NOTICES, CAUTIONS AND WARNINGS

As you read through the various procedures, you will encounter Notices, Cautions and Warnings. Each one is there for a specific purpose. Notices give you added information that will assist you in completing a particular procedure. Cautions prevent you from making an error that could damage the vehicle. Warnings remind you to be especially careful in specific areas where carelessness can cause personal injury.

The following items contain general procedures you should always follow when working on a vehicle

PROTECTION OF VEHICLE

Always cover fenders, seats, and floor areas before starting work. Operate the engine only in a well-ventilated area to avoid carbon monoxide poisoning.

Scheme 20

Scheme 20: PROTECTION OF VEHICLE

A WORD ABOUT SAFETY

The following precautions must be followed when jacking up the vehicle

  1. Block the wheels.
  2. Use only the specified jacking positions.
  3. Support the vehicle with safety stands.

The engine compartment must be clear of tools and people before starting the engine.

Scheme 21

Scheme 21

PREPARATION OF TOOLS AND MEASURING EQUIPMENT

All necessary tools and measuring equipment should be available before starting any work.

Scheme 22

Scheme 22: PREPARATION OF TOOLS AND MEASURING EQUIPMENT

SPECIAL SERVICE TOOLS (SST'S)

Use special service tools when they are required. SST's can be found under "preparation" prior to any procedure requiring them.

Scheme 23

Scheme 23: SPECIAL SERVICE TOOLS (SST'S)

ARRANGEMENT OF PARTS

All disassembled parts should be carefully arranged for reassembly. Separate or otherwise identify the parts to be replaced from those that will be reused.

Scheme 24

Scheme 24: ARRANGEMENT OF PARTS

CLEANING PARTS FOR REUSE

All parts that will be reused should be carefully and thoroughly cleaned using appropriate methods.

Scheme 25

Scheme 25: CLEANING PARTS FOR REUSE

RUBBER PARTS AND TUBING

Prevent gasoline or oil from contacting rubber parts or tubing.

Scheme 26

Scheme 26: RUBBER PARTS AND TUBING

VOLTMETER

The DC voltmeter measures circuit voltage. A voltmeter with a range of 15V or more is used by connecting the positive (+) probe (red lead wire) to the point where voltage is be measured, and the negative (-) probe (black lead wire) to a body ground.

Scheme 27

Scheme 27: VOLTMETER

OHMMETER

The ohmmeter is used to measure the resistance between two points in circuit and also to check for continuity and the diagnosis of short circuits.

CAUTIONDo not attempt to connect the ohmmeter to any circuit in which voltage is applied. Such a connection may damage the ohmmeter.

Scheme 28

Scheme 28

BATTERY CABLE

Before disconnecting connectors or replacing electrical parts, disconnect the negative battery cable.

Scheme 29

Scheme 29: BATTERY CABLE

Scheme 30

Scheme 30: CONNECTORS (REMOVAL OF CONNECTOR)

Scheme 31

Scheme 31
  1. Never pull on the wiring harness when disconnecting connectors.
  2. Connectors can be removed by pressing or pulling lock lever.

CONNECTORS (LOCKING A CONNECTOR)

Listen for a click when locking connectors. This sound indicates that they are securely locked.

Scheme 32

Scheme 32: CONNECTORS (LOCKING A CONNECTOR)

Scheme 33

Scheme 33: CONNECTORS (INSPECTION)

Scheme 34

Scheme 34
  1. When a tester is used to check for continuity or to measure voltage, insert tester probe from wire harness side.
  2. Check terminals of waterproof connectors from connector side because they cannot be accessed from harness side. NOTE: Use a fine wire to prevent damage to the terminal. Do not damage the terminal when inserting the tester lead.

FEMALE

Insert a thin piece of metal from the terminal side of the connector, and then, with the terminal locking tab pressed down, pull the terminal out of the connector.

Scheme 35

Scheme 35: FEMALE

MALE

Follow the same procedure as female-type terminal.

Scheme 36

Scheme 36: MALE

SENSORS, SWITCHES, AND RELAYS

Always handle sensors, switches and relays carefully.

Do not drop them or accidentally strike them against other parts.

Scheme 37

Scheme 37: SENSORS, SWITCHES, AND RELAYS

TOWING

If the vehicle needs to be towed, a wheel lift or as flat-bed method is recommended.

CAUTIONNever tow the vehicle by the method of a suspension (front or rear) lift.

Scheme 38

Scheme 38

Scheme 39

Scheme 39: OVERALL BODY DIMENSION

ENGLISH/METRIC CONVERSION TABLE

MultiplyByTo get equivalent number orMultiplyByTo get equivalent number or
LengthAcceleration
Inch (in)25.4Millimeters (mm)Foot/sec 20.3048Meter/sec 2 (m/s 2 )
Foot (ft)0.3048Meters (m)Inch/sec 20.0254Meter/sec 2 (m/s 2 )
Yard0.9144Meters (m)Torque
Mile1.609Kilometers (km)Inch-pound0.11298Newton-meters (N.m)
Foot-pound1.3558Newton-meters (N.m)
AreaPower
Inch 2 (in 2 )645.2Millimeters 2 (mm 2 )Horsepower (HP)0.746Kilowatts (kw)
6.45Centimeters 2 (cm 2 )Pressure
Foot (ft 2 )0.0929Meters 2 (m 2 )Pounds/inch 26.895Kilopascals (kPa)
Yard0.8361Meters 2 (m 2 )(psi)
VolumeEnergy
Inch 3 (in 3 )16387Mm 3Foot-pound1.3558Joules (J)
16.387Cm 3Kilowatt-hour3,600,000Joules (J)
0.0164Liters (I)
Quart (qt)0.9464Liters (I)
Gallon3.7854Liters (I)
Yard0.7646Meters 3 (m 3 )
MassFuel performance
Pound (lb)0.4536Kilograms (kg)Miles/gal (mpg)0.4251Kilometers/liter (km/I)
Ton907.18Kilograms (kg)
ForceVelocity
Kilogram9.807Newtons (N)Miles/hour (mph)1.6093Kilometers/hour
Ounce (oz)0.2780Newtons (N)
Pound (lb)4.448Newtons (N)
Temperature
To convert fahrenheitTo convert celsius
Temperature to celsiusTemperature to fahrenheit
Temperature, use formulaTemperature, use formula
C = 5/9 (F-32)F = 9/5 C + 32

ENGLISH/METRIC CONVERSION

UNITS

Ft-lb or in-lb (N.m)Torque
RpmRotational speed
AAmperes
VVolts
OhmsResistance (OHMS)
Psi (kPa)Pressure
InHg (mmHg)Pressure (usually negative vacuum)
WWatts (electrical power)
US qt (liters)Volume
In (mm)Length
