Wiring diagram: Body control modules — Integrated control unit circuit Kia Stinger I
All systems
- Air conditioning
- Anti-lock brakes 2
- Anti-theft 2
- Body control modules 2
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers
- Electronic power steering 2
- Electronic suspension
- Engine performance 2.0l turbo 2
- Engine performance 3.3l turbo 2
- Exterior lights 2
- Ground distribution
- Headlights 4
- Horn
- Instrument cluster 2
- Interior lights 2
- Memory systems 3
- Navigation 8
- Power distribution
- Power door locks
- Power mirrors 3
- Power seats 6
- Power top/sunroof
- Power windows
- Radio 3
- Shift interlock
- Starting/charging 2
- Supplemental restraints
- Transmission 3
- Trunk, tailgate, fuel door 2
- Warning systems 2
- Wiper/washer
Integrated control unit circuit (1 of 2) — Body control modules Kia Stinger I
Components on the diagram
Integrated control unit circuit (2 of 2) — Body control modules Kia Stinger I
Components on the diagram
Components on these wiring diagrams
Click a component to highlight it on every diagram it appears on.
