Driving Plate: Overview Kia Sedona I

Replace the distorted, damaged, or cracked drive plate.

Scheme 120

Scheme 121

Scheme 122

Scheme 123

Scheme 124

1. Install the grooved main bearing (upper bearing) on the cylinder block side.
2. Install the grooveless main bearing (lower bearing) on the main bearing cap side.
3. Install the crankshaft. Apply engine oil to the journal and pin.
4. Caps should be installed with the arrow mark directed toward the front of the engine. The cap number sequence must be correct.
5. Tighten all cap bolts to the specified torque according to the order as shown (Scheme 123) Main bearing cap bolt, tightening torque: 68.6-78.5 N.m (700-800 kg.cm, 50.6-57.9 lb.ft)
6. Cap bolt should be tightened to specified torque in 4~5 steps before being tightened to the specified torque.
7. Make certain that the crankshaft turns freely and has the proper crankshaft end play. Crankshaft end play, standard value: 0.050-0.250 mm (0.00197-0.0098 in) Limit: 0.35mm (0.014 in)
8. Assemble the rear oil seal to oil case using the special tool (09231-33000).
9. Install the drive plate and the adapter plate. Tightening torque Drive bolt: 73 - 77 N.m (730 - 770 kg.cm, 53.85 - 56.80 lb.ft)

Scheme 125
