STARTER SPECIFICATIONS
Note. Specifications for Rio are not available from the manufacturer.
| Application | Specifications | |||
|---|---|---|---|---|
| Armature | ||||
| Commutator Runout | ||||
| Standard | .002" (.05 mm) | |||
| Limit | .016" (.4 mm) | |||
| Commutator Diameter | ||||
| Optima & Magentis (Canadian) | ||||
| Limit | 1.118" (28.4 mm) | |||
| Sephia, Spectra & Sportage | ||||
| Limit | 1.22" (31 mm) | |||
| Brush Length | ||||
| Sephia, Spectra & Sportage | ||||
| Standard | .67" (17 mm) | |||
| Limit | .45" (11.5 mm) | |||
| Pinion Gap | .020-.079" (.5-2.0 mm) | |||
STARTER SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | |
|---|---|---|
| Intake Manifold Bracket Bolts | ||
| Sephia & Spectra | 27-38 (37-52) | |
| Sportage | 27-40 (37-54) | |
| Starter Mounting Bolts | ||
| Sephia & Spectra | 27-38 (37-52) | |
| Sportage | 27-40 (37-54) | |
| Starter Cable Nut | ||
| Sephia & Spectra | 7-9 (9.8-12.0) | |
| Sportage | 12-17 (16-23) | |
| INCH Lbs. (N.m) | ||
| Transmission Range (TR) Switch Bolt | ||
| Sephia & Spectra | 70-95 (7.9-10.7) | |
| Sportage | 35-61 (3.9-5.9) | |
TORQUE SPECIFICATIONS
