SPEAKER
| Item | D446 | D465 | |
|---|---|---|---|
| Input Power (W) | Front | 43 (1WAY) | 43 (1WAY) |
| Rear | 45 (2WAY) | 45 (2WAY) | |
| Tweeter | 30 | 30 | |
| Speaker Impedance (ohms) | Front | 4.0 ± 0.6 (1WAY) | 4.0 ± 0.6 (1WAY) |
| Rear | 4.0 ± 0.6 (2WAY) | 4.0 ± 0.6 (2WAY) | |
| Tweeter | 4.0 ± 0.6 | 4.0 ± 0.6 | |
| Speaker Number | 6 | 6 | |
SPEAKER SPECIFICATIONS
Scheme 64
Scheme 65
Scheme 66
Scheme 67
Scheme 68
Scheme 69
Scheme 70
Scheme 71
Scheme 72
- Disconnect the negative (-) battery terminal.
- Remove the center fascia lower panel (A) (Refer to the «CRASH PAD»(ref-278816-S11302877372008020400000) in ) after pulling it by using regular screw driver (-) at part (A). Take care of fixing clips (B).
- Remove the center fascia panel (A) after loosening the screws. Avoid damaging retaining clips.
- Remove the connectors of center fascia panel.
- Remove the mounting screws then remove the center air vent (A).
- Remove the mounting screws then remove the audio unit (A).
- Remove the audio unit after disconnecting the audio connectors and cable.
