Air Conditioning Controller: Other — Kia Sportage III (2010-2014)

Air Conditioning Controller: Other Kia Sportage III

Connector Pin Function

Connector	Pin No	Function	Connector	Pin No	Function
Connector (A)	1	High	Connector (B)	1	Tail Lamp (ILL+)
	2	Middle High		2	Battery
	3	Middle Low		3	Mode Actuator (VENT)
	4			4	Mode Actuator (DEF)
	5	GND		5	Temp Actuator (COOL)
	6	Low		6	Temp Actuator (WARM)
				7	Intake Actuator (FRE)
				8	Intake Actuator (REC)
				9
				10	Detent
				11	Mode Actuator (F/B)
				12	Temp Actuator (F/B)
				13	Intake Actuator (F/B)
				14	Blower Motor Common (-)
				15	Blower F/B
				16	Rheostat (ILL-)
				17	IG2
				18	IG1
				19	Can (HIGH)
				20	Can (LOW)
				21	HTD (Rear DEF IND.)
				22	ECV IN
				23	ECV OUT
				24
				25	Vref (+5V)
				26	Evaporator Sensor
				27	Ambient Sensor
				28
				29
				30
				31	Sensor GND
				32	GND

CONNECTOR PIN REFERENCE CHART

Scheme 84

Scheme 84: Replacement

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Disconnect the negative (-) battery terminal.
Using the screwdriver, remove the cluster fascia panel (A).
Using the screwdriver, remove the crash pad garnish (A).
Using the screwdriver, remove the screws and center fascia panel (A).
Disconnect the center fascia connectors (A).
Loosen the control panel mounting screws and then remove the control panel (A).
Disconnect the connectors and then remove the control panel (B).
Installation is the reverse order of removal.

Scheme 90

Scheme 90: Component

Connector	Pin NO	Function	Connector	Pin NO	Function
Connector (A)	1	Battery	Connector (B)	1	CAN (LOW)
	2	Tail Lamp (ILL+)		2	CAN (HIGH)
	3	IG2		3	Intake Actuator (F/B)
	4	DR Temp Actuator (COOL)		4	Mode Actuator (F/B)
	5	DR Temp Actuator (WARM)		5	PS Temp Actuator (F/B)
	6	Detent		6	DR Temp Actuator (F/B)
	7	Mode Actuator (VENT)		7	Diagnosis (Cluster Ion)
	8	Mode Actuator (DEF)		8	V Ref (+5V)
	9			9
	10			10
	11			11	ECV IN
	12	Rheostat (ILL-)		12	GND
	13	GND		13	HI- Scan (L-line)
	14	IG1		14	Evaporator Sensor
	15	Ion Signal		15	Ambient Sensor
	16	Intake Actuator (FRE)		16
	17	Intake Actuator (REC)		17	LH Photo (-)
	18	Clean Signal		18	RH Photo (-)
	19	Blower Motor (+)		19
	20	PS Temp Actuator (COOL)		20
	21	PS Temp Actuator (WARM)		21
	22	Power Mosfet (GATE)		22	ECV Out
	23	Power Mosfet (DRAIN)
	24	HTD (Rear Def Ind.)
	25	Rear Def S/W (Low)
	26	Sensor GND

CONNECTOR PIN REFERENCE CHART

Scheme 91

Scheme 91: Self Diagnosis

Scheme 92

Scheme 93

Scheme 94

Self-diagnosis process
How to read self-diagnostic code After the display panel flickers three times every 0.5 second, the corresponding fault code flickers on the setup temperature display panel every 0.5 second and will show two figures. Codes are displayed in numerical format FAULT CODE CHART Display Fail description 00 Normal 11 In-car sensor open 12 In-car sensor short 13 Ambient sensor open 14 Ambient sensor short 17 Evaporator sensor open 18 Evaporator sensor short 19 Temp door potentiometer open/short- Drive 20 Temp door potentiometer fault- Drive 21 Mode door potentiometer open/short 22 Mode door potentiometer fault 25 Intake door potentiometer open 26 Intake door potentiometer short 32 Temp door potentiometer open/short - Passenger 33 Temp door potentiometer fault - Passenger 45 APT CAN signal fault 46 - 47 RPM CAN signal fault 48 Vehicle speed CAN signal fault 49 Engine coolant temp CAN signal fault 50 Cluster ion generator fault
Fault code display Continuance operation: DTC code is one. Continuance operation: DTC code of two or more. STEP operation Normal or one fault code is same as a continuance operation. DTC code is two or more. If fault codes are displayed during the check, Inspect specific malfunctions causes by fault codes. Fail safe In-car temperature sensor: Control with the value of 23°C (73.4°F) Ambient temperature sensor: Control with the value of 20°C (67°F) Evaporator temperature sensor: Control with the value of -2°C (28.4°F) Water temperature sensor: Control with the value of 85°C (185°F) Temperature control actuator (Air mix potentiometer): If temperature setting 17°C-24.5°C, fix at maximum cooling position. If temperature setting 25°C-32°C, fix at maximum heating position. Mode control actuator (Direction potentiometer): Fix vent position, while selecting vent mode. Fix defrost position, while selecting all except vent mode. Intake control actuator: Fix fresh position, while selecting fresh mode. Fix recirculation position, while selecting recirculation mode.
