Contents Section: Fuel System All sections

Engine Control/fuel System - General Information - 2.0L: Other Kia Soul I рестайлинг

Fuel System 2 illustrations ~260 words

Fuel Delivery System

ItemsSpecification
Fuel TankCapacity48 lit. (12.6 U.S.gal., 50.7 U.S.qt., 42.2 lmp.qt.)
Fuel FilterTypePaper type
Fuel Pressure RegulatorRegulated Fuel Pressure338 ~ 348 kPa (3.45 ~ 3.55 kgf/cm 2 , 49.0 ~ 50.5 psi)
Fuel PumpTypeElectrical, in-tank type
Driven byElectric motor

Sensors

Manifold Absolute Pressure Sensor (MAPS)

  1. Type: Piezo-resistive pressure sensor type
  2. Specification
Pressure [kPa (kgf/cm 2 , psi)]Output Voltage (V)
20.0 (0.20, 2.9)0.79
46.7 (0.47, 6.77)1.84
101.3 (1.03, 14.7)4.0

Intake Air Temperature Sensor (IATS)

  1. Type: Thermistor type
  2. Specification
Temperature [°C(°F)]Resistance (kohms)
40(-40)40.93 ~ 48.35
20(-4)13.89 ~ 16.03
0(32)5.38 ~ 6.09
10(50)3.48 ~ 3.90
20(68)2.31 ~ 2.57
40(104)1.08 ~ 1.21
50(122)0.76 ~ 0.85
60(140)0.54 ~ 0.62
80(176)0.29 ~ 0.34

Engine Coolant Temperature Sensor (ECTS)

  1. Type: Thermistor type
  2. Specification
Temperature [°C(°F)]Resistance (kohms)
40(-40)48.14
20(-4)14.13 ~ 16.83
0(32)5.79
20(68)2.31 ~ 2.59
40(104)1.15
60(140)0.59
80(176)0.32

Throttle Position Sensor (TPS) [integrated into ETC module]

  1. Type: Hall IC Non-contact sensor type
  2. Specification
Throttle angle (°)Output voltage (V) [Vref = 5.0V]
TPS1TPS2
00.54.5
100.964.05
201.413.59
301.873.14
402.322.68
502.782.23
603.231.77
703.691.32
804.140.86
904.60.41
984.650.35
C.T (0)0.54.5
W.O.T (86)4.410.59

Crankshaft Position Sensor (CKPS)

  1. Type: Magnetic field sensitive Type
ItemSpecification
Coil Resistance (ohms)774 ~ 946 [20°C (68°F)]

Camshaft Position Sensor (CMPS)

  1. Type: Hall effect type Knock Sensor (KS)
  2. Type: Piezo-electricity type
  3. Specification
ItemSpecification
Capacitance (pF)850 ~ 1, 150

Heated Oxygen Sensor (HO2S) [Bank 1/Sensor 1]

  1. Type: Zirconia (ZrO2) [Linear] type
  2. Specification
ItemSpecification
Heater Resistance (ohms)2.4 ~ 4.0 [20°C(69.8°F)]

Heated Oxygen Sensor (HO2S) [Bank 1/Sensor 2]

  1. Type: Zirconia (ZrO2) [Binary] type
  2. Specification
A/F Ratio (lambda)Output Voltage(V)
RICH0.6 ~ 1.0
LEAN0 ~ 0.4
ItemSpecification
Heater Resistance (ohms)Approx. 9.0 [20°C(68°F)]

Accelerator Position Sensor (APS)

  1. Type: Variable resistor type
  2. Specification
Accelerator PositionOutput Voltage (V)
APS1APS2
C.T0.7 ~ 0.80.275 ~ 0.475
W.O.T3.85 ~ 4.351.75 ~ 2.35

Fuel Tank Pressure Sensor (FTPS)

  1. Type: Piezo - Resistivity type
  2. Specification
Pressure [kPa (kgf/cm 2 , in H2O)Output Voltage (V)
6.67 (-0.068, -26.8)0.5
02.5
+6.67 (0.068, 26.8)4.5

Actuators

Injector

  1. Specification
ItemSpecification
Coil Resistance (ohms)13.8 ~ 15.2 [20°C(68°F)]

ETC Motor [integrated into ETC Module]

  1. Specification
ItemSpecification
Coil Resistance (ohms)0.3 ~ 100 [20°C(68°F)]

Purge Control Solenoid Valve (PCSV)

  1. Specification
ItemSpecification
Coil Resistance (ohms)22.0 ~ 26.0 [20°C(68°F)]

CVVT Oil Control Valve (OCV)

  1. Specification
ItemSpecification
Coil Resistance (ohms)9, 4 ~ 10, 4 [20°C(68°F)]

Variable Intake Solenoid (VIS) Valve

  1. Specification
ItemSpecification
Coil Resistance (ohms)30.0 ~ 35.0 [20°C(68°F)]

Variable Charge Motion Actuator (VCMA)

  1. Specification
ItemSpecification
Coil Resistance (ohms)3.4 ~ 4.4 [20°C(68°F)]

VARIABLE CHARGE MOTION ACTUATOR SPECIFICATIONS [MOTOR]

ItemSpecification
Coil Resistance (kohms)3.44 ~ 5.16 [20°C(68°F)]

VARIABLE CHARGE MOTION ACTUATOR SPECIFICATIONS [POSITION SENSOR]

Ignition Coil

  1. Type: Stick type
  2. Specification
ItemSpecification
Primary Coil Resistance (ohms)0.75 ± 15[] [20°C(68°F)]
Secondary Coil Resistance (kohms)5.9 ± 15[] [20°C(68°F)]

Canister Close Valve (CCV)

  1. Specification
ItemSpecification
Coil Resistance (ohms)15.5 ~ 18.5 [20°C(68°F)]

Service Standard

ItemSpecification
Ignition Timing (°)BTDC 5 ± 10
Idle Speed (rpm)A/C OFFNeutral, N, P-range630 ± 100
D-range630 ± 100
A/C ONNeutral, N, P-range720 ± 100
D-range720 ± 100

Engine Control System

ItemKgf.mN.m
ECM installation nut1.0 ~ 1.29.8 ~ 11.8
ECM bracket installation nut0.8 ~ 1.27.8 ~ 11.8
ECM bracket installation bolt2.0 ~ 3.019.6 ~ 29.4
Manifold absolute pressure sensor installation bolt1.0 ~ 1.29.8 ~ 11.8
Intake air temperature sensor installation bolt1.0 ~ 1.29.8 ~ 11.8
Engine coolant temperature sensor installation3.0 ~ 4.029.4 ~ 39.2
Crankshaft position sensor installation bolt1.0 ~ 1.29.8 ~ 11.8
Camshaft position sensor (Bank 1 / Intake) installation bolt1.0 ~ 1.29.8 ~ 11.8
Camshaft position sensor (Bank 1 / Exhaust) installation bolt1.0 ~ 1.29.8 ~ 11.8
Knock sensor installation bolt1.9 ~ 2.418.6 ~ 23.5
Heated oxygen sensor (Bank 1 / sensor 1) installation4.0 ~ 5.039.2 ~ 49.1
Heated oxygen sensor (Bank 1 / sensor 2) installation4.0 ~ 5.039.2 ~ 49.1
Electronic throttle body installation bolt1.0 ~ 1.29.8 ~ 11.8
Purge control solenoid valve bracket installation bolt1.0 ~ 1.29.8 ~ 11.8
CVVT oil control valve (Bank 1 / Intake) installation bolt1.0 ~ 1.29.8 ~ 11.8
CVVT oil control valve (Bank 1 / Exhaust) installation bolt1.0 ~ 1.29.8 ~ 11.8
Variable intake solenoid valve bracket installtion bolt1.0 ~ 1.29.8 ~ 11.8
Ignition coil installation bolt1.0 ~ 1.29.8 ~ 11.8
Variable charge motion actuator installation bolt1.0 ~ 1.29.8 ~ 11.8
ItemKgf.mN.m
Fuel tank installation bolt4.0 ~ 5.539.2 ~ 53.9
Fuel tank installation nut4.0 ~ 5.539.2 ~ 53.9
Fuel pump plate cover installation nut0.2 ~ 0.32.0 ~ 2.9
Filler-neck assembly bracket installation bolt0.4 ~ 0.63.9 ~ 5.9
Filler-neck assembly installation screw0.6 ~ 0.75.6 ~ 6.9
Accelerator pedal installation nut1.7 ~ 2.616.7 ~ 25.5
Delivery pipe installation bolt1.9 ~ 2.418.6 ~ 23.5

Special Service Tools

Tool (Number and Name) Illustration Application Fuel Pressure Gauge (09353-24100) Measuring the fuel line pressure Fuel Pressure Gauge Adapter (09353-38000) Connection between the delivery pipe and the fuel feed line Fuel Pressure Gauge Connector (09353-24000) Connection between the Fuel Pressure Gauge (09353-24100) and the Fuel Pressure Gauge Adapter (09353-38000) Heated Oxygen Sensor Socket Wrench (09392-2H100) Removal and installation of the heated oxygen sensor

Scheme 76

Scheme 76: Special Service Tools
Scheme 76: Special Service Tools

Scheme 77

Scheme 77
Scheme 77
