Compression Pressure Inspection: Removal & Installation Kia Spectra I рестайлинг 2

REMOVAL

Note. Engine removal is not required for this procedure.

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

1. Remove the engine cover.
2. Remove the RH front wheel.
3. Remove the 2 bolts (B) and RH side cover (A).
4. Remove the engine mounting support bracket. Install the engine hanger. Remove the bolt (B), nuts (C,D) and engine mounting support bracket (A). Remove the bolt (B) and engine support bracket stay plate (A).
5. Temporarily loosen the water pump pulley bolts.
6. Remove the alternator drive belt. See «ALTERNATOR BELT INSPECTION & ADJUSTMENT»(ref-272904-S05652873142007112900000) .
7. Remove the air conditioner compressor drive belt.
8. Remove the power steering pump drive belt. See «CHECKING POWER STEERING BELT TENSION»(ref-272906-S09346315552007112900000) .
9. Remove the 4 bolts and water pump pulley.
10. Remove the 4 bolts (B) and timing belt upper cover (A).
11. Turn the crankshaft pulley, and align its groove with timing mark "T" of the timing belt cover. Check that the timing mark of camshaft sprocket is aligned with the timing mark of cylinder head cover. (No. 1 cylinder compression TDC position)
12. Remove the crankshaft pulley bolt (B) and crankshaft pulley (A).
13. Remove the crankshaft flange (A).
14. Remove the 5 bolts (B) and timing belt lower cover (A)
15. Remove the timing belt tensioner (A) and timing belt (B). NOTE: If the timing belt is going to be reused, make an arrow indicating the turning direction to make sure that the belt is reinstalled in the same direction as before.
16. Remove the bolt (B) and timing belt idler (A).
17. Remove the crankshaft sprocket (A).
18. Remove the cylinder head cover. Disconnect the spark plug cables and do not pull on the cable by force. NOTE: Pulling on or bending the cables may damage the conductor inside. Remove the PCV (Positive Crankcase Ventilation) hose (A) and the breather hose (B) from the cylinder head cover. Remove the accelerator cable (A) from the cylinder head cover. Loosen the cylinder head cover bolts (B) and then remove the cover (A) and gasket.
19. Remove the camshaft sprocket. Hold the portion (A) of the camshaft with a hexagonal wrench. Remove the bolt (C) with a wrench (B) and remove the camshaft sprocket.
