SPECIFICATION

ItemsBulb Wattage (W)
FRONTHead lamp (High)55
Head lamp (Low)55
Front turn signal lamp28
Front position lamp8
Front fog lamp27
Side marker5
REARRear stop/tail lamp27/8
Back up lamp18
Rear turn signal lamp27
License plate lamp5
Rear side marker5
INTERIORRoom lamp10 x 2
Overhead console lamp10 x 2
Luggage lamp5
Door courtesy lamp5

LIGHTING SYSTEM SPECIFICATIONS

Scheme 1

Scheme 1: COMPONENT LOCATION

Scheme 2

Scheme 2: REMOVAL

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6
  1. Disconnect the negative (-) battery terminal.
  2. Loosen the mounting bolts (3EA). And remove the head lamp assembly (A) after disconnecting the lamp connectors. NOTE: Take care that retaining clip (A) is not to be damaged.
  3. Remove the power connector (A) of lamp assembly.
  4. Remove the fixing spring (A) and bulb connector (B) after loosening the cover.
  5. Remove the head lamp bulb.
ItemSpecification
Back warning control unitVoltage ratingDC 12V
Operation voltageDC 9-16 V
Operation temperature30°C to +80°C
Operation currentMAX 600 mA
Operation frequency40 ± 5 KHz
Detective methodDirect and indirect detection
Ultrasonic sensorVoltage ratingDC 8 V
Detecting range40-120 cm
Operation voltageDC 7.5-8.5 V
Operation currentMAX 20 mA
Operation temperature30°C to + 80°C
Conservation temperature40°C to +85°C
Operation frequency40 ± 5 KHz
Number of sensors4 (Rear Left, Right, Side Left, Right)
Piezo buzzerVoltage ratingDC 12 V
Operation voltageDC 9-16 V
Operation temperature30°C to +80°C
Operation currentMAX 60 mA
Sound, toneOscillation frequency : 2.2 ± 0.5 KHz
Sound level : 70 dB (DC 13V, 1m)

BACK WARNING SYSTEM SPECIFICATIONS

Scheme 7

Scheme 7: DIAGNOSIS

Scheme 8

Scheme 8
  1. DIAGNOSIS Turn the ignition switch ON, then shift the transaxle lever to 'R'. The Back Warning System is then checked. If no trouble, it generates buzzer alarm sound for 0.3 seconds after 0.5 seconds from power approval. In case of system failure, buzzer alarm is generated 3 times continuously with the interval of 0.3 seconds.
  2. DIAGNOSIS MODE Switch on diagnosis mode upon system failure. In case of system failure, then it indicates the failed point as follows.
