Setting Limit

1. A limit switch is installed to prevent the seat from traveling beyond the maximum forward/reward positions.
2. No limit switch is installed for the recline, height, or pedal adjustments. Arbitrary limit positions are used for these functions.

Detecting Errors For Seat

Take countermeasure against error if the following conditions occur during manual switch operation.

1. Error when pulse is not fed.

PULSE ERROR

1. Stop the related motor (seat/pedal) if an error is detected during playing or Easy access function operation.
2. Stop the corresponding motor if an error is detected during manual operation (excluding slide motor).

1. If seat sensor Vcc below 1V is detected by 1s Stop all seat motors running if seat sensor Vcc error is detected during playing or Easy access function operation. (no buzzer output)
2. Return if seat sensor Vcc is 4V or more.

Handling Errors

1. If errors are discovered, regard them as harness disconnection or sensor failure, and conduct the following measures.

1. Stop auto control (play or Easy access function operation) if it is under auto control and set off buzzer 10 times (however, have motors other than the one with an error operate normally).
2. Set off alarm again in case of recurrence of error after restoration of a motor with an error.
3. Complete alarm 10 times though it comes back to normal during error alarm.
4. Stop alarm if receiving memory recall or play order, and set off buzzer in the corresponding function.
5. Manual operation control is allowed even for a motor with errors.
6. Set off buzzer if memory or play order is received even during error.
7. The timing to lift auto control suspension is when repair for the failing motor is completed, and the criteria for the completion point are as follows

1. Seat: if signal input is normal with over 6 pulses within a sec. from position sensor of a motor with an error caused by manual switch.
2. Adjust pedal: if there is change in input of over 3 LSB within 1 sec. from sensor by manual switch.

Scheme 6

Scheme 7

1. Disconnect the negative (-) battery terminal.
2. Remove the seat back. Refer to «FRONT SEATS»(ref-584203-S09856077012013110100000) .
3. Remove the power seat module after removing the power seat module mounting nuts (4 EA) and connector (3 EA).
4. Installation is the reverse of removal.

Scheme 8

1. Remove the negative (-) battery terminal.
2. Remove the front door trim panel in the car. Refer to «FRONT DOOR»(ref-584210-S41936095862013110100000) .
3. Remove the switch (A) mounting screws (3 EA) after disconnecting the 16 pin switch connector.
4. Remove the connector from the front door trim panel.
5. Installation is the reverse of removal.
