Removal
Engine removal is not required for this procedure.
| CAUTION | Use fender covers to avoid damaging painted surfaces. To avoid damage, unplug the wiring connectors carefully while holding the connector portion. |
Note. Mark all wiring and hoses to avoid misconnection.
Scheme 82
Scheme 83
Scheme 84
Scheme 85
Scheme 86
Scheme 87
Scheme 88
Scheme 89
Scheme 90
Scheme 91
Scheme 92
Scheme 93
Scheme 94
Scheme 95
Scheme 96
Scheme 97
Scheme 98
Scheme 99
Scheme 100
Scheme 101
Scheme 102
Scheme 103
Scheme 104
Scheme 105
Scheme 106
Scheme 107
Scheme 108
Scheme 109
Scheme 110
Scheme 111
Scheme 112
Scheme 113
- Disconnect the battery negative terminal. (Refer to «ENGINE AND TRANSAXLE ASSEMBLY»(ref-537192-S30675217252013032200000) in this group)
- Remove the engine cover. (Refer to «ENGINE AND TRANSAXLE ASSEMBLY»(ref-537192-S30675217252013032200000) in this group)
- Remove the RH front wheel. (Refer to «SPECIFICATIONS»(ref-537195-S12903539772013032200000) - "Wheel")
- Remove the under cover. (Refer to «ENGINE AND TRANSAXLE ASSEMBLY»(ref-537192-S30675217252013032200000) in this group)
- Disconnect the wiring connectors and harness clamps, and then remove the wiring and protectors from the cylinder head cover. The intake OCV (Oil control valve) connector (A) The exhaust OCV (Oil control valve) connector (A) The alternator connector (A) The ignition coil connectors (A) The intake CMPS (Camshaft position sensor) connector (A) The exhaust CMPS (Camshaft position sensor) connector (B)
- Disconnect the breather hose (A).
- Disconnect the PCV (Positive crankcase ventilation) hose (A).
- Remove the ignition coils (A).
- Remove the engine oil level gauge (A).
- Remove the cylinder head cover (A). NOTE: Unfasten the bolts in the sequence as shown.
- Drain engine oil and remove the oil pan. (Refer to «ENGINE OIL»(ref-537289-S28014082032013032200000) .
- Remove the engine mounting support bracket. Set the jack to the edge of the lower crankcase. NOTE: Put the wooden block between lower crankcase and jack. CAUTION: Be careful not to damage the oil screen. Disconnect the engine ground line (A). Remove the engine mounting support bracket (B).
- Remove the drive belt. Loosen the alternator mounting bolts (A). Loosen the tension by turning the tension adjusting bolt (B) counterclockwise. Remove the drive belt (C).
- Remove the front engine hanger (A).
- Remove the alternator (A). (Refer to " «ALTERNATOR»(ref-537208-S23993639882013032200000) ")
- Remove the A/C compressor (A). (Refer to «REMOVAL»(ref-537279-S10720483702013032200000) "").
- Remove the water pump pulley (A).
- Set No. 1 cylinder to TDC (Top dead center) on compression stroke. Turn the crankshaft pulley and align its groove with the timing mark of the timing chain cover. Check that the TDC marks of the intake and exhaust CVVT sprockets are in straight line on the cylinder head surface as shown in the illustration. If not, turn the crankshaft by one revolution (360°) more. NOTE: Do not turn the crankshaft pulley counterclockwise.
- Remove the crankshaft damper pulley (A). CAUTION: Do not press the pulley or apply the excessive force to prevent the rubber part from being deformed. NOTE: There are two methods to hold the ring gear when removing the crankshaft damper pulley. Install the SST (09231-2B100) to hold the ring gear after removing the starter. Install the SST (09231-3D100) to hold the ring gear after removing the service cover. Remove the two transaxle mounting bolts (A) and the service cover (B) on the bottom of the lower crankcase. Adjust the length of the holder (A) so that the grooves of the holder puts into the ring gears (B) at the closest position. Adjust the angle and length of the links (C) so that the two transaxle mounting bolts can be fastened into the original mounted holes. Install the SST using the two transaxle mounting bolts. Tighten the bolts and nuts of the holder and links securely.
- Remove the water pump assembly (A) with the gasket (B).
- Remove the timing chain cover (A) by gently prying the gaps between the cylinder head and cylinder block. CAUTION: Be careful not to damage the contact surfaces of cylinder block, cylinder head and timing chain cover.
- Remove the timing chain tensioner (A). CAUTION: Do not reuse the detached tensioner. If need to reuse the tensioner, remove the tensioner, make the piston (A) to protrude maximally, push the piston (A) to the end, and then mount the stopper pin. At this time, the tensioner fixing pin should be placed in the same way as when the product was first delivered from the factory.
- Remove the timing chain tensioner arm (A).
- Remove the timing chain (A).
- Remove the timing chain guide (A).
