Harnesses Land Rover Discovery L318

Scheme 1

1. Remove camshaft cover gasket.
2. Disconnect engine harness from injector harness.
3. Disconnect multiplugs from injectors. release injector harness from camshaft carrier and remove harness.

Refit

1. Fit new 'O' rings to injector harness connector.
2. Position harness and locate connector to camshaft carrier.
3. Connect injector and engine harness multiplugs.
4. Fit camshaft cover gasket.

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

1. Remove fascia panel. Refer to «REMOVE»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
2. Remove headlining. Refer to «REMOVE»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
3. Remove 5 studs securing sound deadening and remove 3 sound deadening panels.
4. Remove 2 studs securing LH lower 'A' post trim panel and remove trim panel.
5. Release and disconnect 4 multiplugs from LH lower 'A' post.
6. Release clip and disconnect rear washer pipe from LH lower 'A' post.
7. Release harness from behind bonnet release cable.
8. Release harness from 4 retainers in LH upper 'A' post and collect protective sleeves.
9. Release 4 clips securing harness to center of roof.
10. Disconnect multiplug from ACE accelerometer.
11. Disconnect multiplug from interior mirror.
12. Feed harness through roof to upper 'A' post.
13. Release 3 retainers securing harness to RH roof panel.
14. Release 2 cable clips securing body harness to sunroof harness.
15. Drill out 4 rivets securing air conditioning ducting to body, release ducting.
16. Release 2 cable ties securing harness to LH side of body.
17. Release retainer securing harness to LH side of body.
18. Disconnect Lucar from radio aerial LH amplifier.
19. Remove both luggage compartment trim casings. Refer to «REMOVE»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
20. Disconnect 2 multiplugs from rear air conditioning unit.
21. Remove 6 clips securing harness to LH side of body.
22. Remove both rear tail lamps.
23. Disconnect multiplugs from both tail/flasher lamps.
24. Release 2 clips securing harness to rear bumper.
25. Remove nut securing earth header to LH 'E' post and remove grommet from 'E' post.
26. Disconnect multiplug from RF receiver.
27. Feed harness back to air conditioning ducting.
28. Release 3 harness retainers securing harness to RH side of body.
29. Release 6 cable clips securing harness to body.
30. Disconnect Lucar from RH aerial amplifier.
31. Release harness from roof and feed to upper 'E' post.
32. Remove tail door trim casing. Refer to «REMOVE»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components__remove) .
33. Carefully release plastic sheet from tail door.
34. Disconnect multiplug from door latch.
35. Disconnect multiplug and washer tube from rear wiper arm.
36. Disconnect multiplug from rear wiper motor.
37. Disconnect 2 Lucars from heated rear window (HRW).
38. Disconnect multiplug from number plate lamp.
39. Remove 2 screws securing center high mounted stop lamp (CHMSL) cover to tail door glass.
40. Remove CHMSL cover.
41. Disconnect 2 Lucars from CHMSL.
42. Attach draw string to harness and draw harness through tail door.
43. Disconnect draw string from harness, and tape to the tail door.
44. Release 3 clips securing harness to tail door.
45. Release harness sleeve from door outer edge and feed harness through door.
46. Release grommet from 'E' post and feed tail door harness back to upper 'E' post.
47. Disconnect multiplug from fuel flap solenoid.
48. Remove nut securing alarm sounder to RH lower 'E' post.
49. Disconnect multiplug from alarm sounder.
50. Remove alarm sounder.
51. Remove grommet and feed harness from rear bumper to upper 'E' post.
52. Remove nut securing earth headers to RH 'E' post.
53. Feed harness to air conditioning ducting.
54. Remove 4 cable ties securing harness to center of roof.
55. With assistance, remove harness from air conditioning ducting and remove from vehicle.

1. With assistance, position harness to air conditioning ducting and secure with cable ties.
2. Secure harness to sunroof harness with cable clips.
3. Connect multiplug to RF receiver.
4. Feed harness to LH and RH upper 'E' posts.
5. Feed harness through 'E' post to tail lamp and rear bumper and secure with grommet.
6. Connect multiplug to fuel flap solenoid and alarm sounder.
7. Position alarm sounder to rear quarter and secure with nut to 9 Nm (7 lbf.ft).
8. Position both RH earth header to 'E' post and tighten nut to 10 Nm (7 lbf.ft).
9. Feed tail door harness through 'E' post and secure with grommet.
10. Position harness sleeve to outer edge of door and pull harness through door.
11. Secure harness to tail door with clips.
12. Connect washer tube to rear of wiper arm.
13. Remove tape from draw string and secure to CHMSL harness.
14. Draw harness through tail door and connect Lucars to CHMSL.
15. Fit CHMSL cover and secure with screws.
16. Connect multiplug to door lock switch.
17. Connect Lucars to HRW.
18. Connect multiplug to rear wiper motor.
19. Connect multiplug to door latch.
20. Fit plastic sheet to tail door, ensuring it aligns with witness marks.
21. Fit tail door trim casing. Refer to «REFIT»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components__refit) .
22. Connect Lucar to radio aerial RH amplifier.
23. Secure harness to RH side of body with clips and retainers.
24. Position both LH earth header to 'E' post and tighten nut to 10 Nm (7 lbf.ft).
25. Connect multiplugs to both tail/flasher lamps and secure harness to bumper with clips.
26. Fit both rear tail lamps.
27. Secure harness to rear LH side of body with 6 cable clips.
28. Connect 2 Lucars to rear air conditioning unit.
29. Fit both luggage compartment trim casings. Refer to «REFIT»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
30. Feed harness into position for rear interior light.
31. Connect Lucar to radio aerial LH amplifier.
32. Secure harness to body with cable ties clips and retainers.
33. Secure air conditioning ducting to body with rivets.
34. Feed harness to LH lower 'A' post.
35. Secure harness to LH side of body with cable tie clips and retainers.
36. Connect and secure multiplugs to lower LH 'A' post.
37. Feed harness through roof to center.
38. Secure harness behind bonnet release cable.
39. Connect rear washer pipe at lower 'A' post and secure with clip.
40. Secure harness to roof with clips.
41. Connect multiplug to interior mirror, ARC accelerometer.
42. Position sound deadening panels and secure with clips.
43. Fit headlining. Refer to «REFIT»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
44. Fit fascia panel. Refer to «REFIT»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

1. Remove upper inlet manifold. Refer to «DISASSEMBLY»(ref-158799-S36891558992005020100000) .
2. Disconnect injector multiplugs, release harness from fuel rail.
3. Disconnect ignition coil multiplugs.
4. Release and disconnect both HS2O sensor multiplugs.
5. Disconnect CKP sensor multiplug.
6. Disconnect air conditioning compressor multiplug.
7. Remove 2 nuts securing alternator cables and release cables.
8. Disconnect coolant temperature sensor multiplug.
9. Release 2 harness clips from coolant rail.
10. Remove nut securing engine harness positive lead to battery, release lead and position aside.
11. Release clips and remove fuse box cover.
12. Remove bolt securing starter lead to fuse box, release lead and position aside.
13. Disconnect 2 engine harness multiplugs from fuse box.
14. Disconnect EVAP solenoid multiplug.
15. Remove nut securing engine harness earth to body and disconnect engine harness to main harness multiplug.
16. Remove trim fixings securing toe board and remove toe board.
17. Disconnect 5 multiplugs connecting engine harness to ECM.
18. Release engine harness, pull into engine bay.
19. Raise front of vehicle. WARNING: Do not work on or under a vehicle supported only by a jack. Always support the vehicle on safety stands.
20. Remove 3 nuts securing RH exhaust front pipe to manifold. Remove and discard gasket.
21. Remove bolt securing starter heat shield and remove heat shield.
22. Remove nut securing battery cable to starter and disconnect solenoid cable.
23. Disconnect both knock sensor multiplugs.
24. Remove bolt securing harness clip to LH side of engine.
25. Disconnect camshaft sensor and oil pressure switch multiplugs.
26. Remove engine harness.

1. Position engine harness around engine.
2. Connect oil pressure switch and camshaft sensor multiplugs.
3. Fit and tighten bolt securing harness to LH side of engine.
4. Connect both knock sensor multiplugs.
5. Connect battery cable and solenoid cable to starter motor.
6. Position starter heat shield and secure with bolt.
7. Clean exhaust flange mating faces, using a new gasket align exhaust fit nuts and tighten to 60 Nm (44 lbf.ft).
8. Remove stand(s) and lower vehicle.
9. Position harness into footwell and secure grommet.
10. Connect ECM multiplugs.
11. Position toe board and secure with trim fixings.
12. Connect engine harness to main harness multiplug and secure earth lead.
13. Connect EVAP solenoid multiplug.
14. Connect both fuse box multiplugs.
15. Position starter lead to fuse box and secure screw.
16. Fit fuse box cover.
17. Position battery positive lead to battery and secure nut.
18. Secure harness to coolant rail.
19. Position alternator cables and tighten terminal B+ to 18 Nm (13 lbf.ft) and terminal D+ to 5 Nm (3.7 lbf.ft)
20. Connect coolant temperature sensor multiplug.
21. Connect A/C compressor multiplug.
22. Secure harness clip to rear of LH cylinder head.
23. Connect CKP sensor multiplug.
24. Secure injector harness and connect injector multiplugs.
25. Connect coil multiplugs.
26. Connect and secure HS2O sensor multiplug
27. Fit upper inlet manifold. Refer to «REASSEMBLY»(ref-158799-S33978312962005020100000) .
28. Connect battery earth lead.

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

1. Remove engine acoustic cover.
2. Remove battery carrier.
3. Remove engine compartment fuse box cover.
4. Remove bolts securing battery and alternator leads to fuse box.
5. Remove bolt securing heater plug lead to fuse box.
6. Disconnect 2 engine harness multiplugs from fuse box.
7. Disconnect 2 engine harness multiplugs from ECM and main harness.
8. Disconnect multiplug from EGR solenoid.
9. Disconnect multiplug from oil pressure switch.
10. Remove nut and disconnect battery lead from starter solenoid.
11. Disconnect Lucar from starter solenoid.
12. Disconnect multiplug from CKP sensor.
13. Disconnect multiplug from fuel temperature sensor.
14. Release harness clip from coolant pipe.
15. Disconnect multiplug from MAP sensor.
16. Disconnect 4 glow plug connectors.
17. Release nut securing battery lead to alternator and disconnect multiplug from alternator.
18. Disconnect injector multiplug.
19. Remove 2 bolts securing harness to front of cylinder head.
20. Disconnect multiplug from ECT sensor.
21. Disconnect multiplugs from A/C compressor, turbocharger solenoid valve, AAP sensor and MAF sensor.
22. Release harness clips from coolant hose and PAS hose.
23. Note the route of the engine harness, release from underneath of inlet manifold and remove from engine.

1. Position harness on engine.
2. Connect multiplugs to A/C compressor, turbocharger solenoid valve, AAP and MAF sensors.
3. Position harness clips to coolant and PAS hoses.
4. Connect multiplug to ECT sensor.
5. Position harness to front of cylinder head and tighten bolts to 10 Nm (7 lbf.ft).
6. Connect injector multiplug.
7. Connect multiplug and position battery cable to alternator and tighten nut.
8. Connect multiplug to fuel temperature sensor.
9. Connect multiplug to MAP sensor.
10. Connect glow plugs.
11. Connect CKP sensor multiplug.
12. Connect Lucar to starter solenoid.
13. Connect battery lead to starter solenoid and tighten nut to 10 Nm (7 lbf.ft).
14. Position harness clip to coolant pipe.
15. Locate harness over bell housing and connect multiplug to oil pressure switch.
16. Connect 2 multiplugs to EGR solenoids.
17. Connect engine harness multiplug to ECM and main harness.
18. Connect engine harness multiplugs to fuse box.
19. Position glow plug lead to fuse box and tighten bolt to 3.5 Nm (2.6 lbf.ft).
20. Position battery and alternator leads to fuse box and tighten bolts to 6 Nm (4.4 lbf.ft).
21. Fit engine compartment fuse box cover.
22. Fit battery carrier.
23. Fit engine acoustic cover.

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

1. Remove heater assembly. With air conditioning: refer to «80.20.01.98 HEATER ASSEMBLY -- MODELS WITH AIR CONDITIONING»(/land-rover/discovery/l318-2002-2004/remont/heater/#heating-and-ventilation) . Without air conditioning: refer to «80.20.01.99 HEATER ASSEMBLY -- MODELS WITHOUT AIR CONDITIONING»(/land-rover/discovery/l318-2002-2004/remont/heater/#heating-and-ventilation) .
2. Remove 4 clips securing LH and RH trim panels to lower 'A' post.
3. Remove both lower 'A' post trim panels.
4. Remove air filter assembly.
5. Remove battery tray.
6. Remove front bumper. Refer to «REMOVE»(/land-rover/discovery/l318-2002-2004/remont/mirrors/#exterior-fittings) .
7. Disconnect multiplugs from receiver drier and air temperature sensor.
8. Release 3 cable tie clips securing harness to lower support rail.
9. Disconnect multiplugs from cooling fan and horn.
10. Release 3 cable tie clips from front RH panel.
11. Remove RH indicator lamp.
12. Disconnect multiplugs from headlamp and side lamp.
13. Disconnect multiplug from headlamp levelling motor.
14. Release clip securing fog lamp multiplug.
15. Withdraw harness to engine compartment fuse box.
16. Remove nut securing harness earth to body.
17. Release 4 clips and remove engine compartment fusebox cover.
18. Remove 2 bolts securing battery and starter lead to fuse box.
19. Release leads from fusebox.
20. Remove 2 multiplugs from fusebox front.
21. Remove 3 bolts securing fusebox to body.
22. Release fuse box and remove 9 multiplugs from rear of fuse box.
23. Remove fuse box.
24. Disconnect 3 multiplugs from chassis harness.
25. Remove RH front indicator repeater lamp from wing.
26. Disconnect multiplug from repeater lamp.
27. Remove repeater lamp.
28. Attach draw string to indicator lamp harness.
29. Withdraw harness to fuse box.
30. Remove draw string and secure.
31. Disconnect main harness multiplug from engine harness and ABS sensor.
32. Disconnect multiplugs from cruise control actuator and brake fluid level switch.
33. Withdraw harness to bulkhead.
34. Release multiplug from ACE accelerometer.
35. Remove 3 cable tie clips from body and withdraw harness to bulkhead.
36. Disconnect multiplug from LH horn.
37. Remove LH indicator lamp.
38. Disconnect multiplugs from headlamp and side lamp.
39. Disconnect headlamp level multiplug from headlamp levelling motor.
40. Release earth header behind headlamp.
41. Disconnect multiplug from front of washer reservoir.
42. Release clip securing fog lamp multiplug.
43. Disconnect 2 multiplugs from washer pumps.
44. Remove 2 clips securing washer pipes to washer reservoir motors.
45. Remove washer reservoir pipes.
46. Release 2 bolts securing earth points to body.
47. Pull harness into engine bay.
48. Disconnect multiplug from bonnet switch.
49. Disconnect 3 multiplugs from ABS modulator and multiplug from ABS sensor.
50. Release LH indicator repeater lamp.
51. Disconnect multiplug from repeater lamp.
52. Remove repeater lamp.
53. Attach draw string to repeater lamp harness.
54. Pull harness into engine bay, remove draw string and secure.
55. Disconnect multiplug from fuel cut-off switch.
56. Remove plenum molding.
57. Disconnect and release 2 multiplugs from front heated screen element.
58. Pull harness into engine bay.
59. Remove clip securing washer pipes to bonnet.
60. Disconnect pipe from bonnet.
61. Disconnect 11 multiplugs from ECU pack.
62. Remove 2 nuts securing earth headers to LH lower 'A' post.
63. Disconnect 4 multiplugs from body harness.
64. Remove clip securing washer pipe located at lower 'A' post
65. Remove pipe.
66. Disconnect 2 multiplugs from front door harness.
67. With assistance withdraw LH side harness into interior.
68. Disconnect ignition harness multiplug from passenger compartment fusebox.
69. Remove nut securing passenger compartment fusebox to steering support bracket.
70. Release fusebox and disconnect 8 multiplugs.
71. Remove fusebox.
72. Disconnect 7 multiplugs from ignition passive coil and steering column switch assembly.
73. Release 3 multiplugs from steering column support.
74. Disconnect multiplugs from brake and clutch pedal.
75. Disconnect multiplug from RH side body harness.
76. Disconnect 2 multiplugs from RH door harness.
77. Disconnect multiplugs from cruise control ECU, remove nut securing earth header to body and remove earth header.
78. Disconnect 2 multiplugs from ECM.
79. Remove 6 nuts and bolts securing wiper mechanism, release mechanism and disconnect multiplug.
80. With assistance withdraw RH side harness into interior.
81. Release RH side front carpet.
82. Remove nut securing earth header to footwell.
83. Remove earth header.
84. Remove clip securing harness to pedal box.
85. Remove 2 nuts securing harness to tunnel.
86. Disconnect Lucar from handbrake switch.
87. Disconnect multiplug from DCU.
88. Remove rear carpet. Refer to «REMOVE»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
89. Disconnect 3 multiplugs from RH rear door harness.
90. Remove 2 nuts securing 2 earth headers to rear center console tunnel.
91. Remove earth headers from center console.
92. Disconnect multiplug from CD player.
93. Remove 5 clips and 2 retainers securing harness to floor.
94. Disconnect 3 multiplugs from LH rear door harness.
95. Withdraw harness to interior.
96. Maneuver harness over steering column support bracket.
97. With assistance remove main harness.

1. With assistance position main harness to body and maneuver over steering column support bracket.
2. Lay harness in position and secure to floor clips and retainers.
3. Connect LH and RH rear door multiplugs.
4. Connect CD player multiplug.
5. Position center console earth headers and secure with nuts.
6. Fit rear carpet. Refer to «REFIT»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
7. Connect DCU multiplug.
8. Connect Lucar to handbrake switch.
9. Fit and tighten nuts securing harness to transmission tunnel.
10. Secure harness to pedal box.
11. Position footwell earth header and secure with nut.
12. Feed RH side of harness into engine bay.
13. Position carpet.
14. Connect wiper motor multiplug, position mechanism and secure with nuts and bolts.
15. Connect ECM multiplug.
16. Position RH lower 'A' post earth header and secure with nut, connect cruise control multiplug.
17. Connect RH front door and RH side body harness multiplugs.
18. Secure multiplugs to steering column support bracket and connect brake and clutch pedal multiplugs.
19. Connect multiplugs to column switch and passive coil.
20. Position passenger compartment fusebox, connect multiplugs, fit fusebox to fascia and secure with nut.
21. Connect ignition switch multiplug to fuse box.
22. With assistance feed LH side of harness into engine bay.
23. Connect multiplugs to front door harness and body harness.
24. Position earth headers to LH lower 'A' post and secure with nuts.
25. Connect multiplugs to ECU pack.
26. Position harness in engine bay.
27. Connect and secure heated front screen multiplugs.
28. Fit plenum molding.
29. Connect multiplugs to ABS sensor and fuel cut-off switch.
30. Using draw string feed harness through inner wing, remove draw string, connect repeater lamp multiplug and fit lamp.
31. Connect multiplugs to ABS modulator.
32. Feed harness through to front panel.
33. Position body earth leads and secure with bolts.
34. Connect washer reservoir multiplugs and pipes, secure pipes with clips.
35. Secure fog lamp multiplug.
36. Secure earth header behind headlamp.
37. Connect multiplugs to headlamp level motor, headlamp and side lamp.
38. Fit indicator lamp
39. Connect multiplug to LH horn.
40. Feed harness to ACE accelerometer, connect multiplug and secure with cable ties.
41. Connect cruise control, ABS sensor and brake fluid level switch multiplugs.
42. Connect engine harness multiplug and feed harness along RH wing to fuse box.
43. Using draw string pull harness through inner wing, remove draw string, connect repeater lamp multiplug and fit lamp.
44. Connect chassis harness multiplugs.
45. Position engine bay fuse box and connect multiplugs, fit fuse box and secure with screws.
46. Connect multiplugs to front of fuse box.
47. Position battery and starter cables and secure with screws.
48. Fit fuse box cover.
49. Position earth lead and secure with nut.
50. Feed harness through to front panel.
51. Secure fog lamp multiplug.
52. Connect headlamp level motor, headlamp and side lamp multiplugs.
53. Fit indicator lamp.
54. Secure harness to RH front panel.
55. Connect cooling fan and horn multiplug.
56. Secure harness to lower support rail.
57. Connect receiver drier and air temperature sensor multiplugs.
58. Fit front bumper. Refer to «REFIT»(/land-rover/discovery/l318-2002-2004/remont/mirrors/#exterior-fittings) .
59. Fit battery tray.
60. Fit air filter assembly.
61. Position both lower 'A' post trims and secure with studs.
62. Fit heater assembly. With air conditioning: refer to «80.20.01.98 HEATER ASSEMBLY -- MODELS WITH AIR CONDITIONING»(/land-rover/discovery/l318-2002-2004/remont/heater/#heating-and-ventilation) . Without air conditioning: refer to «80.20.01.99 HEATER ASSEMBLY -- MODELS WITHOUT AIR CONDITIONING»(/land-rover/discovery/l318-2002-2004/remont/heater/#heating-and-ventilation) .

Scheme 100

Scheme 101

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

Scheme 108

1. Remove battery cover and disconnect the battery earth lead.
2. Remove CD switch box. Refer to «REMOVE»(/land-rover/discovery/l318-2002-2004/remont/entertainment-systems/#in-car-entertainment-ice) .
3. Remove DVD player unit. Refer to «REMOVE»(/land-rover/discovery/l318-2002-2004/remont/entertainment-systems/#in-car-entertainment-ice) .
4. Release screw covers, remove 4 screws and remove front and rear grab handles from drivers side.
5. Carefully release 'A' post upper finisher from drivers side.
6. Disconnect tweeter multiplug and remove 'A' post finisher.
7. Collect finisher securing clips.
8. Remove 3 screws securing drivers side sun visor and release sun visor.
9. Disconnect multiplug and remove sun visor.
10. Remove 3 screws securing drivers side corner of stowage pocket to roof panel.
11. Release front door seal for access to drivers side 'A' post lower finisher.
12. Remove 2 fixings and remove 'A' post lower finisher from drivers side.
13. Release drivers side front and rear door aperture seals from upper flanges for access to 'B' post upper finisher.
14. Release upper finisher from 'B' post.
15. Release multiplug from DVD unit mounting bracket.
16. Release 2 harness retaining clamps on 'A' post.
17. Disconnect DVD main harness multiplug from vehicle fuse box link harness.
18. Remove DVD main harness from above headlining and from fascia.

1. Fit DVD main harness to fascia and above headlining.
2. Connect DVD main harness multiplug to vehicle fuse box link harness.
3. Secure harness behind clamps at 'A' post and multiplug to DVD unit mounting bracket.
4. Fit upper finisher to 'B' post.
5. Fit 'A' post lower finisher and secure with fixings.
6. Fit seals to front and rear door apertures.
7. Fit screws to secure stowage pocket.
8. Position sun visor and connect multiplug.
9. Fit sun visor and secure with screws.
10. Fit finisher securing clips to 'A' post.
11. Position 'A' post upper finisher and connect tweeter multiplug.
12. Fit 'A' post upper finisher.
13. Fit grab handles, tighten screws and fit screw covers.
14. Fit DVD player unit. Refer to «REFIT»(/land-rover/discovery/l318-2002-2004/remont/entertainment-systems/#in-car-entertainment-ice) .
15. Fit CD switch box. Refer to «REFIT»(/land-rover/discovery/l318-2002-2004/remont/entertainment-systems/#in-car-entertainment-ice) .
16. Connect battery earth lead, fit and secure battery cover.

Scheme 109

Scheme 110

Scheme 111

Scheme 112

1. Remove battery cover and disconnect the battery earth lead.
2. Remove center console. Refer to «REMOVE»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
3. Remove 3 fasteners and release drivers side lower closing panel.
4. Release diagnostic socket and remove closing panel.
5. Rotate turnbuckles and lower fuse box access panel.
6. Disconnect 2 CD switch box link harness multiplugs from vehicle main harness.
7. Disconnect link harness multiplug from CD switch box.
8. Remove 3 cable ties securing CD switch box link harness to fascia support bracket and remove harness.

1. Fit CD switch box link harness and connect multiplugs to vehicle main harness.
2. Connect link harness multiplug to CD switch box.
3. Align CD switch box link harness to fascia support bracket and secure with cable ties.
4. Close and secure fuse box access panel.
5. Position fascia closing panel and fit diagnostic socket.
6. Fit closing panel and secure with fasteners.
7. Fit center console. Refer to «REFIT»(/land-rover/discovery/l318-2002-2004/remont/exteriorinterior-trim/#interior-trim-components) .
8. Connect battery earth lead, fit and secure battery cover.

See also:
• REMOVE
• REMOVE
• REFIT
• 80.20.01.98 HEATER ASSEMBLY -- MODELS WITH AIR CONDITIONING
• REMOVE
• REMOVE
