Specifications
| Items | Specifications | |
|---|---|---|
| Rated voltage | DC 12V | |
| Operating temperature range | 22 ~ +176°F (-30°C ~ +80°C) | |
| Rated load | Dimmer & passing switch | High: 0.2A (Relay load) Low: 0.2A (Relay load) Passing: 0.2A (Relay load) |
| Lighting switch | Lighting: 0.2A (Relay load) | |
| Turn signal switch | 6.6 ± 0.5A (Lamp load) | |
| Wiper & mist switch | Low, High: 4.5A (Motor load) Intermittent: 0.22 ± 0.05A (Relay load) Lock: Max. 28A (Motor load) Washer: 4.0A (Motor load) | |
| Front fog lamp switch | 0.2A (Relay load) | |
| Rear wiper & washer | Wiper: 1.0A (Relay load) Washer: 4.0A (Motor load) | |
ITEM SPECIFICATION CHART
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
- Disconnect the negative (-) battery terminal.
- Remove the steering column upper and lower shrouds (A) after removing 3 screws. NOTE: Take care not to damage and scratch the shrouds and its related parts. Take care not to damage the hook when removing the upper and lower shrouds.
- Disconnect the light switch connector (A) and the wiper switch connector (B).
- Remove the wiper switch (A) by pushing the lock pin (B). NOTE: When removing the wiper & washer switch only, release the lock of wiper switch without removing the steering wheel.
- Remove the steering wheel. Refer to " «STEERING COLUMN AND SHAFT»(ref-584458-S25237596492013110400000) ".
- Remove the clock spring. Refer to " «AIRBAG MODULE»(ref-584477) ".
- Loosen the 2 screws from the multifunction switch assembly (A).
