SPECIFICATIONS
| Item | Specification |
|---|---|
| Master cylinder | |
| Type | Tandem type |
| I.D. | 23.81 mm (0.937 in.) |
| Fluid level warning sensor | Provided |
| Proportioning valve (CBS) | |
| Cut-in pressure (Split point) | 26 kg/cm 2 (2.55 MPa, 370 psi) |
| Decompression ratio | 0.27 : 1 |
| Brake booster | |
| Type | Vacuum |
| Effective diameter | Tandem type with 7+8 in. |
| Boosting ratio | 7.5 : 1 |
| Front brake (Disc) | |
| Type | Floating type with ventilated disc |
| Disc O.D. | 275 mm (10.83 in.) |
| Disc thickness | 26 mm (1.02 in.) |
| Pad thickness | 11 mm (0.43 in.) |
| Cylinder type | Single piston |
| Cylinder I.D. | 057.2 mm (2.25 in.) |
| Rear brake (Disc) | |
| Type | Floating type with solid disc |
| Disc O.D. | 258 mm (10.16 in.) |
| Disc thickness | 10 mm (0.39 in.) |
| Pad thickness | 9 mm (0.35 in.) |
| Cylinder type | Single piston |
| Cylinder I.D. | 033.96 mm (1.34 in.) |
| Rear brake (Drum) | |
| Type | Leading trailing |
| Drum I.D. | 203.2 mm (8 in.) |
| Brake lining thickness | 4.5 mm (0.18 in.) |
| Clearance adjustment | Automatic |
| Parking brake | |
| Actuation | Mechanical brake acting on rear wheels |
| Type | Lever |
| Cable arrangement | V type |
General Specifications
Note. In (Scheme 1), ABS applies to Anti-lock Brake System and CBS applies to Conventional Brake System.
Scheme 1
TIGHTENING TORQUE
| Item | Nm | Kg.cm |
|---|---|---|
| Master cylinder to booster mounting nut | 8--12 | 80--120 |
| Brake booster mounting nut | 13--16 | 130--160 |
| Bleeder screw | 7--9 | 70--90 |
| Brake tube nut, brake hose | 13--17 | 130--170 |
| Caliper guide rod bolt | 22--32 | 220--320 |
| Member assembly bracket mounting bolt | 8--12 | 80--120 |
| Brake pedal mounting bolt | 25--35 | 250--350 |
| Stop lamp switch mounting nut | 8--10 | 80--100 |
| Caliper assembly to knuckle | 69--75 | 690--750 |
| Brake hose to front caliper | 25--30 | 250--300 |
| Brake hub flange nut | 200--260 | 2000--2600 |
| Wheel cylinder mounting bolt | 5--11 | 50--110 |
| Rear drum backing plate mounting bolt | 50--60 | 500--600 |
| Proportioning valve to master cylinder | 35--55 | 350--550 |
Torque Specifications
