Engine Control System: Specifications Kia Sedona III

Testing & Diagnostics 36 illustrations ~247 words

Specifications

(Throttle Position Sensor (TPS))

Throttle Angle (°)Output Voltage (V)
TPS1TPS2
00.05.0
100.54.5
200.94.1
301.43.6
401.83.2
502.32.7
602.72.3
703.21.8
803.61.4
904.10.9
1004.50.5
1105.00.0

VOLTAGE SPECIFICATIONS

Scheme 30

Scheme 30
Scheme 30
ItemSensor Resistance (kohms)
TPS13.6 ~ 6.0 (20°C (68°F))
TPS22.7 ~ 4.1 (20°C (68°F))

RESISTANCE SPECIFICATION

(ETC Motor)

ItemSpecification
Coil Resistance (ohms)1.275 ~ 1.725 (20°C (68°F))

RESISTANCE SPECIFICATION

Scheme 31

Scheme 31: Circuit Diagram
Scheme 31: Circuit Diagram

Specification

Pressure (kPa)Output Voltage (V)
10.00.50
55.02.21
100.03.93
115.04.50

VOLTAGE SPECIFICATION

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33: Circuit Diagram
Scheme 33: Circuit Diagram
TemperatureResistance (kohms)
°C°F
404040.93 ~ 48.35
20413.89 ~ 16.03
0325.38 ~ 6.09
10503.48 ~ 3.90
20682.31 ~ 2.57
401041.08 ~ 1.21
601400.54 ~ 0.66
801760.29 ~ 0.34

RESISTANCE SPECIFICATION

Scheme 34

Scheme 34: Circuit Diagram
Scheme 34: Circuit Diagram
Pressure (kPa)Output Voltage (V)
20.00.79
46.661.84
101.324.0

VOLTAGE SPECIFICATION

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36: Circuit Diagram
Scheme 36: Circuit Diagram
TemperatureResistance (kohms)
°C°F
404048.14
20414.13 ~ 16.83
0325.79
20682.31 ~ 2.59
401041.15
601400.59
801760.32

RESISTANCE SPECIFICATION

Scheme 37

Scheme 37: Circuit Diagram
Scheme 37: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)774 ~ 946 (20°C (68°F))
Air Gap (mm)0.5 ~ 1.5

COIL RESISTANCE SPECIFICATION

Scheme 38

Scheme 38: Wave Form
Scheme 38: Wave Form

Scheme 39

Scheme 39: Circuit Diagram
Scheme 39: Circuit Diagram
ItemSpecification
Output Voltage (V)High: 5.0V
Low: 0.7V
Air Gap (mm)0.5 ~ 1.5

VOLTAGE SPECIFICATION

Scheme 40

Scheme 40: Wave Form
Scheme 40: Wave Form

Scheme 41

Scheme 41: Circuit Diagram
Scheme 41: Circuit Diagram
ItemSpecification
Capacitance (pF)950 ~ 1, 350

CAPACITANCE SPECIFICATION

Scheme 42

Scheme 42: Circuit Diagram
Scheme 42: Circuit Diagram

Scheme 43

Scheme 43: Removal
Scheme 43: Removal

Scheme 44

Scheme 44
Scheme 44
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Disconnect the knock sensor connector (A). (Bank 1) (Bank 2)
  3. Remove the intake manifold. Refer to «INTAKE AND EXHAUST SYSTEM»(/kia/sedona/iii-2014-2020/remont/exhaust/#intake-exhaust-system) .
  4. Remove the installation bolt (A), and then remove the sensor from the cylinder block.

(Bank 1)

Scheme 45

Scheme 45
Scheme 45

(Bank 2)

Scheme 46

Scheme 46
Scheme 46
A/F Ratio (lambda)Output Voltage (V)
RICHMin. 0.8
LEANMax. 0.1

VOLTAGE SPECIFICATION

ItemSpecification
Heater Resistance (ohms)3.3 ~ 4.1 (20°C (68°F))

RESISTANCE SPECIFICATIONS

Scheme 47

Scheme 47: Wave Form
Scheme 47: Wave Form

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49: Circuit Diagram
Scheme 49: Circuit Diagram
TemperatureResistance (kohms)
°C°F
404052.15
20416.52
0326.0
20682.45
401041.11
601400.54
801760.29

RESISTANCE SPECIFICATION

Scheme 50

Scheme 50: Circuit Diagram
Scheme 50: Circuit Diagram
Accelerator PositionOutput Voltage (V)
APS1APS2
C.T.0.7 ~ 0.80.27 ~ 0.47
W.O.T.3.8 ~ 4.41.75 ~ 2.35

VOLTAGE SPECIFICATION

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52: Circuit Diagram
Scheme 52: Circuit Diagram
Pressure (kPa)Output Voltage (V)
3.750.5
02.5
+3.754.5

VOLTAGE SPECIFICATION

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54: Circuit Diagram
Scheme 54: Circuit Diagram
Valve Angle (°)Output Voltage (V)
Mechanical stop04.45 ~ 4.55
Intake Closed73.24 ~ 4.96
Intake Open630.04 ~ 1.76
Mechanical stop700.45 ~ 0.55

VOLTAGE SPECIFICATION

Scheme 55

Scheme 55: Wave Form
Scheme 55: Wave Form

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57: Circuit Diagram
Scheme 57: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)13.8 ~ 15.2 (20°C (68°F))

COIL RESISTANCE SPECIFICATION

Scheme 58

Scheme 58: Circuit Diagram
Scheme 58: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)22.0 ~ 26.0 (20°C (68°F))

COIL RESISTANCE SPECIFICATION

Scheme 59

Scheme 59: Circuit Diagram
Scheme 59: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)9.4 ~ 10.4 (20°C (68°F))

COIL RESISTANCE SPECIFICATION

Scheme 60

Scheme 60: Circuit Diagram
Scheme 60: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)30.0 ~ 35.0 (20°C (68°F))

COIL RESISTANCE SPECIFICATION

Scheme 61

Scheme 61: Circuit Diagram
Scheme 61: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)19.8 ~ 21.8 (20°C (68°F))

COIL RESISTANCE SPECIFICATION

Scheme 62

Scheme 62: Circuit Diagram
Scheme 62: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)19.8 ~ 21.8 (20°C (68°F))

COIL RESISTANCE SPECIFICATION

Scheme 63

Scheme 63: Circuit Diagram
Scheme 63: Circuit Diagram

Scheme 64

Scheme 64: Removal
Scheme 64: Removal

Scheme 65

Scheme 65
Scheme 65
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Disconnect the VCMA connector (A).
  3. Remove the bolts (A) securing the VCMA to the intake manifold.
  4. Separate the VCMA linkage rod (B) from the attachment point on the VCMA lever using a trim clip removal tool.
  5. Remove the VCMA from the vehicle.
