INTRODUCTION
Use this article to quickly find specifications related to servicing and on-vehicle adjustments. This is a quick-reference article to use when you are familiar with an adjustment procedure and only need a specification.
ENGINE IDENTIFICATION CODE
Specifications are determined by specific compression ratios which are stamped on the engine blocks. (Scheme 1)
Scheme 1
CAPACITIES
| Application | Quantity |
|---|---|
| Auto. Transmission (Dexron-IID ATF) | 9.6 Qts. (9.1 L) |
| Crankcase (Includes Filter) (1) | 7 Qts. (6.6 L) |
| Cooling System (Includes Heater) (50/50 Mixture Of Ethylene Glycol Antifreeze & Water) | 12 Qts. (11.4 L) |
| Differential (2) (3) | 3.6 Pts. (3.4 L) |
| Man. Transmission (Dexron-IID ATF) | 5.7 Pts. (5.4 L) |
| Transfer Case (3) | 4.9 Pts. (4.6 L) |
| Power Steering (4) | 7.2 Pts. (6.8 L) |
| Front Axle Swivel Pin Housing (5) | 0.75 Pts. (0.71 L) |
| (1) API Service Level SGMSH SAE 10W-40, 10W-50 (2) Both front and rear. (3) API GL4 Or GL5 MIL-L-2105 Or ML-l-2105B, 90 EP, 80W EP (4) Dexron-IID ATF (5) API GL5, MIL-L-2105 Or MIL-L-2105B, C Or D | |
| (1) | API Service Level SGMSH SAE 10W-40, 10W-50 |
| (2) | Both front and rear. |
| (3) | API GL4 Or GL5 MIL-L-2105 Or ML-l-2105B, 90 EP, 80W EP |
| (4) | Dexron-IID ATF |
| (5) | API GL5, MIL-L-2105 Or MIL-L-2105B, C Or D |
FLUID CAPACITIES
QUICK-SERVICE
| Component | Months | Miles | |
|---|---|---|---|
| Accessory Belt | 84 | 105,000 | |
| Air Filter | |||
| Normal Service | 24 | 30,000 | |
| Automatic Transmission Fluid & Filter | |||
| Normal Service | 24 | 30,000 | |
| Engine Oil & Filter | |||
| Normal Service | 6 | 7500 | |
| Evaporative Canister | 84 | 105,000 | |
| Fuel Filter | |||
| Normal Service | 48 | 60,000 | |
| Heated Oxygen Sensor | 66 | 82,500 | |
| Manual Transmission Fluid | |||
| Normal Service | 30 | 37,500 | |
| Spark Plugs | |||
| Normal Service | 24 | 30,000 | |
| Transfer Case Fluid (4WD) | |||
| Normal Service | 24 | 30,000 | |
REPLACEMENT INTERVALS
BELT ADJUSTMENT
This vehicle is equipped with a serpentine belt and automatic tensioner. No adjustments are required.
ENGINE COMPRESSION
Check engine compression with engine at normal operating temperature at specified cranking speed, all spark plugs removed and throttle wide open.
| Application (1) | (2) Specification |
|---|---|
| 8.13:1 Compression Engine | 150-160 psi (10.5-11.2 kg/cm 2 ) |
| 9.35:1 Compression Engine | 170-180 psi (12.0-12.7 kg/cm 2 ) |
| (1) See ENGINE IDENTIFICATION CODE under INTRODUCTION. (2) Maximum variation between cylinders is 10 percent. | |
| (1) | See ENGINE IDENTIFICATION CODE under INTRODUCTION. |
| (2) | Maximum variation between cylinders is 10 percent. |
ENGINE COMPRESSION SPECIFICATIONS
VALVE CLEARANCE
Note. This vehicle is equipped with hydraulic lifters. No adjustments are required.
SPARK PLUGS
Spark plug type is Champion RN11YCC with a 0.033-0.038" (0.84-0.96 mm) gap.
Scheme 2
Scheme 3
IGNITION TIMING
| Application | Specification | |
|---|---|---|
| 8.13:1 Compression Engine | 1-3 @ 800 Max | |
| 9.35:1 Compression Engine | ||
| With Catalyst | 4-6 @ 800 Max | |
| Without Catalyst | 3-5 @ 800 Max | |
IGNITION TIMING (Degrees BTDC @ RPM)
| Application (1) | (2) (3) Specification | ||
|---|---|---|---|
| 8.13:1 Compression Engine | |||
| @ 800 RPM | 2 To 4 Degrees BTDC | ||
| @ 1400 RPM | 6 Degrees & 18 Minutes To 8 Degrees & 30 Minutes BTDC | ||
| @ 2000 RPM | 5 Degrees & 30 Minutes To 8 Degrees & 30 Minutes BTDC | ||
| 9.35:1 Compression Engine | |||
| With Catalyst | |||
| @ 800 RPM | 2 To 4 Degrees BTDC | ||
| @ 1400 RPM | 6 Degrees & 18 Minutes To 8 Degrees & 30 Minutes BTDC | ||
| @ 2200 RPM | 5 Degrees & 30 Minutes To 8 Degrees & 30 Minutes BTDC | ||
| Without Catalyst | |||
| @ 650 RPM | 1 To 3 Degrees BTDC | ||
| @ 1400 RPM | 7 Degrees & 48 Minutes To 10 Degrees BTDC | ||
| @ 2200 RPM | 7 To 8 Degrees BTDC | ||
| (1) See ENGINE IDENTIFICATION CODE under INTRODUCTION. (2) Check ignition timing advance with engine decelerating and vacuum advance disconnected. (3) Manufacturer breaks up the degree specification into minutes for more accurate calculations. 60 minutes is equal to one degree. | |||
| (1) | See ENGINE IDENTIFICATION CODE under INTRODUCTION. |
| (2) | Check ignition timing advance with engine decelerating and vacuum advance disconnected. |
| (3) | Manufacturer breaks up the degree specification into minutes for more accurate calculations. 60 minutes is equal to one degree. |
IGNITION TIMING ADVANCE
DISTRIBUTOR PICK UP AIR GAP
Air gap of the distributor pick up should be 0.008-0.014" (0.20-0.35 mm).
Regulated Fuel Pressure
Regulated fuel pressure should be 35-37 psi (2.4-2.6 kg/cm 2 ). Pressure will vary depending on amount of intake manifold vacuum acting on fuel pressure regulator.
IDLE SPEED
Note. Before setting idle speed, ensure MIL is not on, no DTCs are stored, ignition timing is correct, spark plugs and air cleaner are okay and PCV system is operating properly.
| Application | RPM | ||
|---|---|---|---|
| Base Idle Speed | 500-550 | ||
| Curb Idle Speed | |||
| A/T | |||
| In Neutral, No Load | 665-735 | ||
| In Gear, A/C Off | 572-628 | ||
| In Gear, A/C On | 622-678 | ||
| M/T | |||
| A/C Off | 672-728 | ||
| A/C On | 722-778 | ||
IDLE SPEED SPECIFICATIONS
MIXTURE
CO level for this vehicle at idle should be 0.5-1.0%.
THROTTLE POSITION SENSOR
Note. Throttle Position (TP) sensor is not adjustable. For testing procedures, see SELF-DIAGNOSTICS or SYSTEM & COMPONENT TESTING article. Throttle Position (TP) sensor operating range is 0.8-5 volts. If TP sensor should fail, Engine Control Module (ECM) will default to a value of 5.76 volts and set the Malfunction Indicator Light (MIL).
