Exterior Lights 5 illustrations ~275 words

Specification

ItemsBulb Wattage (W)
Head lamp (High/Low)60/55
Front turn signal lamp27
Front fog lamp35
Position lamp5
Rear stop/tail lamp27/8
Back up lamp16
Rear turn signal lamp27
License plate lamp5
Side marker5
Room lamp10
Overhead console lamp10
High mounted stop lamp5
Luggage room lamp5
Turn signal lamp - Outside mirror5

Scheme 1

Scheme 1: Component Location

Scheme 2

Scheme 2: Head Lamp Relay / Front Lamp Relay

Scheme 3

Scheme 3
  1. Disconnect the negative(-) battery terminal.
  2. Pull out the relay from the engine compartment relay box. Head lamp(Low) relay Head lamp (High) relay
  3. Check for continuity between terminals. There should be continuity between the No. 87 and No. 30 terminals when power and ground are connected to the No. 86 and No. 85 terminals.
  4. There should be no continuity between the No. 87 and No. 30 terminals when power is disconnected.

Scheme 4

Scheme 4: Tail Lamp
  1. Disconnect the negative(-) battery terminal.
  2. Remove the crash pad lower panel. (Refer to the " «CRASH PAD»(ref-537227-S36224571332013032200000) ")
  3. Remove the junction box.
  4. Check for continuity between the terminals. There should be continuity between the No. 1 terminal in the I/P-F and the No. 17(LH) or 16(RH) terminal in the I/P-I when power and ground are connected to the No. 1 terminal in the I/P-F and the No. 18 terminal in the I/P-A. There should be no continuity between the No. 1 terminal in the I/P-F and the No. 17(LH) or 16(RH) terminal in the I/PI when power is disconnected.

Scheme 5

Scheme 5: Front Fog Lamp
  1. Disconnect the negative(-) battery terminal.
  2. Remove the crash pad lower panel. (Refer to the " «CRASH PAD»(ref-537227-S36224571332013032200000) ")
  3. Remove the junction box.
  4. Check for continuity between the terminals. There should be continuity between the No. 1 terminals in the I/P-F and No. 11 terminals in the I/P-G when power and ground are connected to the No. 1 terminals in the I/P-F and No. 3 terminals in the I/P-A. There should be no continuity between the No. 1 terminals in the I/P-F and No. 11 terminals in the I/P-G when power is disconnected.
