Fuses & Relays: Overview Kia Sedona II

Fuses & Circuit Breakers 17 illustrations ~434 words

Scheme 1

Scheme 1: COMPONENT LOCATION
Scheme 1: COMPONENT LOCATION

Scheme 2

Scheme 2: FAM (FRONT AREA MODULE)
Scheme 2: FAM (FRONT AREA MODULE)

For fuse and relay locations within the engine compartment fuse/relay box (Scheme 2)

Use designated fuses only.

DescriptionFuse RatingProtected Components
FRT/RR WASHER10AFRONT WASHER MOTOR RELAY, REAR WASHER MOTOR RELAY
STOP LAMP20ASTOP LAMP SWITCH
KEY SW #125AIGNITION SWITCH
STOP SIGNAL7.5AABS CONTROL MODULE, ESC MODULE, PCM
A/C COMP7.5AA/C COMP RELAY, ATM RELAY
ATM15AATM RELAY
FRT DEICER15AWINDSHIELD DEFOGGER RELAY
HORN15AHORN RELAY
ECU #110AA COMP RELAY, PCM, MASS AIR FLOW SENSOR, IMMOBILIZER MODULE
O2 DN10AOXYGEN SENSOR #3, OXYGEN SENSOR #4
ECU #215APCM MAIN VALVE, COOLING FAN RELAY, PCSV, OCV, CCV
O2 UP10AOXYGEN SENSOR #1, OXYGEN SENSOR #2
IGN COIL20AIGNITION COIL #1 - #6, CONDENSER #1, #2
INJECTOR15AINJECTORS #1 - #6, PCM
P/TRAIN7.5AMAIN RELAY, BURGLAR ALARM RELAY, PCM
FUEL PUMP15AFUEL PUMP RELAY
ABS #140AABS CONTROL MODULE, ESC MODULE
ABS #220AABS CONTROL MODULE, ESC MODULE
F/WIPER30AFRONT WIPER ON RELAY
KEY SW #230ASTARTER RELAY, IGNITION SWITCH
FRT BLOWER40AFront Blower Relay
RR BLOWER30ARear Blower Relay
IPM #150AIPM
IPM #250AIPM
IPM #350AIPM
RAM #150ARAM
RAM #250ARAM
RAM #350ARAM

IDENTIFYING FUSES & RELAYS (ENGINE COMPARTMENT FUSE/RELAY BOX - FAM)

  1. Be sure there is no play in the fuse holders, and that the fuses are held securely.
  2. Are the fuse capacities for each circuit correct?
  3. Are there any blown fuses? If a fuse is to be replaced, be sure to use a new fuse of the same capacity. Always determine why the fuse blew first and completely eliminate the problem before installing a new fuse.

Scheme 3

Scheme 3: RELAY
Scheme 3: RELAY

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8
  1. Be sure that the relays are held the each module securely.
  2. Are the relay types for each circuit correct?
  3. If system of some relay is not operate accurately, replace with a new one and check the system.

Scheme 9

Scheme 9: FAM (FRONT AREA MODULE)
Scheme 9: FAM (FRONT AREA MODULE)

Scheme 10

Scheme 10
Scheme 10
  1. Disconnect the negative (-) battery terminal.
  2. Remove the FAM cover of engine room.
  3. Remove the FAM connectors (2EA) (A) and battery terminal nut (1EA) (B).
  4. Remove FAM mounting bolts (3EA-) (A) and remove the FAM (B) from splash shield (C).
  5. Disconnect the connector from splash shield.
  6. Installation is the reverse of removal.

Scheme 11

Scheme 11: IPM (INSTRUMENT PANEL MODULE)
Scheme 11: IPM (INSTRUMENT PANEL MODULE)

For fuse locations within the passenger compartment fuse box (Scheme 11)

Use designated fuses only.

DescriptionFuse RatingProtected Components
ACC7.5APOWER OUTSIDE MIRROR SWITCH, AUDIO, DIGITAL, CLOCK & TELLTALE, RSE MODULE, KEY INTERLOCK RELAY
P/OUTLET #215ACIGARETTE LIGHTER
START7.5ABURGLAR ALARM RELAY, TRANSAXLE RANGE SWITCH
AIRBAG IND7.5AINSTRUMENT CLUSTER
ENG7.5AATM LEVER SWITCH, STOP LAMP SWITCH, INPUT SPEED SENSOR, OUTPUT SPEED SENSOR, TRANSAXLE RANGE SWITCH, PCM, VEHICLE SPEED SENSOR
IG17.5ATRIP COMPUTER, BACK WARNING BUZZER, RHEOSTAT, TIRE PRESSURE MONITORING MODULE, ESC SWITCH, INSTRUMENT CLUSTER, OC SENSOR, MULTIFUNCTION SWITCH
ABS7.5AABS CONTROL MODULE, EEC MODULE, YAW RATE SENSOR, STEERING ANGLE SENSOR, MULTIPURPOSE CHECK CONNECTOR
AIRBAG15ADIGITAL CLOCK & TELLTALE, SRS CONTROL MODULE
TPMS7.5ATIRE PRESSURE MONITORING MODULE, FRONT INITIATOR LH/RH, REAR INITIATOR LH/RH
PEDAL15AADJUST PEDAL RELAY
P/OUTLET #115AFRONT POWER OUTLET
ASS P/SEAT20AASSISTOR POWER SEAT MODULE
DRV P/SEAT30ALIMIT SWITCH, DRIVER POWER SEAT MODULE
OBD-II7.5ADATA LINK CONNECTOR, MULTIPURPOSE CHECK CONNECTOR
ROOM7.5AOC SENSOR, HOME LINK, VANITY LAMP LH/RH, A/C CONTROL MODULE, MAP LAMP, REAR ROOM LAMP SWITCH
K/LOCK7.5AKEY INTERLOCK RELAY
ILLUMI7.5AIPM
AMP25AAMP
S/WARMER20ASEAT WARMER RELAY
SUNROOF25ASUNROOF MODULE
AUDIO15ASTEP LAMP LH/RH, AUDIO, RSE MODULE
MEMORY7.5AA/C CONTROL MODULE, DIGITAL CLOCK & TELLTALE, INSTRUMENT CLUSTER, TRIP COMPUTER, DOOR MODULE, FAM, DRIVER POWER SEAT MODULE
IG2 #17.5AMULTIFUNCTION SWITCH, A/C CONTROL MODULE, HOME LINK, ELECTRO CHROMIC MIRROR, RAIN SENSOR, RELAY BOX
1G2 #27.5ADOOR MODULE, REAR A/C CONTROL SWITCH, FAM, DRIVER POWER SEAT MODULE
DDM30ADRIVER DOOR MODULE
ADM30AASSISTOR DOOR MODULE

IDENTIFYING FUSES (PASSENGER COMPARTMENT FUSE BOX - IPM)

Scheme 12

Scheme 12: RAM (REAR AREA MODULE)
Scheme 12: RAM (REAR AREA MODULE)

For fuse locations within the passenger compartment rear area fuse box (Scheme 12)

Use designated fuses only.

DescriptionFuse RatingProtected Components
PSD-LH30APOWER SLIDING DOOR MODULE LH
PSD-RH30APOWER SLIDING DOOR MODULE RH
RR-DEFOG25ARR DEFOG RELAY, REAR DEFOGGER
POWER TAILGATE30APOWER TAIL GATE MODULE
P/QUARTER10AQUARTER GLASS OPEN RELAY LH, QUARTER GLASS CLOSE RELAY LH QUARTER GLASS OPEN RELAY RH, QUARTER GLASS CLOSE RELAY RH
RR/WIPER15ARR WIPER RELAY, REAR WIPER MOTOR
RR D/LOCK20AS/DOOR LOCK RELAY, S/DOOR UNLOCK RELAY SLIDING DOOR LOCK ACTUATOR, TAILGATE LOCK ACTUATOR
PR P/OTLT-LH15AREAR POWER OUTLET LH
PR P/OTLT-RH15AREAR POWER OUTLET RH
FUEL DOOR15AFUEL FILLER RELAY, FUEL FILLER ACTUATOR
RR P/WIN-LH25AS/DOOR WINDOW RELAY (UP) LH S/DOOR WINDOW RELAY (DN) LH
RR P/WIN-RH25AS/DOOR WINDOW RELAY (UP) RH S/DOOR WINDOW RELAY (DN) RH
LUGGAGE7.5ALUGGAGE LAMP, POWER TAILGATE ON/OFF SWITCH

IDENTIFYING FUSES (REAR AREA PASSENGER COMPARTMENT FUSE BOX - RAM)

  1. Be sure there is no play in the fuse holders, and that the fuses are held securely.
  2. Are the fuse capacities for each circuit correct?
  3. Are there any blown fuses? If a fuse is to be replaced, be sure to use a new fuse of the same capacity. Always determine why the fuse blew first and completely eliminate the problem before installing a new fuse.

Scheme 13

Scheme 13: RELAY
Scheme 13: RELAY
  1. Be sure that the relays are held the each module securely.
  2. Are the relay types for each circuit correct?
  3. If system of some relay is not operate accurately, replace with a new one and check the system.

Scheme 14

Scheme 14: IPM (INSTRUMENT PANEL MODULE)
Scheme 14: IPM (INSTRUMENT PANEL MODULE)

Scheme 15

Scheme 15
Scheme 15
  1. Disconnect the negative (-) battery terminal.
  2. Remove the crash pad lower panel (A). (Refer to «CRASH PAD»(ref-269624-S13157458082007110100000) ).
  3. Disconnect the receiver antenna cable and connectors (5EA). Remove IPM mounting nuts (3EA) and IPM (A).
  4. Installation is the reverse of removal procedures.

DESCRIPTION

The ICM (Integrated circuit module) relay (A) is united with many kinds of relays and installed side of the in-panel module.

Scheme 16

Scheme 16: DESCRIPTION
Scheme 16: DESCRIPTION

Scheme 17

Scheme 17
Scheme 17

More articles — Fuses & Relays
