Special Service Tools
Tool (Number and name) Illustration Use Crankshaft front oil seal installer (09231-2E000) (09231-H1100) Installation of the front oil seal 09231-2E000 (installer) 09231-H1100 (handle) Valve stem seal installer (09222-2E000) Installation of the valve stem oil seal Valve spring compressor (09222-3K000) (09222-3K100) Removal and installation of the intake or exhaust valve 09222-3K000 (compressor) 09222-3K100 (holder) Crankshaft rear oil seal installer (09214-2E000) (09231-H1100) Installation of the rear oil seal 09214-2E000 (installer) 09231-H1100 (handle) Ring gear stopper (09231-2B100) Holding ring gear so that engine doesn't turn/move after the starter is removed Ring gear stopper (09231-3D100) Holding ring gear so that engine doesn't turn/move after the service cover is removed Torque angle adapter (09221-4A000) Installation of bolts & nuts needing an angular method of adjustment Oil pan remover (09215-3C000) Removal of oil pan Must use this tool to separate the oil pan from the lower crankcase assembly without damage to the sealing surfaces Tensioner stopper pin (09240-2E100) Holding compressed piston of tensioner
