Starter Motor: Overview Land Rover Discovery IV

Special Tool(s)

Ball joint separator 205-754 (LRT-54-027)

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

1. Disconnect the battery ground cable. For additional information, refer to: «Specification»(ref-579247-S04291360502013100600000) information.
2. Raise and support the vehicle.
3. Remove the front wheel.
4. Remove the engine undershield. For additional information, refer to: «Engine Undershield»(ref-579161-S41158151222013100600000) information.
5. Remove the engine compartment upper RH heat shield. Remove the screw.
6. Remove the upper suspension arm and brake line heat shields for access. Remove the 3 nuts. Remove the 3 bolts. Remove the 3 heat shields.
7. Disconnect the height sensor link arm.
8. Remove the stabilizer bar link nut.
9. Loosen the upper arm retaining nut.
10. Using the special tool, release the upper arm ball joint. Remove and discard the retaining nut.
11. Release the brake hose from the upper arm. Raise the upper arm for access.
12. Disconnect the starter motor electrical connections. Remove the nut.
13. Remove the starter motor. Remove the 2 bolts.
