Power Window Timer Kia Sedona III

Power Window Timer

This function defines the conditions for allowing use of power windows, quarter glass, and feed to sunroof relay coil.

Scheme 28

1. Working Conditions This function is available when ignition key is in RUN position and for 30 sec after end of RUN. Window operation will be canceled if the driver or assist door is opened during the 30 sec period after the key is turned from RUN to ACC or OFF position.
2. Functional Diagram

Scheme 29

1. Description There are two sliding doors and one tailgate in the vehicle. A switch is fitted at each B-pillar to permit Power Sliding Door activation. For the tailgate, there is also one push button switch. These switches are used to send an signal of 200 ms minimum to the PSD module (or PTG module).
2. Functional Diagram

Scheme 30

1. Description The easy access function permits automatic rearward movement of the driver seat when the key is removed from the cylinder. Automatic forward movement of the driver seat will take place when the key is inserted into the cylinder. This function will be enabled on IMS equipped vehicles when the AUTO button is pressed. Inhibit Switch should be in P-Position for the Easy Access operation.
2. Functional Diagram

Scheme 31

1. The instrument cluster indicators listed below are controlled by the In-Panel Module (IPM), Front Area Module (FAM), or Rear Area Module (RAM) as applicable. These indicators are: Gearbox status Oil pressure Sediment fuel filter Vacuum Brake fluid Washer fluid Seat belt Park brake Charging voltage Turn indicators High beam Front fog Doors open Tailgate open Stop lamp failure front and rear
2. Functional Diagram
