COMPONENT INSPECTION Kia Sorento I facelift

Automatic Transaxle System: Diagnosis 5 illustrations ~587 words

COMPONENT INSPECTION

Refer to DTC P0711 .

ItemDetecting ConditionPossible cause
DTC StrategyCheck the voltage range* ATF T/S : Automatic Transmission Fluid Temperature Sensor OPEN OR SHORT IN CIRCUIT Faulty ATF T/S 1 Faulty TCM
Enable ConditionsOil temp, at IG "ON" < or = -39°C Engine speed > 1000 RPM Output speed > or = 500 RPM Engine coolant temp. > or = 70°C Delay time = 160sec
Threshold valueInput voltage > 4.8V
Diagnostic Time10 minutes accumulative total
Fail SafeFluid temperature is regarded as 80°C

DTC DETECTING CONDITION POSSIBLE CAUSE

Refer to DTC P0711 .

Refer to DTC P0711 .

Refer to DTC P0712 .

Refer to DTC P0711 .

ItemDetecting ConditionPossible cause
DTC StrategySpeed rationality checkSignal circuit is open or short Sensor power circuit is open Sensor ground circuit is open Faulty INPUT SPEED SENSOR 1 Faulty TCM
Enable ConditionsBattery voltage > 10V Output speed > 200 RPM Engine speed > 700 RPM State of "TRANSMISSION" is "STATIC" The time after the last shift was finished 500msec
Threshold valueInput speed1 > 100 RPM
Diagnostic TimeMore than 2sec
Fail Safe"Input speed" is regarded as 600 RPM (Nt = 600 RPM) Shift prevention over 4th gear Prevention of manual shift Prevention of pressure adaptation

DTC DETECTING CONDITION POSSIBLE CAUSE

  1. Many malfunctions in the electrical system are caused by poor harness and terminal conditions. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
  2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
  3. Has a problem been found? YES Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-278800-S14269648552008020400000) " procedure. NO Go to " «SIGNAL CIRCUIT INSPECTION»(ref-278800-S14591895952008020400000) " procedure.

Scheme 14

Scheme 14: SIGNAL CIRCUIT INSPECTION
Scheme 14: SIGNAL CIRCUIT INSPECTION
  1. Ignition "ON" & Engine "OFF".
  2. Disconnect the "C106-3" connector.
  3. Measure voltage between terminal "6" of the C106-3 harness connector and chassis ground. Specification : Approx. 5 V
  4. Is voltage within specifications? YES Go to " «POWER SUPPLY CIRCUIT INSPECTION»(ref-278800-S16761712152008020400000) " procedure. NO Check for open or short in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-278800-S14269648552008020400000) " procedure. If signal circuit in harness is OK, Go to " «CHECK TCM»(ref-278800-S42363626802008020400000) " of the " «COMPONENT INSPECTION»(ref-278800-S31865699612008020400000) " procedure.

Scheme 15

Scheme 15: POWER SUPPLY CIRCUIT INSPECTION
Scheme 15: POWER SUPPLY CIRCUIT INSPECTION
  1. Remove "OIL PAN".
  2. Ignition "ON", Engine "OFF".
  3. Connect the "C106-3 and Shift CM" connector.
  4. Measure resistance between terminal "4" of the TURBINE SENSOR harness connector and chassis ground. Specification : approx. 12V
  5. Is voltage within specifications ? YES Go to " «GROUND CIRCUIT INSPECTION»(ref-278800-S17134782072008020400000) " procedure. NO Check for open or short in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-278800-S14269648552008020400000) " procedure. If power circuit in harness is OK, Substitute with a known-good Shift CM and check for proper operation. If the problem is corrected, replace Shift CM as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-278800-S14269648552008020400000) " procedure.

Scheme 16

Scheme 16: GROUND CIRCUIT INSPECTION
Scheme 16: GROUND CIRCUIT INSPECTION
  1. Remove "OIL PAN".
  2. Engine "OFF".
  3. Disconnect the "C106-3 and Shift CM" connector.
  4. Measure resistance between terminal "3" of the INPUT SPEED SENSOR harness connector and chassis ground. Specification : approx. 0ohms
  5. Is resistance within specifications? YES Go to " «COMPONENT INSPECTION»(ref-278800-S31865699612008020400000) " procedure. NO Check for open in harness. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-278800-S14269648552008020400000) " procedure.

Scheme 17

Scheme 17: COMPONENT INSPECTION
Scheme 17: COMPONENT INSPECTION

Scheme 18

Scheme 18
Scheme 18
  1. Check "TURBINE SENSOR 2" Ignition "ON" & Engine "OFF". Connect the "C106-3" connector. Measure Frequency between terminal "6" of the C106-3 harness connector and chassis ground. Specification : See «CONNECTOR PIN SPECIFICATION»(ref-278800-S01830015312008020400000) . CONNECTOR PIN SPECIFICATION NAME PIN NO Measurement condition Spec Turbine Sensor1 6 1st gear 12.42 MPH (20km/h) Idle SW OFF Approx. 1.1K(Hz) Turbine Sensor 2 7 4th gear 31 MPH (50km/h) Idle SW OFF CAUTION: Scan tool data link cable is maintain to connecting condition. is frequency within specifications? YES Go to " «CHECK TCM»(ref-278800-S42363626802008020400000) " as below. NO Replace "TURBINE SENSOR" as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-278800-S14269648552008020400000) " procedure.
  2. CHECK TCM Ignition "ON" & Engine "OFF". Disconnect "C106-3" connector. Install scan tool and access "SIMU-SCAN" mode. Simulate frequency to TURBINE SENSOR 1 signal circuit. Is "TURBINE SENSOR 1" signal value changed according to simulation frequency? YES Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-278800-S14269648552008020400000) " procedure. NO Substitute with a known-good TCM and check for proper operation. If the problem is corrected, replace TCM as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-278800-S14269648552008020400000) " procedure.
ItemDetecting ConditionPossible cause
DTC StrategySpeed rationality checkSignal circuit is open or short Sensor power circuit is open Sensor ground circuit is open Faulty INPUT SPEED SENSOR 1 Faulty TCM
Enable ConditionsBattery voltage > 10V Output speed > 1000 RPM Engine speed (Only current gear is the 1st gear) > 3000 RPM Engine speed (2.3.4.5 gear) > 700 RPM Position lever = "D"
Threshold valueInput speed1 < or = 100 RPM
Diagnostic TimeMore than 2sec
Fail Safe"Input speed" is regarded as 600 RPM (Nt = 600 RPM) Shift prevention over 4th gear Prevention of manual shift Prevention of pressure adaptation

DTC DETECTING CONDITION POSSIBLE CAUSE

Refer to DTC P0716 .

Refer to DTC P0716 .
