DESCRIPTION
All modules are linked a low speed CAN network.
The input information for the modules is coming from both the CAN network and the hardware components (actuators and sensors).
- FAM (Front Area Module) Headlamp low/high beam control (with DRL) Park lamp control Front fog lamp control Front turn signal lamp control Windshield wiper control Windshield deicer Diagnostics
- IPM (In-Panel Module) RKE (Remote Keyless Control) VAS (Voice Alarm System) Ignition key hole illumination Switch indicators control Panel light control Seat belt warning Auto light/DRL control (Logic) Windshield/Rear wiper control (Logic) Turn and Hazard lamp control (Logic) Central door lock (Logic) Windshield deicer timer Rear glass defog timer Gateway for ISO-9141 (K-Line)
- RAM (Rear Area Module) Tail lamp control Turn and Hazard lamp control Back up lamp control Rear fog lamp control Stop lamp outage detection Sliding door power window/Quarter glass control Room lamp control Rear wiper control Rear glass defog Fuel filler door open solenoid control
- ADM (Assist Drive Module)
- DDM (Driver Drive Module)
MODULE INTRODUCTION
FAM/IPM/RAM consists of a power board and an electronic board. The power board contains circuit protection devices and switching devices. The electronic board uses Intelligent Power Switching (IPS) for HS/LS load control, logic functions and CAN/K-Line communication.
The power board and electronic board are connected with pin blocks for the Front Area Module (FAM) and VCD (Variable Connection Displacement) for the In-Panel Module (IPM) and the Rear Area Module (RAM).
