Key Reminder Unlock Function Kia Sportage III

Body Control Module (BCM) 2 illustrations

Key Reminder Unlock Function

This function is making unlock status when user forget the key inside the vehicle and lock the door.

Scheme 68

Scheme 68

Scheme 68

T1: Key refirst unlock time

Scheme 69

Scheme 69

Scheme 69

T1: Key refirst unlock time, T2: 0.5 sec

Name	Value
Key ReFirst Unlock Time	1 sec ± 0.1 sec
Key ReUnlock Time	500 msec ± 50 msec

VALUE SPECIFICATION CHART
