OIL SPECIFICATION
- The HFC-134a system requires a synthetic (PAG) compressor oil whereas the R-12 system requires mineral compressor oil. The two oils must never be mixed.
- Compressor (PAG) oil varies according to compressor model. Be sure to use oil specified for the model of compressor.
SPECIFICATION
| Evaporator core temperature [°C(°F)] | Resistance [kohms] |
|---|---|
| 10(14) | 13.6 |
| 0(32) | 8.0 |
| 10(50) | 4.9 |
| 15(59) | 3.9 |
| 30(86) | 2.0 |
| 40(104) | 1.3 |
| 50(122) | 0.9 |
EVAPORATOR TEMPERATURE SENSOR SPECIFICATIONS
Scheme 1
Scheme 2
- In-car air temperature sensor is located at the lower crush pad.
- The sensor contains a thermistor which measures the temperature of the inside. The signal, decided by the resistance value which changes in accordance with perceived inside temperature, is delivered to heater control unit and according to this signal the control unit regulates in car temperature to intended value.
Scheme 3
- Ignition "OFF"
- Disconnect in-car temperature sensor.
- Using the multi-tester, Measure resistance between terminal "2" and "4" of in-car sensor.
| Temperature [°C(°F)] | Resistance between terminals 2 and 4 (kohms) |
|---|---|
| 0 (32) | 97.83 +/- 2.61% |
| 15 (59) | 47.12 +/- 1.45% |
| 25 (77) | 30.00 +/- 1.20% |
| 35 (95) | 19.60 +/- 1.44% |
| 50 (122) | 10.82 +/- 2.26% |
IN-CAR TEMPERATURE SENSOR SPECIFICATION
Scheme 4
- Disconnect the negative (-) battery terminal.
- Remove the lower crush panel (A) .
- Disconnect the connector of in-car sensor.
- Loosen the mounting screws (B) and then remove the in-car sensor (C).
Scheme 5
| Relative humidity(%) | Frequency(Hz) | Relative humidity(%) | Frequency(Hz) |
|---|---|---|---|
| 10 | 7,224 | 55 | 6,664 |
| 15 | 7,162 | 60 | 6,600 |
| 20 | 7,100 | 65 | 6,534 |
| 25 | 7,038 | 70 | 6,468 |
| 30 | 6,976 | 75 | 6,399 |
| 35 | 6,915 | 80 | 6,330 |
| 40 | 6,853 | 85 | 6,258 |
| 45 | 6,791 | 90 | 6,186 |
| 50 | 6,728 | 95 | 6,110 |
HUMIDITY SPECIFICATION
Scheme 6
- Connect scantool to data link connector(DLC).
- Engine "ON"
- Monitor the "Humidity Sensor" Parameter on the Scantool while drying the humidity sensor with a hair drier or heat gun adjusted to a low heat setting.
- Are the DTC B1200 present and is parameter of "Humidity Sensor" fixed? NOTE: Parameter of "Humidity Sensor" will be fixed at 10%, if there is any fault in Humidity Sensor. YES Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-235431-S23500211042006062100000) " procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-235431-S10985697542006062100000) " procedure.
Refer to DTC B1200
Scheme 7
- Connect scantool to Data Link Connector(DLC).
- Engine "ON"
- Monitor the "Humidity Sensor" Parameter on the Scantool while drying the humidity sensor with the implement such as hair drier.
- Are the DTC B1201 present and is parameter of "Humidity Sensor" fixed? NOTE: Parameter of "Humidity Sensor" will be fixed at 10%, if there is any fault in Humidity Sensor. YES Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-235431-S26825563012006062100000) " procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-235431-S26292702852006062100000) " procedure.
| Temperature[°C(°F)] | Resistance(kohms) | Temperature[°C(°F)] | Resistance(kohms) |
|---|---|---|---|
| 30(-22) | 176.3 | 25(77) | 10 |
| 15(5) | 73.6 | 35(95) | 6.5 |
| 0(32) | 32.9 | 60(140) | 2.5 |
| 15(59) | 15.8 | 80(176) | 1.2 |
TEMPERATURE SPECIFICATION
Scheme 8
- Connect scantool to data link connector(DLC).
- Engine "ON"
- Monitor the "WATER TEMP. SENSOR" Parameter on the Scan tool
- Are the DTC B1202 present and is parameter of "WATER TEMP. SENSOR" fixed? NOTE: Parameter of "WATER TEMP. SENSOR" will be fixed at 20°C, if there is any fault in WATER TEMP. SENSOR. YES Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-235431-S15320854442006062100000) " procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-235431-S20783686522006062100000) " procedure.
Refer to DTC B1202 .
Scheme 9
- Connect scantool to data link connector(DLC).
- Engine "ON"
- Monitor the "WATER TEMP. SENSOR" Parameter on the Scantool.
- Are the DTC B1203 present and is parameter of "WATER TEMP. SENSOR" fixed? NOTE: Parameter of "WATER TEMP. SENSOR" will be fixed at 20°C, if there is any fault in WATER TEMP. SENSOR. YES Go to " «INSPECTION»(ref-235431-S31316968222006062100000) " procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-235431-S22318746942006062100000) " procedure.
| Temperature[°C(°F)] | Resistance(kohms) | Temperature[°C(°F)] | Resistance(kohms) |
|---|---|---|---|
| 30(-22) | 528.2 | 25(77) | 30 |
| 15(5) | 218.2 | 35(95) | 19.6 |
| 0(32) | 97.83 | 60(140) | 7.478 |
| 15(59) | 47.12 | 80(176) | 3.225 |
TEMPERATURE SPECIFICATION
Scheme 10
- Connect scantool to data link connector(DLC).
- Engine "ON"
- Monitor the "in car TEMP. SENSOR" Parameter on the Scantool.
- Are the DTC B1233 present and is parameter of "in car TEMP. SENSOR" fixed? NOTE: Parameter of "in car TEMP. SENSOR" will be fixed at 23°C(73°F), if there is any fault in in car TEMP. SENSOR. YES Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-235431-S06293777052006062100000) " procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-235431-S17169455822006062100000) " procedure.
Refer to DTC B1233 .
Scheme 11
- Connect scantool to data link connector(DLC).
- Engine "ON"
- Monitor the "in car TEMP. SENSOR" Parameter on the Scantool.
- Are the DTC B1234 present and is parameter of "in car TEMP. SENSOR" fixed? NOTE: Parameter of "in car TEMP. SENSOR" will be fixed at 23°C(73°F), if there is any fault in in car TEMP. SENSOR. YES Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-235431-S21708121072006062100000) " procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-235431-S07239629862006062100000) " procedure.
| Temperature[°C(°F)] | Resistance(kohms) | Temperature[°C(°F)] | Resistance(kohms) |
|---|---|---|---|
| 30(-22) | 507 | 25(77) | 30 |
| 15(5) | 215.3 | 35(95) | 24.2 |
| 0(32) | 97.5 | 60(140) | 16 |
| 15(59) | 59.6 | 80(176) | 10.8 |
TEMPERATURE SPECIFICATION
Scheme 12
- Connect scantool to Data Link Connector(DLC).
- Engine "ON"
- Monitor the "AMBIENT TEMP. SENSOR" Parameter on the Scantool.
- Are the DTC B1237 present and is parameter of "AMBIENT TEMP. SENSOR" fixed? YES Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-235431-S36095859322006062100000) " procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-235431-S33985930342006062100000) " procedure.
Refer to DTC B1237 .
Scheme 13
- Connect scantool to Data Link Connector(DLC).
- Engine "ON"
- Monitor the "AMBIENT TEMP. SENSOR" Parameter on the Scantool. NOTE: Parameter of "AMBIENT TEMP. SENSOR" will be fixed at 20°C(67°F), if there is any fault in AMBIENT TEMP. SENSOR.
- Are the DTC B1238 present and is parameter of "AMBIENT TEMP. SENSOR" fixed? YES Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-235431-S00130069292006062100000) " procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-235431-S38168522882006062100000) " procedure.
| Temperature[°C(°F)] | Resistance(kohms) | Temperature[°C(°F)] | Resistance(kohms) |
|---|---|---|---|
| 10(14) | 13.6 | 15(59) | 3.9 |
| 0(32) | 8 | 30(86) | 2 |
| 5(41) | 6.2 | 40(104) | 1.3 |
| 10(50) | 4.9 | 50(122) | 0.9 |
TEMPERATURE SPECIFICATION
Scheme 14
- Connect scantool to Data Link Connector(DLC).
- Engine "ON"
- Monitor the "EVAPORATIVE SENSOR" Parameter on the Scantool.
- Are the DTC B1241 present and is parameter of "EVAPORATIVE SENSOR" fixed? NOTE: Parameter of "EVAPORATIVE SENSOR" will be fixed at -2°C(28.4°F), if there is any fault in EVAPORATIVE SENSOR. YES Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-235431-S24243199922006062100000) " procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-235431-S03726557822006062100000) " procedure.
Refer to DTC B1241 .
Scheme 15
- Connect scantool to Data Link Connector(DLC).
- Engine "ON"
- Monitor the "EVAPORATIVE SENSOR" Parameter on the Scantool.
- Are the DTC B1242 present and is parameter of "EVAPORATIVE SENSOR" fixed? NOTE: Parameter of "EVAPORATIVE SENSOR" will be fixed at -2°C(28.4°F), if there is any fault in EVAPORATIVE SENSOR. YES Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-235431-S26887362902006062100000) " procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-235431-S35079868502006062100000) " procedure.
Refer to DTC B1245 .
Scheme 16
- Connect scantool to Data Link Connector(DLC).
- Engine "ON"
- Monitor the "Driver Air Mix Potentiometer" Parameter on the Scantool while operating temp. switch.
- Are the DTC B1246 present and is parameter of "Driver Air Mix potentiometer" fixed? NOTE: Parameter of "Driver Air Mix potentiometer" will be fixed at 100%(or any value above 90%), or 0% (or any value below 10%), if there is any fault in Driver Air Mix potentiometer. YES Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-235431-S33099749402006062100000) " procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-235431-S06917043352006062100000) " procedure.
Refer to DTC B1249 .
Scheme 17
- Connect scantool to Data Link Connector(DLC).
- Engine "ON"
- Monitor the "DR. DIRECTION POTENTIO." parameter on the scantool. While operating mode switch.
- Are the DTC B1250 present and is parameter of "DR. DIRECTION POTENTIO." fixed? NOTE: Parameter of "DR. DIRECTION POTENTIO." will be fixed at 100%(or any value above 90%), or 0% (or any value below 10%), if there is any fault in Driver Direction potentiometer. YES Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-235431-S27705259882006062100000) " procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-235431-S34306900292006062100000) " procedure.
Refer to DTC B1245 .
Scheme 18
- Connect scantool to Data Link Connector(DLC).
- Engine "ON"
- Monitor the "Driver Air Mix Potentiometer" Parameter on the Scantool. While operating temp, switch.
- Are the DTC B2406 present and is parameter of "Driver AIR MIX Potentiometer" fixed? NOTE: There is any fault in Driver AIR MIX Motor. If the parameter of "Driver AIR MIX DOOR" is 30% or less when the actuator operates to the hot position, or If the parameter is 60% and more when the actuator operates to the cold position. YES Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-235431-S26462937032006062100000) " procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-235431-S04455573762006062100000) " procedure.
Refer to DTC B1249 .
Scheme 19
- Connect scantool to Data Link Connector(DLC).
- Engine "ON"
- Monitor the "DR DIRECTION POTENTIO" parameter on the scantool while operating mode switch.
- Are the DTC B2409 present and is parameter of "Driver DIRECTION POTENTIO." fixed? NOTE: There is any fault in Driver Direction Motor. If the parameter of "Driver DIRECTION POTENTIO." is 10% or less on "VENT" mode, or If the parameter is 90% or more on "DEF" mode. YES Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-235431-S38530964772006062100000) " procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-235431-S18487586002006062100000) " procedure.
