Refit — Part 2 Land Rover Discovery II

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

1. Remove heater assembly. With air conditioning: refer to «80.20.01.98 HEATER ASSEMBLY -- MODELS WITH AIR CONDITIONING»(ref-207938-S08939157412005120400000) . Without air conditioning: refer to «80.20.01.99 HEATER ASSEMBLY -- MODELS WITHOUT AIR CONDITIONING»(ref-207938-S28805529652005120400000) .
2. Remove 4 clips securing LH and RH trim panels to lower 'A' post.
3. Remove both lower 'A' post trim panels.
4. Remove air filter assembly.
5. Remove battery tray.
6. Remove front bumper. Refer to «REMOVE»(ref-207934-S35200962142005120400000) .
7. Disconnect multiplugs from receiver drier and air temperature sensor.
8. Release 3 cable tie clips securing harness to lower support rail.
9. Disconnect multiplugs from cooling fan and horn.
10. Release 3 cable tie clips from front RH panel.
11. Remove RH indicator lamp.
12. Disconnect multiplugs from headlamp and side lamp.
13. Disconnect multiplug from headlamp levelling motor.
14. Release clip securing fog lamp multiplug.
15. Withdraw harness to engine compartment fuse box.
16. Remove nut securing harness earth to body.
17. Release 4 clips and remove engine compartment fusebox cover.
18. Remove 2 bolts securing battery and starter lead to fuse box.
19. Release leads from fusebox.
20. Remove 2 multiplugs from fusebox front.
21. Remove 3 bolts securing fusebox to body.
22. Release fuse box and remove 9 multiplugs from rear of fuse box.
23. Remove fuse box.
24. Disconnect 3 multiplugs from chassis harness.
25. Remove RH front indicator repeater lamp from wing.
26. Disconnect multiplug from repeater lamp.
27. Remove repeater lamp.
28. Attach draw string to indicator lamp harness.
29. Withdraw harness to fuse box.
30. Remove draw string and secure.
31. Disconnect main harness multiplug from engine harness and ABS sensor.
32. Disconnect multiplugs from cruise control actuator and brake fluid level switch.
33. Withdraw harness to bulkhead.
34. Release multiplug from ACE accelerometer.
35. Remove 3 cable tie clips from body and withdraw harness to bulkhead.
36. Disconnect multiplug from LH horn.
37. Remove LH indicator lamp.
38. Disconnect multiplugs from headlamp and side lamp.
39. Disconnect headlamp level multiplug from headlamp levelling motor.
40. Release earth header behind headlamp.
41. Disconnect multiplug from front of washer reservoir.
42. Release clip securing fog lamp multiplug.
43. Disconnect 2 multiplugs from washer pumps.
44. Remove 2 clips securing washer pipes to washer reservoir motors.
45. Remove washer reservoir pipes.
46. Release 2 bolts securing earth points to body.
47. Pull harness into engine bay.
48. Disconnect multiplug from bonnet switch.
49. Disconnect 3 multiplugs from ABS modulator and multiplug from ABS sensor.
50. Release LH indicator repeater lamp.
51. Disconnect multiplug from repeater lamp.
52. Remove repeater lamp.
53. Attach draw string to repeater lamp harness.
54. Pull harness into engine bay, remove draw string and secure.
55. Disconnect multiplug from fuel cut-off switch.
56. Remove plenum molding.
57. Disconnect and release 2 multiplugs from front heated screen element.
58. Pull harness into engine bay.
59. Remove clip securing washer pipes to bonnet.
60. Disconnect pipe from bonnet.
61. Disconnect 11 multiplugs from ECU pack.
62. Remove 2 nuts securing earth headers to LH lower 'A' post.
63. Disconnect 4 multiplugs from body harness.
64. Remove clip securing washer pipe located at lower 'A' post
65. Remove pipe.
66. Disconnect 2 multiplugs from front door harness.
67. With assistance withdraw LH side harness into interior.
68. Disconnect ignition harness multiplug from passenger compartment fusebox.
69. Remove nut securing passenger compartment fusebox to steering support bracket.
70. Release fusebox and disconnect 8 multiplugs.
71. Remove fusebox.
72. Disconnect 7 multiplugs from ignition passive coil and steering column switch assembly.
73. Release 3 multiplugs from steering column support.
74. Disconnect multiplugs from brake and clutch pedal.
75. Disconnect multiplug from RH side body harness.
76. Disconnect 2 multiplugs from RH door harness.
77. Disconnect multiplugs from cruise control ECU, remove nut securing earth header to body and remove earth header.
78. Disconnect 2 multiplugs from ECM.
79. Remove 6 nuts and bolts securing wiper mechanism, release mechanism and disconnect multiplug.
80. With assistance withdraw RH side harness into interior.
81. Release RH side front carpet.
82. Remove nut securing earth header to footwell.
83. Remove earth header.
84. Remove clip securing harness to pedal box.
85. Remove 2 nuts securing harness to tunnel.
86. Disconnect Lucar from handbrake switch.
87. Disconnect multiplug from DCU.
88. Remove rear carpet. Refer to «REMOVE»(ref-207935-S42132041262005120400000) .
89. Disconnect 3 multiplugs from RH rear door harness.
90. Remove 2 nuts securing 2 earth headers to rear center console tunnel.
91. Remove earth headers from center console.
92. Disconnect multiplug from CD player.
93. Remove 5 clips and 2 retainers securing harness to floor.
94. Disconnect 3 multiplugs from LH rear door harness.
95. Withdraw harness to interior.
96. Maneuver harness over steering column support bracket.
97. With assistance remove main harness.

1. With assistance position main harness to body and maneuver over steering column support bracket.
2. Lay harness in position and secure to floor clips and retainers.
3. Connect LH and RH rear door multiplugs.
4. Connect CD player multiplug.
5. Position center console earth headers and secure with nuts.
6. Fit rear carpet. Refer to «REFIT»(ref-207935-S18186345842005120400000) .
7. Connect DCU multiplug.
8. Connect Lucar to handbrake switch.
9. Fit and tighten nuts securing harness to transmission tunnel.
10. Secure harness to pedal box.
11. Position footwell earth header and secure with nut.
12. Feed RH side of harness into engine bay.
13. Position carpet.
14. Connect wiper motor multiplug, position mechanism and secure with nuts and bolts.
15. Connect ECM multiplug.
16. Position RH lower 'A' post earth header and secure with nut, connect cruise control multiplug.
17. Connect RH front door and RH side body harness multiplugs.
18. Secure multiplugs to steering column support bracket and connect brake and clutch pedal multiplugs.
19. Connect multiplugs to column switch and passive coil.
20. Position passenger compartment fusebox, connect multiplugs, fit fusebox to fascia and secure with nut.
21. Connect ignition switch multiplug to fuse box.
22. With assistance feed LH side of harness into engine bay.
23. Connect multiplugs to front door harness and body harness.
24. Position earth headers to LH lower 'A' post and secure with nuts.
25. Connect multiplugs to ECU pack.
26. Position harness in engine bay.
27. Connect and secure heated front screen multiplugs.
28. Fit plenum molding.
29. Connect multiplugs to ABS sensor and fuel cut-off switch.
30. Using draw string feed harness through inner wing, remove draw string, connect repeater lamp multiplug and fit lamp.
31. Connect multiplugs to ABS modulator.
32. Feed harness through to front panel.
33. Position body earth leads and secure with bolts.
34. Connect washer reservoir multiplugs and pipes, secure pipes with clips.
35. Secure fog lamp multiplug.
36. Secure earth header behind headlamp.
37. Connect multiplugs to headlamp level motor, headlamp and side lamp.
38. Fit indicator lamp
39. Connect multiplug to LH horn.
40. Feed harness to ACE accelerometer, connect multiplug and secure with cable ties.
41. Connect cruise control, ABS sensor and brake fluid level switch multiplugs.
42. Connect engine harness multiplug and feed harness along RH wing to fuse box.
43. Using draw string pull harness through inner wing, remove draw string, connect repeater lamp multiplug and fit lamp.
44. Connect chassis harness multiplugs.
45. Position engine bay fuse box and connect multiplugs, fit fuse box and secure with screws.
46. Connect multiplugs to front of fuse box.
47. Position battery and starter cables and secure with screws.
48. Fit fuse box cover.
49. Position earth lead and secure with nut.
50. Feed harness through to front panel.
51. Secure fog lamp multiplug.
52. Connect headlamp level motor, headlamp and side lamp multiplugs.
53. Fit indicator lamp.
54. Secure harness to RH front panel.
55. Connect cooling fan and horn multiplug.
56. Secure harness to lower support rail.
57. Connect receiver drier and air temperature sensor multiplugs.
58. Fit front bumper. Refer to «REFIT»(ref-207934-S30296778672005120400000) .
59. Fit battery tray.
60. Fit air filter assembly.
61. Position both lower 'A' post trims and secure with studs.
62. Fit heater assembly. With air conditioning: refer to «80.20.01.98 HEATER ASSEMBLY -- MODELS WITH AIR CONDITIONING»(ref-207938-S08939157412005120400000) . Without air conditioning: refer to «80.20.01.99 HEATER ASSEMBLY -- MODELS WITHOUT AIR CONDITIONING»(ref-207938-S28805529652005120400000) .

Scheme 100

Scheme 101

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

Scheme 108

1. Remove battery cover and disconnect the battery earth lead.
2. Remove CD switch box. Refer to «REMOVE»(ref-208281-S21280945162005120500000) .
3. Remove DVD player unit. Refer to «REMOVE»(ref-208281-S05549575042005120500000) .
4. Release screw covers, remove 4 screws and remove front and rear grab handles from drivers side.
5. Carefully release 'A' post upper finisher from drivers side.
6. Disconnect tweeter multiplug and remove 'A' post finisher.
7. Collect finisher securing clips.
8. Remove 3 screws securing drivers side sun visor and release sun visor.
9. Disconnect multiplug and remove sun visor.
10. Remove 3 screws securing drivers side corner of stowage pocket to roof panel.
11. Release front door seal for access to drivers side 'A' post lower finisher.
12. Remove 2 fixings and remove 'A' post lower finisher from drivers side.
13. Release drivers side front and rear door aperture seals from upper flanges for access to 'B' post upper finisher.
14. Release upper finisher from 'B' post.
15. Release multiplug from DVD unit mounting bracket.
16. Release 2 harness retaining clamps on 'A' post.
17. Disconnect DVD main harness multiplug from vehicle fuse box link harness.
18. Remove DVD main harness from above headlining and from fascia.

1. Fit DVD main harness to fascia and above headlining.
2. Connect DVD main harness multiplug to vehicle fuse box link harness.
3. Secure harness behind clamps at 'A' post and multiplug to DVD unit mounting bracket.
4. Fit upper finisher to 'B' post.
5. Fit 'A' post lower finisher and secure with fixings.
6. Fit seals to front and rear door apertures.
7. Fit screws to secure stowage pocket.
8. Position sun visor and connect multiplug.
9. Fit sun visor and secure with screws.
10. Fit finisher securing clips to 'A' post.
11. Position 'A' post upper finisher and connect tweeter multiplug.
12. Fit 'A' post upper finisher.
13. Fit grab handles, tighten screws and fit screw covers.
14. Fit DVD player unit. Refer to «REFIT»(ref-208281-S21249912952005120500000) .
15. Fit CD switch box. Refer to «REFIT»(ref-208281-S03936855302005120500000) .
16. Connect battery earth lead, fit and secure battery cover.

Scheme 109

Scheme 110

Scheme 111

Scheme 112

1. Remove battery cover and disconnect the battery earth lead.
2. Remove center console. Refer to «REMOVE»(ref-207935-S41671062802005120400000) .
3. Remove 3 fasteners and release drivers side lower closing panel.
4. Release diagnostic socket and remove closing panel.
5. Rotate turnbuckles and lower fuse box access panel.
6. Disconnect 2 CD switch box link harness multiplugs from vehicle main harness.
7. Disconnect link harness multiplug from CD switch box.
8. Remove 3 cable ties securing CD switch box link harness to fascia support bracket and remove harness.

1. Fit CD switch box link harness and connect multiplugs to vehicle main harness.
2. Connect link harness multiplug to CD switch box.
3. Align CD switch box link harness to fascia support bracket and secure with cable ties.
4. Close and secure fuse box access panel.
5. Position fascia closing panel and fit diagnostic socket.
6. Fit closing panel and secure with fasteners.
7. Fit center console. Refer to «REFIT»(ref-207935-S01042334042005120400000) .
8. Connect battery earth lead, fit and secure battery cover.
