Power Windows Kia Spectra II

Windows 18 illustrations ~319 words

Scheme 1

Scheme 1: TROUBLESHOOTING
Scheme 1: TROUBLESHOOTING

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3
  1. No windows operate from the main switch on the driver's door.
  2. Driver's side window does not operate.
  3. Passenger's side window does not operate.

Scheme 4

Scheme 4: COMPONENTS
Scheme 4: COMPONENTS

Scheme 5

Scheme 5: FRONT POWER WINDOW MOTOR INSPECTION
Scheme 5: FRONT POWER WINDOW MOTOR INSPECTION

Scheme 6

Scheme 6
Scheme 6
  1. Remove the front door trim panel. See «FRONT DOOR»(/kia/spectra/ii-2004-2008/remont/gauges-instrument-panels/#body-interiorexterior) .
  2. Disconnect the 2P connector from the motor.
  3. Connect the motor terminals directly to battery voltage (12V) and check that the motor operates smoothly. Next, reverse the polarity and check that the motor operates smoothly in the reverse direction. If the operation is abnormal, replace the motor.

Scheme 7

Scheme 7: REAR POWER WINDOW MOTOR INSPECTION
Scheme 7: REAR POWER WINDOW MOTOR INSPECTION

Scheme 8

Scheme 8
Scheme 8
  1. Remove the rear door trim panel. See «REAR DOOR»(/kia/spectra/ii-2004-2008/remont/gauges-instrument-panels/#body-interiorexterior) .
  2. Disconnect the 2P connector from the motor.
  3. Connect the motor terminals directly to battery voltage (12V) and check that the motor operates smoothly. Next, reverse the polarity and check that the motor operates smoothly in the reverse direction. If the operation is abnormal, replace the motor.

Scheme 9

Scheme 9: CIRCUIT DIAGRAM
Scheme 9: CIRCUIT DIAGRAM

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11: POWER WINDOW MAIN SWITCH
Scheme 11: POWER WINDOW MAIN SWITCH

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13
  1. Remove the front door trim panel. See «FRONT DOOR»(/kia/spectra/ii-2004-2008/remont/gauges-instrument-panels/#body-interiorexterior) .
  2. Remove the power window main switch (A) by pushing the mounting clip of the power window main switch.
  3. Check for continuity between the terminals. When the continuity does not agree, it exchanges the switch.

Scheme 14

Scheme 14: POWER WINDOW LOCK SWITCH
Scheme 14: POWER WINDOW LOCK SWITCH

Scheme 15

Scheme 15: POWER WINDOW SUB SWITCH
Scheme 15: POWER WINDOW SUB SWITCH

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17
  1. Remove the rear door trim panel. See «REAR DOOR»(/kia/spectra/ii-2004-2008/remont/gauges-instrument-panels/#body-interiorexterior) .
  2. Remove the power window sub switch (A) by pushing the fixation clip of the power window sub switch.
  3. Check for continuity between the terminals. When the continuity does not agree, it exchanges the switch.

POWER WINDOW RELAY INSPECTION

Check for continuity between the terminals.

Scheme 18

Scheme 18: POWER WINDOW RELAY INSPECTION
Scheme 18: POWER WINDOW RELAY INSPECTION
  1. There should be continuity between the No. 30 and No. 87 terminals when power and ground are connected to the No. 85 and No. 86 terminals.
  2. There should be no continuity between the No. 30 and No. 87 terminals when power is disconnected.
