Sunroof: Overview Kia Sedona I

Scheme 1

Scheme 2

1. Operate the switch and check for the continuity between the terminal.
2. If the continuity is not as specified, replace the switch.

Scheme 3

Scheme 4

1. Apply battery voltage to the terminals 1 & 8 and ground terminal 3.
2. Apply the battery voltage to terminals as below table, and check that the sunroof unit operates as below table.

Scheme 5

Scheme 6

Scheme 7

1. Remove headliner. See «REMOVAL & Installation»(ref-176725-S22622770092005051000000) .
2. Remove glass panel. Tighten glass mounting nuts to 4-6 N.m (40-60kg.cm, 35-52 lb.ft)
3. Disconnect the drain hose.
4. Remove the sunroof mounting bolts and nuts, and remove the sunroof assembly. Tighten sunroof mounting bolts to: 7-11 N.m (70-110 kg.cm, 61-95 lb.ft) Tighten sunroof mounting nuts to: 4-6 N.m (40-60 kg.cm, 35-52 lb.ft)

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

1. Remove the drip rail.
2. Remove the stopper.
3. Remove the sunshade.
4. Remove the guide assembly.
5. Remove the deflector.
6. Remove the motor assembly.
7. Assembly is the reverse of disassembly.
