PASSENGER COMPARTMENT FUSE BOX
Note. Passenger compartment fuse box is located below and to the side of the steering column. Remove cover using a coin or small screwdriver and turning 90 degrees. (Scheme 1) For fuse box and fuse identification (Scheme 2)- (Scheme 4).
Scheme 1
Scheme 2
Scheme 3
Scheme 4
ENGINE COMPARTMENT FUSE BOX
Note. Engine compartment fuse box is located on passenger's side of engine compartment, next to coolant reservoir. (Scheme 5) For fuse box and fuse identification (Scheme 6)and (Scheme 7).
Scheme 5
Scheme 6
Scheme 7
UNDER SEAT FUSE BOXES
Note. Two identical small fuse boxes are located beneath each front seat. (Scheme 8) For fuse box and fuse identification (Scheme 9)
