WHEN INSTALLING CONNECTING PARTS
FLANGE WITH GUIDE PIN
Check the new O-ring for damage (use only the specified) and lubricate it using compressor oil. Tighten the nut to specified torque.
Precaution When Installing Connecting Parts. Scheme 161
| Size | Tightening torque [ N.m (kg.m, lbf.ft) ] | |
|---|---|---|
| General bolt, nut | ||
| 4T | 7T | |
| M6 | 5-6 (0.5-0.6, 3.6-4.3) | 9-11 (0.9-1.1, 6.5-7.9) |
| M8 | 12-14 (1.2-1.4, 8.7-10) | 20-26 (2.0-2.6, 14-18) |
| M10 | 25-28 (2.5-2.8, 18-20) | 45-55 (4.5-5.5, 32-39) |
| Size | Flange bolt, nut | |
| 4T | 7T | |
| M6 | 5-7 (0.5-0.7, 3.6-5.0) | 8-12 (0.8-1.2, 5.8-8.6) |
| M8 | 10-15 (1.0-1.5, 7-10) | 19-28 (1.9-2.8, 14-20) |
| M10 | 21-31 (2.1 -3.1, 15-22) | 39-60 (3.9-6.0, 28-43) |
TIGHTENING TORQUE SPECIFICATIONS
HANDLING TUBING AND FITTINGS
The internal parts of the refrigeration system will remain in a state of chemical stability as long as pure moisture-free refrigerant and refrigerant oil are used. Abnormal amounts of dirt, moisture or air can upset the chemical stability and cause problems or serious damage.
THE FOLLOWING PRECAUTIONS MUST BE OBSERVED
- When it is necessary to open the refrigeration system, have everything you will need to service the system ready so the system will not be left open any longer than necessary.
- Cap or plug all lines and fittings as soon as they are opened to prevent the entrance of dirt and moisture.
- All lines and components in parts stock should be capped or sealed until they are ready to be used.
- Never attempt to rebind formed lines to fit. Use the correct line for the installation you are servicing.
- All tools, including the refrigerant dispensing manifold, the gauge set manifold and test hoses, should be kept clean and dry.
Refrigeration Flow Cycle. Scheme 162
REFRIGERANT RECOVERY
Use only service equipment that is U.L-listed and is certified to meet the requirements of SAE J2210 to remove HFC-134a (R-134a) from the air conditioning system.
| CAUTION | Air conditioning refrigerant or lubricant vapor can irritate your eyes, nose, or throat. Be careful when connecting service equipment. Do not breathe refrigerant or vapor. |
If accidental system discharge occurs, ventilate work area before resuming service.
Additional health and safety information may be obtained from the refrigerant and lubricant manufacturers.
Scheme 163
- Connect an R-134a refrigerant Recovery/Recycling/Charging System (A) to the high-pressure service port (B) and the low-pressure service port (C) as shown, following the equipment manufacturer's instructions. (Scheme 163): Identifying Recovery/Recycling/Charging System And Low-Pressure Service Port
- Measure the amount of refrigerant oil removed from the A/C system after the recovery process is completed. Be sure to install the same amount of new refrigerant oil back into the A/C system before charging.
SYSTEM EVACUATION
Use only service equipment that is U.L-listed and is certified to meet the requirements of SAE J2210 to remove HFC-134a(R-134a) from the air conditioning system.
| CAUTION | Air conditioning refrigerant or lubricant vapor can irritate your eyes, nose, or throat. Be careful when connecting service equipment. Do not breathe refrigerant or vapor. |
If accidental system discharge occurs, ventilate work area before resuming service.
Additional health and safety information may be obtained from the refrigerant and lubricant manufacturers.
Scheme 164
- When an A/C System has been opened to the atmosphere, such as during installation or repair, it must be evacuated using an R-134a refrigerant Recovery/Recycling/Charging System (If the system has been open for several days, the receiver/dryer should be replaced, and the system should be evacuated for several hours).
- Connect an R-134a refrigerant Recovery/Recycling/Charging System (A) to the high-pressure service port (B) and the low-pressure service port (C) as shown, following the equipment manufacturer's instructions. (Scheme 164): Identifying Recovery/Recycling/Charging System And Low-Pressure Service Port
- If the low-pressure does not reach more than 93.3 kPa (700 mm Hg, 27.6 in. Hg) in 10 minutes, there is probably a leak in the system. Partially charge the system, and check for leaks. See «LEAK TEST»(ref-278806-S20051629652008020400000).
- Remove the low pressure valve from the low-pressure service port.
SYSTEM CHARGING
Use only service equipment that is U.L-listed and is certified to meet the requirements of SAE J2210 to remove HFC-134a(R-134a) from the air conditioning system.
| CAUTION | Air conditioning refrigerant or lubricant vapor can irritate your eyes, nose, or throat. Be careful when connecting service equipment. Do not breathe refrigerant or vapor. |
If accidental system discharge occurs, ventilate work area before resuming service.
Additional health and safety information may be obtained from the refrigerant and lubricant manufacturers.
- Connect an R-134a refrigerant Recovery/Recycling/Charging System (A) to the high-pressure service port (B) as shown, following the equipment manufacturer's instructions. see scheme 7: Connecting R-134A Refrigerant Recovery/Recycling/Charging System To High-Pressure Service Port
- Add the same amount of new refrigerant oil to system that was removed during recovery. Use only specified refrigerant oil. Charge the system with 18.25 ± 0.85 oz. (540 ± 25g) of R-134a refrigerant. Do not overcharge the system the compressor will be damaged.
VERIFICATION OF VEHICLE REPAIR
After a repair, it is essential to verify that the fault has been corrected.
- Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode and then clear DTC.
- Operate the vehicle and monitor the DTC on the scan tool.
- Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.
Refer to DTC B1200 .
Identifying Water Temperature Sensor. Scheme 165
After a repair, it is essential to verify that the fault has been corrected.
- Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode and then clear DTC.
- Operate the vehicle and monitor the DTC on the scan tool.
- Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.
Refer to DTC B1202 .
Identifying Temperature Control Actuator. Scheme 166
After a repair, it is essential to verify that the fault has been corrected.
- Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode and then clear DTC.
- Operate the vehicle and monitor the DTC on the scan tool.
- Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.
After a repair, it is essential to verify that the fault has been corrected.
- Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode and then clear DTC.
- Operate the vehicle and monitor the DTC on the scan tool.
- Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.
Identifying Intake Door Actuator. Scheme 167
After a repair, it is essential to verify that the fault has been corrected.
- Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode and then clear DTC.
- Operate the vehicle and monitor the DTC on the scan tool.
- Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.
Refer to DTC B1208 .
Identifying Temperature Control Actuator. Scheme 168
After a repair, it is essential to verify that the fault has been corrected.
- Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode and then clear DTC.
- Operate the vehicle and monitor the DTC on the scan tool.
- Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.
Refer to DTC B1233 .
Identifying Ambient Temperature Sensor. Scheme 169
After a repair, it is essential to verify that the fault has been corrected.
- Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode and then clear DTC.
- Operate the vehicle and monitor the DTC on the scan tool.
- Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.
Refer to DTC B1237 .
Identifying Evaporator Temperature Sensor. Scheme 170
After a repair, it is essential to verify that the fault has been corrected.
- Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode and then clear DTC.
- Operate the vehicle and monitor the DTC on the scan tool.
- Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.
Refer to DTC B1241 .
Identifying Temperature Control Actuator. Scheme 171
After a repair, it is essential to verify that the fault has been corrected.
- Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode and then clear DTC.
- Operate the vehicle and monitor the DTC on the scan tool.
- Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.
Refer to DTC B1245 .
Identifying Mode Control Actuator. Scheme 172
After a repair, it is essential to verify that the fault has been corrected.
- Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode and then clear DTC.
- Operate the vehicle and monitor the DTC on the scan tool.
- Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.
Refer to DTC B1249 .
Identifying Temperature Control Actuator. Scheme 173
Refer to DTC B1245 .
Refer to DTC B1208 .
Refer to DTC B1249 .
Refer to DTC B1204 .
