Fuses & Circuit Breakers: Other Kia Sedona I

Fuses & Circuit Breakers 4 illustrations

PASSENGER COMPARTMENT FUSE BOX

Note. Passenger compartment fuse box is located behind access panel on driver's side kick panel. (Scheme 1)

Scheme 1

Scheme 1: PASSENGER COMPARTMENT FUSE BOX

Scheme 1: PASSENGER COMPARTMENT FUSE BOX

Scheme 2

Scheme 2

Scheme 2

ENGINE COMPARTMENT FUSE/RELAY BOX

Note. Engine compartment fuse/relay box is located on driver's side of engine compartment, in front of shock tower. (Scheme 3)

Scheme 3

Scheme 3: ENGINE COMPARTMENT FUSE/RELAY BOX

Scheme 3: ENGINE COMPARTMENT FUSE/RELAY BOX

Scheme 4

Scheme 4

Scheme 4
