FUEL TANK PRESSURE SENSOR (FTPS)
- Type: Piezo - Resistivity type
- Specification
| Pressure (kPa) | Output Voltage (V) |
|---|---|
| 3.75 | 0.5V |
| 0 | 2.5V |
| +3.75 | 4.5V |
FUEL TANK PRESSURE SENSOR (FTPS) SPECIFICATION
PURGE CONTROL SOLENOID VALVE (PCSV)
- Specification
| Item | Specification |
|---|---|
| Coil Resistance (ohms) | 19.0-22.0 ohms [20°C) (68°F)] |
PURGE CONTROL SOLENOID VALVE (PCSV) SPECIFICATION
CANISTER CLOSE VALVE (CCV)
- Specification
| Item | Specification |
|---|---|
| Coil Resistance (ohms) | 19.8-21.8 ohms [20°C (68°F)] |
CANISTER CLOSE VALVE (CCV) SPECIFICATION
COMPONENT
| Components | Function | Remarks |
|---|---|---|
| Crankcase Emission System Positive Crankcase Ventilation (PCV) valve | HC reduction | Variable flow rate type |
| Evaporative Emission System Evaporative emission canister Purge Control Solenoid Valve (PCSV) | HC reduction HC reduction | Duty control solenoid valve |
| Exhaust Emission System MFI system (air-fuel mixture control device) Three-way catalytic converter | CO, HC, NOx reduction CO, HC, NOx reduction | Heated oxygen sensor feedback type Monolithic type |
COMPONENT REFERENCE CHART
