SPECIFICATIONS
| Application | Specification | |
|---|---|---|
| Compressor Type | Nippondenso 10PA17 10-Cyl. | |
| Compressor Belt Tension | (1) | |
| System Oil Capacity | (2) 6.3 ozs. | |
| Refrigerant (R-134a) Capacity | ||
| Without Rear A/C | 23.8-25.5 ozs. | |
| With Rear A/C | 30.9-32.6 ozs. | |
| System Operating Pressure (3) | ||
| High Side | 377.1-464.1 psi (26.5-32.6 kg/cm 2 ) | |
| Low Side | 29.0-33.4 psi (2.0- 2.3 kg/cm 2 ) | |
| (1) Belt tension is maintained by an automatic belt tensioner. (2) Use Nippondenso ND-OIL 8 refrigerant oil. (3) At 77-84°F (25-29°C) and engine speed at 1500 RPM for 10 minutes with A/C operating. | ||
| (1) | Belt tension is maintained by an automatic belt tensioner. |
| (2) | Use Nippondenso ND-OIL 8 refrigerant oil. |
| (3) | At 77-84°F (25-29°C) and engine speed at 1500 RPM for 10 minutes with A/C operating. |
SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|---|
| Blower Motor Mounting Bolts | 14 (19) |
| Compressor-To-Mounting Bracket Bolts | 18 (25) |
| Rear Evaporator Assembly-To-Body Bolts | 12 (16) |
| Evaporator Pipe-To-Thermostatic Expansion Valve | 24 (32) |
| Instrument Panel-To-Body | 19 (26) |
| Heater Assembly | 12 (16) |
| Rear Seat Support Bracket Bolts | 18 (25) |
| Thermostatic Expansion Valve Pressure Pipe Union | 16 (22) |
| INCH Lbs. | |
| A/C Pipes-To-Compressor Bolts | 89 (10) |
| A/C Pipes-To-Receiver Drier Bolts | 44 (5) |
| Adaptor Block-To-Receiver Drier Bolt | 44 (5) |
| Condenser Pipe Bolt | 44 (5) |
| Dual Pressure Switch-To-Receiver Drier | 89 (10) |
| Evaporator Pipe Bolts | 44 (5) |
| High/Low Pressure Pipes Bolts | 89 (10) |
| Instrument Panel-To-Steering Column Bracket | 96 (11) |
| Receiver-Drier-To-Bracket Bolts | 44 (5) |
TORQUE SPECIFICATIONS
