SPECIFICATIONS
| Items | Specifications |
|---|---|
| Rated voltage | DC 12 V |
| Operating temperature range | 30°C ~ +80°C (-22 ~ +176°F) |
| Rated load | |
| Dimmer & passing switch | High: 15A (Relay load) |
| Low: 10A (Relay load) | |
| Passing: 15A (Relay load) | |
| Lighting switch | Lighting: 1A (Relay load) |
| Turn signal & lane change switch | 6.6+/-0.5A (Lamp load) |
| Front fog lamp switch | 1A (Relay load) |
| Wiper & mist switch | Low, High: 4A (Motor load) |
| Intermittent: 0.22+/-0.05A (Relay load) | |
| Lock: Max. 23A (Motor load) | |
| Mist: 4A (Motor load) | |
| Washer switch | 4A (Motor load) |
| Variable intermittent volume switch | Max. 25mA |
| Rear wiper & washer switch | Rear wiper: 200mA (Relay load) |
| Rear washer: 4A (Motor load) |
MULTI FUNCTION SWITCH SPECIFICATIONS
Scheme 1
Scheme 2
Scheme 3
Scheme 4
- Remove the steering column upper and lower shrouds (A) after removing 3 screws.
- Remove the light switch (B) after loosening its 2 screws and connector (A).
- Remove the wiper switch (B) after loosening its 2 screws and connector (A).
- Installation is the reverse of removal.
