Specifications
| Items | Specifications | |
|---|---|---|
| Rated voltage | DC 12V | |
| Operating temperature range | 30°C ~ +80°C (-22 ~ +176°F) | |
| Rated load | Dimmer & passing switch | High: 0.2A (Relay load) Low: 0.2A (Relay load) Passing: 0.2A (Relay load) |
| Lighting switch | Lighting: 0.2A (Relay load) | |
| Turn signal switch | 6.6 ± 0.5A (Lamp load) | |
| Wiper & mist switch | High: 4.5A (Motor load) Low: 4.5 A (Motor load) Intermittent: 0.22±0.05A(Relay Load) Lock: Max. 28A (Motor load) Mist: 4A (Motor load) | |
| Fog lamp switch | 0.2A (Relay load) | |
| Rear wiper & Washer | Wiper: 1A (Relay load) Washer: 4A (Motor load) | |
Scheme 1
Scheme 2
Scheme 3
- With the multi function switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the multi-function switch
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
- With the multi function switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the multi-function switch.
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Scheme 15
Scheme 16
Scheme 17
Scheme 18
Scheme 19
- Disconnect the negative (-) battery terminal.
- Remove the steering column upper and lower shrouds (A) after removing 3 screws.
- Disconnect the light switch connector (A) and the wiper switch connector (B).
- Remove the wiper switch (A) by pushing the lock pin (B). NOTE: When removing the wiper & washer switch only, release the lock of wiper switch without removing the steering wheel.
- Remove the clock spring(A).
- Loosen the screws from the multifunction switch assembly.
- Remove the multifunction switch assembly(A) after loosening the connectors.
