Description
The AUX, iPod and USB JACK on the center console is for customers who like to listen to external portable music players like the MP3, iPod, earphone, USB memory stick, CD player and etc., through the vehicle's sound system when it is linked to this jack. The customer has this added option.
In case of distortions from media connected to the AUX source, the audio unit may not be defect but the output level of the used media does not match the specification of the AUX input.
Scheme 6
Scheme 7
Scheme 8
- Disconnect the negative (-) battery terminal.
- Remove the center fascia panel, console lower cover, center air vent, switches, tray and heater control panel (A). Refer to «CRASH PAD»(ref-584184-S20633735772013110100000) .
- Remove the AUX jack (B) after removing the tray (A) mounting screws.
