Wheel Alignment Specifications & Procedures: Adjustments Land Rover Discovery III

Wheel Alignment 1 illustration ~172 words

WHEEL ALIGNMENT PROCEDURES

The following is the only wheel alignment equipment which has been approved.

  1. Beissbarth ML 4600 wheel alignment computer (6 sensor).
  2. Beissbarth ML 4600-8 wheel alignment computer (8 sensor).
  3. Beissbarth ML 4000 wheel alignment computer (8 sensor wireless).
  4. Hunter S411-14.

STEERING LOCK-TO-LOCK ADJUSTMENT

Procedure not available from manufacturer.

TOE ADJUSTMENT

  1. Roll vehicle backwards and forwards to settle linkage. Install alignment equipment according to manufacturer's instructions. Check toe adjustment. See «WHEEL ALIGNMENT SPECIFICATIONS»(ref-161596-S07099946242004041900000) . If toe adjustment is not within specification, go to next step. If toe adjustment is within specification, ensure track rod clamp 8 mm bolts are tightened to 16 ft. lbs. (22 N.m) and 10 mm bolts are tightened to 24 ft. lbs. (33 N.m).
  2. Loosen clamp bolts at both ends of track rod. Rotate track rod to increase or decrease toe adjustment. Tighten track rod clamp 8 mm bolts to 16 ft. lbs. (22 N.m) and 10 mm bolts to 24 ft. lbs. (33 N.m). Recheck front wheel alignment.

Scheme 2

Scheme 2
