SPECIFICATIONS
| Items | Specifications |
|---|---|
| Rated voltage | 12V |
| Load | Max. 200mA (Relay load) |
| Detection illuminations Tail lamp / Head lamp | ON: 24 +/- 5.2 (Lux), 0.81 +/-0.05 (V) OFF: 48 +/-10.5 (Lux), 1.41 +/-0.05 (V) |
SPECIFICATIONS
Scheme 1
Scheme 2
- Remove the photo & auto light sensor (A) after removing the defroster center cover.
- Disconnect the 8P connector from the auto light sensor then inspect the connector on the wire harness side, as shown in the chart. TESTER CONNECTION AND SPECIFIED CONDITION Tester connection Condition Specified condition 1-Ground Auto light switch ON Continuity 2-Ground Constant Continuity 3-Ground Ignition switch ON 12V 4-Ground Constant 5V Tail lamp switch ON 0V 6-Ground Ignition switch ON 12V Head lamp switch ON 0V
- If the circuit is not as specified, inspect the circuits connected to other parts.
