1.8L 4 Cylinder Engine: Specifications Kia Spectra II

Mechanical 6 illustrations

ENGINE SPECIFICATIONS

ItemEngine modelT8 DOHC
TypeGasoline, 4 cycle
Cylinder arrangement and numberIn line, 4 cylinders
Combustion chamberPentroof
Valve systemOHC, belt driven (IN :2, EX : 2)
Displacement109.4 (1,793)
Bore and strokeCu in(cc)3.19X3.43 (81.0X87.0)
Compression ratioIn (mm)9.5:1
Compression pressure psi (kpa, kg/cm 2 )-rpm193 (1,333, 13.6)-300
Valve timingINOpenBTDC10°
CloseABDC42°
EXOpenBBDC50°
CloseATDC10°
Valve clearanceIN (mm)IN0: Maintenance-free
EX0 : Maintenance-free
Idle speedRpm800±50
Ignition timingBTDC5°±10°
Firing order1-3-4-2

Engine Specifications Chart

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
A/C Compressor Bracket Bolt
12-mm14-18 (19-25)
14-mm28-38 (38-51)
A/C Compressor Mounting Bolt29-38 (39-52)
Automatic Transaxle Linkage Nut24-34 (32-46)
Camshaft Timing Belt Pulley Bolt36-45 (49-61)
Connecting Rod Nut35-37 (47-50)
Crankshaft\Timing Belt Pulley Bolt116-123 (157-167)
Cylinder Head Bolts (1)
Step 136 (49)
Step 2Loosen Bolts In Sequence
Step 329 (39)
Step 4Plus Torque Angle 90 Degrees
Step 5Plus Torque Angle Additional 90 Degrees
Engine Ground Strap-To-Engine Bolts28-38 (38-52)
Engine Hanger Bolt28-38 (38-52)
Engine Mount Bolts/Nuts
No. 1 (2)49-69 (67-93)
No. 2 (3)28-38 (38-52)
No. 3 (4)63-86 (85-117)
No. 4 (5)
Bolt47-66 (64-89)
Nut50-69 (68-93)
Exhaust Manifold Heat Shield Bolt14-18 (19-25)
Exhaust Manifold-To-Head Bolt/Nut28-34 (38-46)
Flywheel\Drive Plate Bolt72-76 (97-103)
Front Exhaust Pipe Nuts
Clamp Nuts15-20 (20-27)
Converter Hanger Nuts51-69 (69-94)
Pipe-To-TWC Warmup Converter Nuts30-41 (40-55)
Intake Manifold Bolt14-18 (19-25)
Intake Manifold Support Bracket Bolt27-38 (37-52)
Joint Shaft Support Bracket Bolts32-46 (43-62)
Main Bearing Cap Bolts (6)
Step 129 (39)
Step 2Loosen To Zero
Step 315 (20)
Step 4Plus Torque Angle 90 Degrees
Step 5Plus Torque Angle Additional 60 Degrees
Oil Pan Bolts14-17 (19-23)
Oil Pump Bolt14-19 (19-26)
Pinch Bolts32-38 (43-52)
Power Steering Pump Mounting Bolt28-38 (38-52)
Rear Seal Cover Long Bolt30-41 (40-55)
Stabilizer Control Link Bolts32-45 (43-61)
Starter Bolt27-38 (37-52)
Tensioner Pulley Lock Bolt28-38 (38-52)
Thermostat Housing Bolt14-19 (19-26)
Water Pump Bolt14-19 (19-26)
INCH Lbs. (N.m)
Camshaft Bearing Cap Bolts (7)97-124 (11-14)
Center Cover Bolt44-80 (5-9)
Crankshaft Pulley Bolt106-150 (12-17)
Cylinder Head Cover Bolt71-89 (8-10)
Engine Ground Strap-To-Frame Bolt71-106 (8-12)
Oil Pressure Switch Connection106-159 (12-18)
Oil Strainer Bolt71-106 (8-12)
Rear Seal Cover Short Bolt71-97 (8-11)
Timing Belt Cover Bolt71-97 (8-11)
Timing Belt Guide Plate Bolt106-150 (12-17)
Water Pump Pulley Bolt106-150 (12-17)
(1) Tighten in sequence to specification. (Scheme 304) (2) For illustration of engine mount No. 1 (Scheme 305) (3) For illustration of engine mount No. 2 see scheme 367 (4) Manufacturer does not provide illustration for mount No. 3. (5) For illustration of engine mount No. 4 see scheme 368 (6) Tighten in sequence to specification. see scheme 369 (7) Tighten in sequence to specification. see scheme 370
(1)Tighten in sequence to specification. (Scheme 304)
(2)For illustration of engine mount No. 1 (Scheme 305)
(3)For illustration of engine mount No. 2 see scheme 367
(4)Manufacturer does not provide illustration for mount No. 3.
(5)For illustration of engine mount No. 4 see scheme 368
(6)Tighten in sequence to specification. see scheme 369
(7)Tighten in sequence to specification. see scheme 370

TORQUE SPECIFICATIONS

Scheme 300

Scheme 300

Scheme 301

Scheme 301

Scheme 302

Scheme 302

Scheme 303

Scheme 303

Scheme 304

Scheme 304

Scheme 305
