Tighten dowel bolts: Stage 1 - 20 Nm (15 ft. lbs.) Stage 2 - Further 45°
5. Using a lint free cloth and a suitable cleaning solvent, clean bearing ladder and mating face on cylinder block.
6. Apply clean engine oil to crankshaft thrust washers and fit to bearing ladder with oil grooves facing outwards.
7. Fit bearing ladder and ensure that all bearing shells are seated correctly.
8. Noting that longest bolts must be fitted in inner holes in bearing ladder, fit new bolts and tighten. (Scheme 196): Stage 1 - 20 Nm (15 ft. lbs.) Stage 2 - Further 90°
9. Using a lint free cloth and a suitable cleaning solvent, clean mating surfaces on cylinder block and lower crankcase.
10. Apply a continuous bead of sealant, Part No. STC 50550, to paths on lower crankcase as shown then spread to an even film using a roller. (Scheme 197) CAUTION: To avoid contamination, assembly must be completed immediately after application of sealant.
11. Fit 2 M8 slave guide studs into cylinder block at positions shown. (Scheme 198)
12. Position lower crankcase to cylinder block.
13. Fit and lightly tighten 6 M8 bolts, remove guide studs, fit and lightly tighten 2 remaining M8 bolts. (Scheme 199)
14. Using sequence shown, tighten bolts to 25 Nm (18 ft. lbs.).
15. Fit and tighten remaining M8 bolt to 25 Nm (18 ft. lbs.).
16. Fit 2 rear M6 bolts and tighten to 9 Nm (7 ft. lbs.).
17. Clean oil pick-up strainer and mating face.
18. Lubricate new "O" ring with clean engine oil and fit to pick-up strainer. CAUTION: Ensure "O" ring, Part No. LYX 000210L is used.
19. Apply sealant, Part No. STC 50552 to threads of oil pick-up strainer retaining bolt.
20. Position oil pick-up strainer, fit and tighten bolt to 25 Nm (18 ft. lbs.).
21. Clean oil pump, oil seal recess in oil pump body and mating face on cylinder block, ensure bolt holes are clean and dry.
22. Clean oil seal running surface on crankshaft.
