Compressor Servicing: Removal & Installation Kia Sephia I рестайлинг

Removal

1. Using clutch plate holder, remove clutch plate bolt. Using puller and forcing screw, remove clutch plate. (Scheme 1)
2. Remove shim(s) and snap ring. Use pulley puller pilot. Use a puller to remove pulley. Remove screw for clutch coil lead. Remove 3 screws and clutch coil.

Installation

1. To install, reverse removal procedure. Align and install clutch coil. Tighten clutch coil screws to 44 INCH lbs. (5 N.m). Using pulley installer and drive handle, tap pulley onto compressor. On DKS-17CH compressor, install cover located under snap ring. On all models, install new snap ring.
2. Tighten clutch plate bolt to 113 INCH lbs. (13 N.m) Using feeler gauge, ensure clearance between clutch plate and pulley is .012-.024" (.30-.60 mm). If clearance is incorrect, add or remove shim(s) as necessary.

Note. Shaft seal servicing procedure not available at time of publication.

Scheme 1
