General Information: Overview Kia Soul I рестайлинг

Hoist/jack 8 illustrations ~1241 words

Scheme 4

Scheme 4: Identification Number Locations
Scheme 4: Identification Number Locations

Scheme 5

Scheme 5: Vehicle Identification Number
Scheme 5: Vehicle Identification Number
  1. World Manufacturer Identifier (WMI) KNA: Passenger vehicle, MPV(Multipurpose Passenger Vehicle)/SUV(Sports Utility Vehicle)/RV(Recreational Vehicle) KNC: Commercial vehicle (Van) KND: MPV/SUV/RV (For U.S.A, Canada, Mexico) KNH: Van
  2. Vehicle line J: SOUL
  3. Model & Series S: Low grade (L) T: Middle-Low grade (GL) U: Middle grade (GLS, JSL, TAX) V: Middle-High grade (HGS) W: High grade (TOP)
  4. Body/Cabin type, Gross Vehicle Weight Rating KNA 1: Limousine 2: Sedan - 2 door 3: Sedan - 3 door 4: Sedan - 4 door 5: Sedan - 5 door 6: Coupe 7: Convertible 8: Wagon 9: Commercial Van 0: Pick-Up KNC (Commercial vehicle / Van) Except U.S.A, Canada, Mexico, Gulf Cooperation Council, China X: Standard Cabin / Semi-Bonnet Y: Double Cabin / Bonnet Z: Super Cabin / Box For U.S.A, Canada, Mexico, Gulf Cooperation Council, China 2: Standard Cabin Class-H 4x2 3: Standard Cabin Class-E 4x2 / Semi-Bonnet Class-E 4x2 4: Standard Cabin Class-E 4x4 / Semi-Bonnet Class-E 4x4 5: Standard Cabin Class-F 4x2 / Semi-Bonnet Class-F 4x2 6: Standard Cabin Class-F 4x4 / Semi-Bonnet Class-F 4x4 7: Double Cabin Class-E 4x2 / Bonnet Class-E 4x2 8: Double Cabin Class-E 4x4 / Bonnet Class-E 4x4 9: Double Cabin Class-F 4x2 / Bonnet Class-F 4x2 0: Double Cabin Class-F 4x4 / Bonnet Class-F 4x4 A: Super Cabin Class-E 4x2 / Box Class-E 4x2 B: Super Cabin Class-E 4x4 / Box Class-E 4x4 C: Super Cabin Class-F 4x2 / Box Class-F 4x2 D: Super Cabin Class-F 4x4 / Box Class-F 4x4 KND 1: Wagon 4x2 Class-A 2: Wagon 4x2 Class-B 3: Wagon 4x2 Class-C 4: Wagon 4x2 Class-D 5: Wagon 4x2 Class-E 6: Wagon 4x2 Class-F 7: Wagon 4x2 Class-G A: Wagon 4x4 Class-A B: Wagon 4x4 Class-B C: Wagon 4x4 Class-C D: Wagon 4x4 Class-D E: Wagon 4x4 Class-E F: Wagon 4x4 Class-F G: Wagon 4x4 Class-G KNH 1: Box 2: Bonnet 3: Semi-Bonnet
  5. Restraint system, Brake system KNA, KND Except U.S.A, Canada, Mexico 0: Both side - None 1: Both side - Active belt 2: Both side - Passive belt For U.S.A, Canada, Mexico Code Seat belt Front air bag Knee air bag Side air bag Curtain air bag Driver's Passenger's Driver's Passenger's 1st row 2nd row 3rd row 1st row 2nd row 3rd row A o o o x x o x x o o x B o o o x x x x x x x x C o o o x x o x x o o o D o o o x x o o x o o x E o o x x x x x x x x x F o o o x x o x x x x x J o o o o x o o x o o x L o o o o x o x x o o x N o x x x x x x x x x x H o o o o x o x x o o o KNC, KNH Except U.S.A, Canada, Mexico 7: Hydraulic brake system 8: Pneumatic brake system 9: Mixed brake system For U.S.A, Canada, Mexico X: Hydraulic brake system Y: Pneumatic brake system Z: Mixed brake system
  6. Engine type 5: Gasoline engine 1.6 (Gamma GDI) 6: Gasoline engine 2.0 (Nu MPI)
  7. Check digit or Driver's side & Transmission Except U.S.A, Canada, Mexico, Gulf Cooperation Council, China, Yemen A: LHD & MT B: LHD & AT C: LHD & MT+Transfer D: LHD & AT+Transfer E: LHD & CVT L: RHD & MT M: RHD & AT N: RHD & MT+Transfer S: RHD & AT+Transfer T: RHD & CVT For U.S.A, Canada, Mexico, Gulf Cooperation Council, China, Yemen Check digit: 0 ~ 9, x
  8. Model year B: 2011, C: 2012, D: 2013, E: 2014...
  9. Plant of production 6: Sohari (Korea) 5: Hwasung (Korea) 7: Kwangju (Korea) T: Seosan (Korea)
  10. Vehicle production sequence number 000001 ~ 999999
CodeColor
9HBlack Soul
1D, UDClear White
3D, A3DBright Silver
IMTitanium Silver
I2Moonlight Blue
1ETomato Red
I7Green Tea Latte
A1, A1WVanilla Shake
BD5Olive Green
DT9Saddle Brown
ASEMisty Green

PAINT CODE

Scheme 6

Scheme 6: Engine Number
Scheme 6: Engine Number
  1. Engine fuel G: Gasoline
  2. Engine range 4: 4 cycle 4 cylinder
  3. Engine development order and capacity F: Gamma engine N: Nu engine
  4. Engine Capacity D: 1591cc (Gamma GDI) A: 1999cc (Nu MPI)
  5. Production year B: 2011, C: 2012, D: 2013, E: 2014...
  6. Plant of production A: Asan (Korea) B: Beijing (China) H: Hwasung (Korea) K: Montgomery (U.S.A) M: Chennai (India) P: Poseung (Korea) S: Sohari (Korea) T: Izmit (Turkey) U: Ulsan (Korea) W: Shandong (China) Z: Zilina (Slovakia) 1: Yancheng (China)
  7. Engine production sequence number 000001 ~ 999999

Scheme 7

Scheme 7: Manual (M6CF1)
Scheme 7: Manual (M6CF1)
  1. Assembly code of plant
  2. Production year B: 2011, C: 2012, D: 2013, E: 2014...
  3. Plant of production W: Hwasung (Korea) J: Ostrava (Czech)
  4. Transaxle production sequence number 000001~999999

Scheme 8

Scheme 8: Manual (M6CF3-1)
Scheme 8: Manual (M6CF3-1)
  1. Model W: M6CF3-1
  2. Production year B: 2011, C: 2012, D: 2013, E: 2014...
  3. Plant of production W: Hwasung (Korea) J: Ostrava (Czech)
  4. Speed
  5. Reserve
  6. Final gear ratio K: 4.333 (Nu)
  7. Transaxle production sequence number 000001 ~ 999999

Scheme 9

Scheme 9: Automatic
Scheme 9: Automatic
  1. Model EA: A6MF1 NA: A6GF1
  2. Production year B: 2011, C: 2012, D: 2013, E: 2014...
  3. Final gear ratio T: 3.367 (Nu 15, 16 inch tire) U: 3.510 (Nu 18 inch tire) S: 3.796 (Gamma)
  4. Detailed classification F: Nu 2.0 MPI (15, 16 inch tire) G: Nu 2.0 MPI-ISG (15, 16 inch tire) E: Nu 2.0 MPI (18 inch tire) F: Nu 2.0 MPI-ISG (18 inch tire) C: Gamma 1.6 GDI F: Gamma 1.6 GDI-ISG
  5. Plant classification H: Hwasung (Korea) U: Ulsan - Plant 1 (Korea) S: Ulsan - Plant 2 (Korea) 2: Powertech - Pant 2 (Korea) 4: Powertech - Pant 4 (Korea) A: Powertech (U.S.A) C: Powertech (China)
  6. Transaxle production sequence number 000001 ~ 999999

Scheme 10

Scheme 10: Warning / Caution Label Locations
Scheme 10: Warning / Caution Label Locations

Scheme 11

Scheme 11: Battery Caution Label Describtion
Scheme 11: Battery Caution Label Describtion
  1. Keep lighted cigarettes and all other flames or sparks away from the battery.
  2. Wear eye protection when charging or working near a battery. Always provide ventilation when working in an enclosed space. When lifting a plastic-cased battery, excesive pressure on acid to leak resulting in personal injury. Lift with a battery carrier or with your hands on opposite corners. Never attempt to change the battery when the battery cables are connected. The electrical ignition system works with high voltage. Never touch these components with the engine running or the ignition switched on.
  3. Keep batteries out of the reach of children because batteries contain highly corrosive SULFURIC ACID. Do not allow battery acid to contact your skin, eyes, clothing or paint finish.
  4. If any electrolyte gets into your eyes, flush your eyes with clean water for at least 15 minutes and get immediate medical attention. If possible, continue to apply water with a sponge or cloth until medical attention is received. If electrolyte gets on your skin, throughly wash the contacted area. If you feel a pain or a burning sensation, get medical attention immediately.
  5. Always read the following instructions carefully when handing a battery.
  6. Hydrogen, which is a highly combustible gas, is always presents in battery cells and may explode if ignited.
  7. An improperly disposed battery can be harmful to the environment and human health. Always confirm local regurations for battery disposal.
Battery ItselfBatteries should be stored in cool, dry (27 degrees Celsius) places and out of direct sunlight. MF batteries are tightly sealed to prevent acid leakage. However, tilting the battery to an angle of 45 degrees can cause acid to leak through the vents on the sides. Therefore, batteries should always be stored in their upright positions. Prevent placing any aqueous or solid (i.e. conductors) bodies on top of the battery. It is extremely dangerous to use tools, such as hammers, on the battery terminals when connecting cables to the mounted battery.
Battery on VehicleWhen storing the vehicle for long periods of time, make sure to remove the memory fuse at junction box to prevent natural discharging. Also, run the engine for battery charging within 1 month if the memory fuse wasn't removed from the start of vehicle storing. If the memory fuse was removed, run the engine for battery charging within 3 months from the start of vehicle storing.

HANDLING AND STORAGE BATTERY

Note. After reconnecting or recharging a discharged battery, the ESC OFF indicator may illuminate. In this case, turn the handle half way to the left and right whilst the ignition switch is in the ON position. Then, restart the engine after the ignition is OFF. The ESC OFF indicator may turn OFF. If the ESC OFF indicator does not turn OFF, have the system checked referring to DTC. (Refer to the BRAKE SYSTEM BLEEDING .
