PASSENGER COMPARTMENT FUSE BOX
Note. Passenger compartment fuse box is located below and to the side of the steering column. Remove cover using a coin or small screwdriver and turning 90 degrees. (Scheme 1)
Scheme 1
Scheme 2
| Relay | System |
|---|---|
| 1 | LH Indicators |
| 2 | RH Indicators |
| 3 | Rear Window Lift |
| 4 | Ignition Coils - V8 only |
| 5 | Daylight Running Lamps - if fitted |
| 6 | Daylight Running Lamps - if fitted |
Passenger Compartment Fuse Relays
| Fuse | System | |
|---|---|---|
| 1 | 25A | Central door locking |
| 2 | 10A | Fuel flap release |
| 3 | 10A | LH headlight main beam |
| 4 | 10A | Rear fog guard lights |
| 5 | 15A | Daytime running lights (if fitted) |
| 6 | 25A | Rear air conditioning blower |
| 7 | 30A | Heater blower front |
| 8 | 30A | Heated rear window, heated mirrors |
| 9 | 10A | LH headlight dipped beam |
| 10 | 10A | RH headlight dipped beam |
| 11 | 10A | LH side & tail lights, number plate light, interior illumination |
| 12 | 30A | Sunroof |
| 13 | 30A | Rear windows |
| 14 | 20A | Ignition coils |
| 15 | 20A | Cigar lighter, interior lights, seat heaters, vanity mirror illumination |
| 16 | 15A | Clock, radio |
| 17 | 15A | Radio amplifier, speakers |
| 18 | 15A | Rear wiper motor |
| 19 | 15A | Front wipers/washers |
| 20 | 15A | Interior lights, clock/radio memory, engine remobilization |
| 21 | 15A | Transfer box |
| 22 | 10A | RH headlight main beam |
| 23 | 10A | Starter motor |
| 24 | 10A | Alternator, auto transmission |
| 25 | 25A | Brake, reverse lights |
| 26 | 10A | Auxiliary circuits |
| 27 | 10A | Instruments, hill descent control |
| 28 | 10A | Self leveling suspension, anti-lock braking |
| 29 | 10A | Active cornering enhancement (ACE) |
| 30 | 20A | Cruise control, electric mirrors, rear washer |
| 31 | 10A | Air conditioning blower |
| 32 | 25A | Accessory socket |
| 33 | 10A | RH side & tail lights, radio, trailer socket, interior illumination |
| 34 | 30A | Front windows |
| 35 | 10A | Airbag SRS - DO NOT REMOVE |
Passenger Compartment Fuse Box Fuses
ENGINE COMPARTMENT FUSE BOX
Note. Engine compartment fuse box is located on passenger's side of engine compartment, next to coolant reservoir. (Scheme 3)
Scheme 3
Scheme 4
| Relay | System |
|---|---|
| 1 | Fuel Pump |
| 2 | Starter |
| 3 | Headlamp Powerwash |
| 4 | Cooling Fan |
| 5 | Self Leveling/ABS (SLABS) |
| 6 | Glowplugs - Diesel |
| 7 | Auxiliary circuits |
| 8 | Heated Front Seats |
| 9 | Main Relay |
| 10 | Anti-Lock Braking System (ABS) |
| 11 | A/C Compressor Clutch |
| 12 | Front Fog Lights |
| 13 | Horns |
| 14 | Active Conering Enhancement (ACE) |
Engine Compartment Fuse Relays
| Fuse | System | |
|---|---|---|
| 1 | 30A | Injectors |
| 2 | 15A | Engine management system |
| 3 | 15A | Front fog lights |
| 4 | 20A | Headlight washers |
| 5 | 40A | Cooling fans |
| 6 | 10A | Air conditioning |
| 7 | 40A | Heated front screen (LH) |
| 8 | 40A | Heated front screen (RH) |
| 9 | 25A | Trailer lights |
| 10 | 30A | Fuel pump |
| 11 | 30A | ABS valve |
| 12 | 20A | Automatic gearbox |
| 13 | 10A | Body Control Unit (BCU) |
| 14 | 15A | Direction indicators, hazard lights |
| 15 | 15A | Active cornering enhancement (ACE) |
| 16 | 10A | Horn |
Engine Compartment Fuse Box Fuses
UNDER SEAT FUSE BOXES
Note. Two identical small fuse boxes are located beneath each front seat. (Scheme 5)
Scheme 5
| Fuse | System | |
|---|---|---|
| 1 | 40A | Seat electrics |
| 2 | 3A | Lumbar support - pump |
| 3 | 3A | Lumbar support - solenoid |
| 4 | Empty | |
Under Seat Fuses
