VENT ASSEMBLIES
The vent assemblies allow occupants to control the flow and direction of face level air. Each vent assembly incorporates a thumbwheel to regulate flow and moveable vanes to control direction.
Scheme 37
- Distribution Control Knob
- Blower Fan Speed Control Knob
- Temperature Control Knob
- Fresh/Recirculated Air Selection Switch
- Air Conditioning Selection Switch (Where Fitted)
Rotary knobs are installed on the centre console to control air distribution, blower speed and air temperature. The air distribution and temperature knobs operate cables connected to the control flaps in the heater assembly. The blower speed knob operates a rotary switch in the blower's electrical circuit. Graphics on the control panel indicate the function and operating positions of the controls.
Scheme 38
- Distribution control knob
- Blower fan speed control knob
- Temperature control knob
- Air conditioning selection switch (where fitted)
- Fresh/recirculated air selection switch
